China Factory Supply 8.8 Inch Bar Type TFT Display 480x1920 Pixel MIPI Interface
China Factory Supply 8.8 Inch Bar Type TFT Display 480x1920 Pixel MIPI Interface
China Factory Supply 8.8 Inch Bar Type TFT Display 480x1920 Pixel MIPI Interface
China Factory Supply 8.8 Inch Bar Type TFT Display 480x1920 Pixel MIPI Interface
China Factory Supply 8.8 Inch Bar Type TFT Display 480x1920 Pixel MIPI Interface
China Factory Supply 8.8 Inch Bar Type TFT Display 480x1920 Pixel MIPI Interface
Specifications
Brand Name :
SAEF
Model Number :
SF-TO880XC-7106AN
Certification :
ISO9001 / ISO14000
Place of Origin :
ShenZhen / China
MOQ :
3 pcs
Price :
Negotiable based on order lot quantity
Payment Terms :
L/C, T/T, Western Union, Paypal
Supply Ability :
3000K pcs per month
Delivery Time :
1-5 weeks
Packaging Details :
Standard Exportation Package
Keywords :
Bar type TFT 8.8 inch
Resolution :
480x1920
Interface :
MIPI
Viewing Direction :
IPS all viewing angles
Touch screen :
No
Driving Voltage :
3.3 V
Contrast Ratio :
1000:1
Surface Luminance :
550 cd/m2 (nits)
Operating Temp. :
–20℃ to +70℃
Storage Temp :
–30℃ to +80℃
pins :
40 PINS
Connection :
Connector type
LED lifetime :
40,000 hours
Compliance :
REACH & RoHS Compliant
Description

8.8 Inch Bar Type TFT Display 480x1920 Pixel MIPI Interface Product Introduction

Product Quick Review

►Size : 8.8 inch
►Resolution : 480x1920 dots
►View Direction : IPS
►MIPI Interface
►Driver IC : OTA7290B
►Control-Board : No
►Brightness(cd/m²): 550
►Touch Panel : Without Touch Panel, CTP optional

Description

With its ultra-wide aspect ratio of nearly 4:1, this bar-type display excels in narrow spaces. Use this display as an information panel on an appliance or dashboard. This display can show wide graphics that get squished on other displays or can be broken into sections to take the place of multiple other displays.
The active area of the display is 8.88" on the diagonal. It has an MIPI interface, and a white LED backlight with 550 nits surface brightness.

SAEF Bar Type TFT-LCD displays are perfect for industrial equipment, automotive application, server system, POS system, home automation, household application and dynamic information displays. We offer different sizes Bar Type TFT (Stretched Bar LCD Display) including sizes of

0.96 inch bar type TFT 80x160 pixels, 1.05 inch bar type TFT 120x240 pixels, 1.1 inch bar type TFT 126x294 pixels,

1.14 inch bar type TFT 135x240 pixels, 1.47 inch bar type TFT 172x320 pixels, 1.9 inch bar type TFT 170x320 pixels,

2.3 inch bar type TFT 100x310 pixels, 2.4 inch bar type TFT 220x480 pixels, 2.86 inch bar type TFT 376x960 pixels,

2.99 inch bar type TFT 268x800 pixels, 3 inch bar type TFT 268x800 pixels, 3.13 inch bar type TFT 276x960 pixels,

3.16 inch bar type TFT 288x960 pixels, 3.2 inch bar type TFT 320x820 pixels, 3.38 inch bar type TFT 180x460 pixels,

3.4 inch bar type TFT 180x640 pixels, 3.4 inch bar type TFT 412x960 pixels, 3.49 inch bar type TFT 172x640 pixels,

3.5 inch bar type TFT 340x800 pixels, 3.71 inch bar type TFT 240x960 pixels, 3.8 inch bar type TFT 480x76 pixels,

3.9 inch bar type TFT 480x128 pixels, 3.99 inch bar type TFT 400x960 pixels, 4 inch bar type TFT 400x960 pixels,

4.5 inch bar type TFT 320x960 pixels, 4.58 inch bar type TFT 320x960 pixels, 4.6 inch bar type TFT 320x960 pixels,

6.1 inch bar type TFT 280x1424 pixels, 6.5 inch bar type TFT 1024x400 pixels, 6.5 inch bar type TFT 800x320 pixels,

6.86 inch bar type TFT 480x1280 pixels, 6.9 inch bar type TFT 280x1424 pixels, 7 inch bar type TFT 280x1424 pixels,

7.84 inch bar type TFT 400x1280 pixels, 7.85 inch bar type TFT 400x1280 pixels, 8.8 inch bar type TFT 480x1920 pixels,

9.3 inch bar type TFT 1920x480 pixels, 10.1 inch bar type TFT 1024x100 pixels, 10.1 inch bar type TFT 1280x480 pixels,

10.4 inch bar type TFT 1024x100 pixels, 10.88 inch bar type TFT 440x1920 pixels, 11.3 inch bar type TFT 440x1920 pixels,

12.3 inch bar type TFT 1920x720 pixels, 12.6 inch bar type TFT 1920x515 pixels, 14 inch bar type TFT 3840x1100 pixels (4K).

