A653M Z60 Resin Coated Galvanized Steel Coil Hot Dip Galvanized Preservative
A653M Z60 Resin Coated Galvanized Steel Coil Hot Dip Galvanized Preservative
A653M Z60 Resin Coated Galvanized Steel Coil Hot Dip Galvanized Preservative
A653M Z60 Resin Coated Galvanized Steel Coil Hot Dip Galvanized Preservative
A653M Z60 Resin Coated Galvanized Steel Coil Hot Dip Galvanized Preservative
A653M Z60 Resin Coated Galvanized Steel Coil Hot Dip Galvanized Preservative
A653M Z60 Resin Coated Galvanized Steel Coil Hot Dip Galvanized Preservative
A653M Z60 Resin Coated Galvanized Steel Coil Hot Dip Galvanized Preservative
Specifications
Brand Name :
Tisco
Model Number :
GI COIL
Certification :
ISO9001,SGS, ROHS,Third part
Place of Origin :
CHINA
MOQ :
1 MT
Price :
1000-3000 USD / MT
Payment Terms :
L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
4000 MT PER week
Delivery Time :
5-15 Days
Packaging Details :
The Coils Are Packed In Eye-to-sky Or Eye-to-wall Position, Wrapped In HDPE And Hardboard, Strapped With Hoop Iron And Placed On Wooden Pallets. Moisture Protection Is Provided By Silica Gel Packets.
Base Type :
Cold-rolled Base ， Hot rolled Base
Specification :
CNS 1244 2013 JIS G 3302 2019 ASTM A653M 2017 AS1397 2011 EN 10346 2015
Coating Mass :
Z08~Z60 ,Z90~Z600
Thickness of Base Steel (mm) :
0.27mm-2mm
Surface Finish :
Regular Spangle, Minimized (Zero) Spangle, Extra-Smooth
Surface Treatment :
Chromating, Oiled, Resin Coated (Anti-Fingerprint), or Green Treatment (Environmentally Friendly Anti-Fingerprint)
Application :
doors, window hoods, gutters, downspouts, etc.
Package :
The coils are packed in eye-to-sky or eye-to-wall position, wrapped in HDPE and hardboard, strapped with hoop iron and placed on wooden pallets. Moisture protection is provided by silica gel packets.
Name :
HDP Coil ; GI COIL ; Galvanized Coil
Coil INNER Diameter :
508MM, 610MM ,405MM ,ETC
Description

ASTM A653M Regular Spangle Zinc Coated Galvanized Coil / GI Coil For Doors and windows

Passing cold rolled / Hot rolled coil through a melted zinc bath, in order to coat the steel with a thin layer of zinc to provide corrosion resistance, is called hot dip galvanizing.


Hot dip galvanized coils (GI coils) have many applications in construction/building, roofing, automotive parts, sections, profiled sheets, etc...

As a galvanized coils (GI coils) supplier you can always contact us for questions about our coil products or pricings.

GALVAZINC products have superior corrosion resistance thanks to a thicker coating layer than thin coated sheets with high formability and weldability. Produced by the continuous galvanizing line, products has good coating adhesion and formability, combined with excellent corrosion resistance and lubricity imparted by various chemical treatments.

Galvanized Coil / GI Coil Synonyms

HDP , GI Coil , Galvanized steel coil , Galvanized Steel coil sheet , GI Steel coils sheet , GI Strips , Galvanized strips . gi coil sheet gi coil galvanized steel .gp coil sheet. gp coils galvanized steel .ga coil China, ppgi coil . ppgi coils galvanized steel. ppgi coils color. ppgi coil manufacturer. ppgi , ppgi steel , ppgi coil

