1inch Sanitary A790 Metal Pipe Mirror Ss Hollow For Construction
1inch Sanitary A790 Metal Pipe Mirror Ss Hollow For Construction
1inch Sanitary A790 Metal Pipe Mirror Ss Hollow For Construction
1inch Sanitary A790 Metal Pipe Mirror Ss Hollow For Construction
1inch Sanitary A790 Metal Pipe Mirror Ss Hollow For Construction
1inch Sanitary A790 Metal Pipe Mirror Ss Hollow For Construction
1inch Sanitary A790 Metal Pipe Mirror Ss Hollow For Construction
1inch Sanitary A790 Metal Pipe Mirror Ss Hollow For Construction
Specifications
Brand Name :
xinzheng
Model Number :
Sanitary Tube
Certification :
ISO,SGS,ISO & SGS,ISO/CE/SGS
Place of Origin :
CHINA
MOQ :
1 PCS
Price :
1-2USD / kg
Payment Terms :
L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
4000 MT PER week
Delivery Time :
5-25 Days
Packaging Details :
Standard seaworthy export package
Standard :
ASME ,AISI,ASTM, EN, ISO
seamless Tube :
Up To 652 mm OD
wall thickness :
0.5mm to 200 mm
Trade Name :
304H stainless steel
Technique :
Cold drawn , Hot rolled
Application :
exausting pipe
Type :
Seamless , Welded
Finish :
Polished , Mill finished
Welding line type :
Seamless
Description

304 / 316 Astm A790 Mirror Polished Finished Stainless Steel Hollow Pipe / Tube For Construction

Xinzheng Steel Industries is supplying Stainless Steel Hollow Tube in different thickness, different diameter length, and in different quality. Generally, these Hollowed steel tubes have high corrosion resistance capacity, high deformability, high toughness and higher strength. Available in different dimensions & grades, these SS Hollow Tube are widely used in different industrial applications. For building sewages and water pipes, these steel hollow tubes are used. According to the different applications, the Stainless Steel Seamless Hollow Tube have different diameters. In the construction industry, these Hollow stainless steel tubes are used most widely. Whenever, any customization is needed, these Hollow Tubes can be customized very easily. Trilok Steel Industries is specialized as providing Stainless steel Hollow Tube Section in Polished Grit 120 - 600 finish. Hollow stainless steel tubes are available as per requirement of application.

304 / 316 Astm A790 Mirror Polished Finished Stainless Steel Hollow Pipe / Tube For Construction Specification and Dimension Ranges

STAINLESS STEEL HOLLOW PIPE SPECIFICATION

Stainless Steel Hollow
Pipe Size		 1/2 inch, 3/4 inch, 1 inch
Stainless Steel Hollow Pipe Suppliers Grades TP - 304, 304L, 316, 316L, 201

Stainless Steel Hollow

Pipe Standards

 ASTM A249 - A269 - A312 - A358 - A409 - A554 - A778 - A789 - A790
Stainless Steel Hollow Pipe Finish Polished Grit 120 - 600, Seamless, Welded, Brushed, Pickled, Solution Annealed and Pickled up to O.D. 219.1mm,Mirror Polished

STAINLESS STEEL HOLLOW PIPE DIAMETER, HOLLOW STAINLESS STEEL PIPE WEIGHT CHART

Stainless Steel Hollow Pipes Wall Thickness & Weight
Nominal Pipe Size Outside Diameter Schedule 5S Schedule 10S Schedule 40S
W.T. W.T. W.T.
in inch in mm mm kg/Mt. mm kg/Mt. mm kg/Mt.
1/2 21.34 1.65 0.81 2.11 1.01 2.77 1.28
3/4 26.67 1.65 1.03 2.11 1.3 2.87 1.70
1 33.4 1.65 1.31 2.77 2.12 3.38 2.53
1 1/4 42.16 1.65 1.67 2.77 2.72 3.56 3.43
1 1/2 48.26 1.65 1.92 2.77 3.15 3.68 4.10
2 60.33 1.65 2.42 2.77 3.98 3.91 5.51
2 1/2 73.03 2.11 3.74 3.05 5.03 5.16 8.75
3 88.9 2.11 4.57 3.05 6.54 5.49 11.44
3 1/2 101.6 2.11 5.25 3.05 7.51 5.74 13.75
4 114.3 2.11 5.95 3.05 8.48 6.02 16.29
5 141.3 2.77 9.59 3.4 11.72 6.55 22.0

other Stainless steel Tubing Dimension ranges :

Product Name Executive Standard Dimension Steel Code / Steel Grade
Industrial Pipes ASTM A312, A358, A778, JIS G3459 OD: 1/4"~40" TP304, TP304L, TP316L, SUS304TP
WT: SCH5S~SCH80S
Tubes for Boiler and Heat-Exchanger, General Service Tubing ASTM A249, A269, JIS G3463 OD: 15.9~139.8mm TP304, TP304L, TP316L, SUS304TB
WT: 1.6~5.0mm
Mechanical and Structural Tubes ASTM A554, JIS G3446 OD: 7.9~152.4mm MT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD SUS304
WT: 0.5~6.5mm
Square Tubes ASTM A554 OD: 12.7x12.7~150x150mm MT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD
WT: 0.7~6.5mm
Rectangular Tubes ASTM A554 OD: 10x20~100x200mm MT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD
WT: 0.7~6.5mm
Sanitary Tubing ASTM A270 OD: 25.4~165.2mm TP304, TP304L, TP316L, SUS304TBS
JIS G3447 WT: 0.8~3.05mm
Large Gauge Pipes for Ordinary Piping JIS G3448 OD: 15.88~318.5mm SUS304TPD
WT: 0.8~3.0mm
Large Diameter Pipes JIS G3468 OD: 14"~40" SUS304TPY
WT: SCH5S~SCH40S