Product Information

Keywords: Bar Type TFT 8.8 Inch
Resolution: 480x1920
Interface: MIPI
Viewing Direction: IPS All Viewing Angles
Driving Voltage: 3.3 V
Surface Luminance: 550 Cd/m2 (nits)
Touch Screen: No
Contrast Ratio: 1000:01:00
Operating Temp.: –20℃ To +70℃
Storage Temp: –30℃ To +80℃
Connection: Connector Type
Pins: 40 PINS
LED Lifetime: 40,000 Hours
Compliance: REACH & RoHS Compliant

8.8 Inch Bar Type TFT Display 480x1920 Pixel MIPI Interface Product Drawing

China Factory Supply 8.8 Inch Bar Type TFT Display 480x1920 Pixel MIPI Interface

Pin Definition

NO. Pin Name Description
1 GND Ground
2 D0P DSI-D0+ data signals
3 D0N DSI-D0- data signals
4 GND Ground
5 D1P DSI-D1+ data signals
6 D1N DSI-D1- data signals
7 GND Ground
8 CLKP DSI-Clock+ signals
9 CLKN DSI-Clock- signals
10 GND Ground
11 D2P DSI-D2+ data signals
12 D2N DSI-D2- data signals
13 GND Ground
14 D3P DSI-D3+ data signals
15 D3N DSI-D3- data signals
16 GND Ground
17 GND Ground
18 IOVCC Power Supply 1.8V
19 IOVCC Power Supply 1.8V
20 REFCLK/NC reference clock/NC
21 SDA Data signal Dummy
22 SCL Clock signal Dummy
23 BIST Built-in Self Test
24 RSTB LCM reset signals
25 STBYB Standby mode control H:normal operation;L:disable display
26 AVDD/ NC NC
27 GND Ground
28 K LED Cathode
29 K LED Cathode
30 GND Ground
31 VGL/NC Gate OFF Voltage/NC
32 GND Ground
33 GND Ground
34 VGH/NC Gate ON Voltage/NC
35 LEDA LED anode
36 LEDA LED anode
37 TE Tearing effect output
38 VCI Power Supply 3.3V
39 VCI Power Supply 3.3V
40 VCOM/NC VCOM voltage/NC

Absolute Maximum Ratings

Item Symbol Value Unit
Power supply voltage for logic VCI -0.5~4 V
Input voltage Vin VVCI+0.3 V
Operating temperature Topr -20 to 70 °C
Storage temperature Tstg -30 to 80 °C

Optical Characteristics

Item Symbol Condition Min Typ Max Unit
View Angles θT CR≧10 75 80 - Degree
θB 75 80 -
θL 75 80 -
θR 75 80 -
Contrast Ratio CR θ=0° 800 1000 - -

Transmittance

(with Polarizer)

T (%)

 4.03 4.53
Response Time TON 25℃ - 30 40 ms
TOFF
Uniformity U - 70 80 - %
NTSC - - - 70 - %
Luminance L 550 - cd/m2

8.8 Inch Bar Type TFT Display 480x1920 Pixel MIPI Interface Product Image

China Factory Supply 8.8 Inch Bar Type TFT Display 480x1920 Pixel MIPI Interface

China Factory Supply 8.8 Inch Bar Type TFT Display 480x1920 Pixel MIPI Interface

Search keyword: tft 8.8", 8.8 tft lcd, 8.8" tft lcd, 8.8 inch tft lcd, tft lcd 8.8, 8.8 tft display, 8.8" tft display, 8.8 inch tft display, tft display 8.8 inch, tft display 8.8", 8.8 inch tft lcd display, bar type TFT 8.8 inch, bar type TFT 8.8", 8.8 inch bar type TFT, 8.8" bar type display. stretched bar type TFT 8.8", 8.8 inch stretched bar type TFT, 8.8" stretch bar type display.