Zinc Coated Galvanized Coil / GI Coil Specication ,Surface Finish, Size Range

Hot-dip Galvanized Steel Coil
CNS 1244 2013 JIS G 3302 2019 ASTM A653M 2017 AS1397 2011 EN 10346 2015
Specifications Hot-rolled Base: Cold-rolled Base: Hot-rolled Base: Cold-rolled Base: DS G1~G3 DX51-52-53D
SGHC SGCC SGHC SGCC DDS G250 S220GD
SGHD SGCD SGHD SGCD CS TYPE A, B, C 300 (250
SGH 1~3 SGH 1~3 FS TYPE A, B 350 280
340 SGC 340 SGC SS GRADE 400 320
400 340 400 340 33(230) 450 350
440 400 440 400 37(255) 550 550)
490 440 490 440 40(275)
540 490 540 490 50(340)CLASS 1~3
570 570 80(550)CLASS 1~3
Thickness of Base Steel (mm) 1.2~4.60 SGCD1~3: 0.27~2.0mm 1.2~4.60 SGCC,SGC340: 0.18~3.0mm; DS: 0.27~2.0mm; G1: 0.19~4.50mm; DX51D: 0.19~4.50mm;
SGCC/SGC: 0.19~2.0mm SGCD1~3: 0.25~2.0mm; DDS: 0.25~2.0mm; G2&G3: 0.27~2.0mm; S220~550GD: 0.19~4.6mm;
SGC400, 440: 0.229~3.0mm; CS/FS: 0.19~4.50mm; G250~550GD: 0.19~4.6mm; S250GD: 0.18~2.02mm;
SGC490: 1.8~3.0mm; SS GRADE 33~80: 0.19~4.50mm; G300: 0.229~2.3mm; DX52D: 0.295~2.0mm;
SGC570: 0.229~2.2mm CS TYPE A, B, C, Grade 33, 37: 0.18~3.0mm; G350: 0.229~3.0mm; DX53D, 54D: 0.25~2.0mm;
FS TYPE A, B: 0.295~2.0mm; G450: 0.6~3.0mm; S280GD, S350GD: 0.229~3.0mm;
Grade 40, 50: 0.229~3.0mm; G500: 1.1~2.5mm; S320GD: 0.229~2.3mm;
Grade 55(380): 0.35~3.0mm; G550: 0.229~2.2mm S550GD: 0.229~2.2mm
Grade 60(410): 0.47~1.6mm;
Grade 65(450): 0.6~3.0mm;
Grade 80: 0.229~2.2mm
Coating Mass: Z08~Z60 Z08~Z60 Z90~Z600 Z100~Z600 Z100~Z350
Regular Spangle
(thickness > 0.60mm)
Minimized (Zero)
Spangle
Surface Finish Regular Spangle, Minimized (Zero) Spangle, Extra-Smooth
Surface Treatment Chromating, Oiled, Resin Coated (Anti-Fingerprint), or Green Treatment (Environmentally Friendly Anti-Fingerprint)
Remarks 1. Tolerance for thickness, width, flatness and so on conforms to individual product specification.
2. All products with thickness 2.0mm and under can be skin passed.
3. The specification for thicknesses under 1.6mm for hot-rolled base metal according to JIS G3302 will be the same as for thicknesses 1.6mm.
4. The coil inside diameters can be either 508mm or 610mm. The maximum coil outside diameter is 2000mm.
5. Please make inquiries to our Sales & Marketing Division for products with special specifications.
6. Coating mass beyond the specifications above can be provided by Yieh Corp. upon mutual agreement between customers and us.
7. Coating mass Z08, Z09 and Z90 only apply for cold-rolled base metals.

Available Size

Product Name Base Type Thickness (mm) Width (mm)
Hot-dip Galvanized Steel Coil Cold-rolled Base 0.17~3.00 670~1650
Hot-rolled Base 1.20~4.60 670~1300

The table above shows the widest range of product dimensions. For a detailed

acceptable order range, please contact US.

Galvanized Coil / GI Coil Application

Galvanized steel is well suited for applications that need rust-resistant materials at a competitive price,

ultraviolet light protection and easy integration with other materials. Industries that use hot-dipped

galvanized steel products include:

Automotive
Pipe and Tubular
Outdoor Recreation
Agriculture
Construction

A653M Z60 Resin Coated Galvanized Steel Coil Hot Dip Galvanized Preservative

A653M Z60 Resin Coated Galvanized Steel Coil Hot Dip Galvanized PreservativeA653M Z60 Resin Coated Galvanized Steel Coil Hot Dip Galvanized Preservative

A653M Z60 Resin Coated Galvanized Steel Coil Hot Dip Galvanized Preservative

FAQ

Q: Would you provide samples For free?

A: Yes . with on stock specification We provide samples For Free . Freight charge collect

Q: What information should i provide to source for the right products ?

A: Material grade, width, thickness, coating and Purchase quantity , Expected lead time ,etc

Q: What are the shipping ports?

A: Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports, you can choose other ports according to your needs.

Q: About product prices?

A: Prices vary from period to period due to cyclical changes in the price of raw materials.

Q: How long does your delivery time take?

A: In general, our delivery time is within 5-45 days, and may be delayed if the demand is extremely large or special circumstances occur.

Q: Can I visit your location?

A: Of course, we welcome customers from all over the world to visit our factory. However, some of the plants are not open to the public.

Q: Does the product have quality inspection before loading?

A: Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.

Q: How to pack the products?

A: The inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation wooden pallet. It can effectively protect products from corrosion during ocean transportation.

Q: What is your working time?

A: In general, our online service time is Beijing time: 8:00-22:00, after 22:00, we will reply to your inquiry during the next working day.