304 / 316 Astm A790 Mirror Polished Finished Stainless Steel Hollow Pipe / Tube For Construction Technical datasheet

STAINLESS STEEL HOLLOW PIPE CHEMICAL COMPOSITION

The below table shows the chemical composition of the used for Stainless Steel Hollow Pipes:

STAINLESS STEEL HOLLOW PIPE GRADES UNS C Mn P S Si Cr Ni Mo Ti Nb N
TP304 S30400 0.08 2 0.045 0.03 1 18.0-20.0 8.0-11.0
TP304L S30403 0.035 2 0.045 0.03 1 18.0-20.0 8.0-13.0
TP316 S3160 0.08 2 0.045 0.03 1 16.0-18.0 11.0-14.0 2.0-3.0
TP316L S31603 0.035 2 0.045 0.03 1 16.0-18.0 10.0-14.0 2.0-3.0

STAINLESS STEEL HOLLOW PIPE MECHANICAL PROPERTIES

Material Heat Temperure Tensile Strength Yield Strength Elongation %, Min
Treatment Min. Ksi (MPa), Min. Ksi (MPa), Min.
º F(º C)
TP304 Solution 1900 (1040) 75(515) 30(205) 35
TP304L Solution 1900 (1040) 70(485) 25(170) 35
TP316 Solution 1900(1040) 75(515) 30(205) 35
TP316L Solution 1900(1040) 70(485) 25(170) 35

304 / 316 Astm A790 Mirror Polished Finished Stainless Steel Hollow Pipe / Tube For Construction Package

1inch Sanitary A790 Metal Pipe Mirror Ss Hollow For Construction1inch Sanitary A790 Metal Pipe Mirror Ss Hollow For Construction

1inch Sanitary A790 Metal Pipe Mirror Ss Hollow For Construction

1inch Sanitary A790 Metal Pipe Mirror Ss Hollow For Construction

1inch Sanitary A790 Metal Pipe Mirror Ss Hollow For Construction

1inch Sanitary A790 Metal Pipe Mirror Ss Hollow For Construction

FAQ


Q: Would you provide samples For free?

A: Yes . with on stock specification We provide samples For Free . Freight charge collect

Q: What information should i provide to source for the right products ?
A: Material grade, width, thickness, coating and Purchase quantity , Expected lead time ,etc

Q: What are the shipping ports?
A: Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports, you can choose other ports according to your needs.

Q: About product prices?
A: Prices vary from period to period due to cyclical changes in the price of raw materials.


Q: How long does your delivery time take?
A: In general, our delivery time is within 5-45 days, and may be delayed if the demand is extremely large or special circumstances occur.

Q: Can I visit your location?
A: Of course, we welcome customers from all over the world to visit our factory. However, some of the plants are not open to the public.

Q: Does the product have quality inspection before loading?
A: Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.

Q: How to pack the products?
A: The inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation wooden pallet. It can effectively protect products from corrosion during ocean transportation.

Q: What is your working time?
A: In general, our online service time is Beijing time: 8:00-22:00, after 22:00, we will reply to your inquiry during the next working day.

304 / 316 Astm A790 Mirror Polished Finished Stainless Steel Hollow Pipe / Tube For Construction Synonyms

Sanitary tubing ,sanitary tube , sanitary pipe , dairy tubing ,dairy pipe ,dairy tubing , water tubing ,

water tube , water piping , food grade tubing , Aerospace tubes ,ANSI/ASME pipe ,ASME/ASTM welded pipe
Bimetallic tubes ,Boiler tubes,Capillary tubes,Chemical injection lines ,Coiled tubing,Composite tubes ; Condenser tubes ; Control lines ; Downhole casing ; Ethylene furnace tubes ; Evaporator tubes ; Finned tubes ; Fittings ; Flanges ; Flowline piping ; Furnace tubes ; GDI and CNG fuel system tubes ; Heat exchanger tubes ; Phosphoric acid production ; Urea production ; High-pressure tubes ; High-temperature tubes; Hollow bar ; Hydraulic tubing ; Instrumentation tubing ; ISO/EN tubes ; Lance tubes ; Mechanical tubing
Medical tubes ;Muffle tubes ; Nitric acid tubes ; Nuclear fuel tubes ; Nuclear steam generator tubing
Precision tubes ; Production tubing (OCTG) ; Recuperator tubes ; Reheater tubes ; Riser tubes ; Scrubber tubes ; Steam generator tubes ; Stripper tubes; Subsea tubes ; Superheater tubes ; Thermocouple tubes
Titanium tubes ; Umbilical tubes ; Zirconium tubes, Nickel alloy tube ,Nickel alloy tubing , super aolly Tube , Superalloy tubing , Copper tube , copper tubing . ANSI/ASME pipe ASME/ASTM welded pipe Bimetallic tubes Boiler tubes Capillary tubes Chemical injection lines Coiled tubing Composite tubes Condenser tubes Control lines Downhole casing Ethylene furnace tubes Evaporator tubes Finned tubes Fittings Flanges Flowline piping Furnace tubes GDI and CNG fuel system tubes Heat exchanger tubes High-pressure tubes High-temperature tubes Hollow bar Hydraulic tubing Instrumentation tubing ISO/EN tubes Lance tubes Laying head pipe Mechanical tubing Medical tubes Muffle tubes Nitric acid tubes Nuclear fuel tubes Nuclear steam generator tubing Precision tubes Production tubing (OCTG) Recuperator tubes Reheater tubes Riser tubes Scrubber tubes Steam generator tubes Stripper tubes Subsea tubes Superheater tubes Thermocouple tubes Titanium tubes Umbilical tubes Zirconium tubes
