Specifications
Brand Name :
SF
Model Number :
N185T-3568
Place of Origin :
China
Certification :
3C,FCC,CE,ROHS etc.
MOQ :
2
Price :
Negotiable based on order quantity
Packaging Details :
Packaged Securely for Standard Exportation
Delivery Time :
1-5 weeks
Payment Terms :
100% pay in advance
Supply Ability :
10K pcs per month
Screen Size :
18.5 Inches
Display area :
409×229mm
Camera :
No
Processor :
Quad-core Rockchip RK3566
Surface Luminance :
300 Cd/m2 (nits)
POE :
Optional
Bluetooth :
BT 5.2
Working temp :
0-50degree
RAM :
2GB
Internal memory :
16GB
Operation system :
Android 11/13 OS
Touch screen :
10-Point capacitive touch
Interface :
TF,USB 2.0,USB 3.0,RJ45,Earphone,HDMI out,Power
Software :
Free installation applications
Description

18.5 Inch Android Touch Screen Monitor KR3568 IPS Display No Camera Vesa Wall Mounted With POE RJ45 Port Product Introduction

Exceptional Display
High - Def Panel: 18.5" full - view screen, crafted for immersive visuals in every scenario.
Sharp Resolution: 1920x1080, delivering crystal - clear images for work, play, and digital signage.
Ultra - Wide IPS Viewing: 85/85/85/85 (L/R/U/D) angle, ensuring consistent clarity from any position.
Ideal Brightness: 300 cd/m², adaptable to various lighting setups.
High Contrast: 1000:1 ratio for vivid colors and deep blacks.
Optimal Scale: 16:9 format with a 409×229mm display area for seamless multitasking.
Robust System
Powerful CPU: Rockchip RK3566 Quad Core 64 - bit Cortex - A55, ensuring smooth operation under any load.
Flexible RAM: 2GB (4GB optional) for quick data handling and multitasking.
Ample Storage: 16GB (32GB optional) of internal memory, expandable to fit your needs.
Latest OS: Runs on Android 11/13, offering a user - friendly interface and app compatibility.
Versatile Connectivity
Wireless WIFI: 802.11b/g/n for stable wireless internet access.
Wired Ethernet: 100M (1000M optional) for high - speed, reliable connections.
Bluetooth 5.2: Effortless pairing with external devices.
Optional 4G/5G: Stay connected on - the - go.
Rich Interfaces
TF Slots: For easy storage expansion.
USB 2.0 & 3.0: Connect U disks, mice, keyboards, and more.
RJ45 w/POE Option: Stable network with power - over - ethernet flexibility.
3.5mm Headphone Jack: Private audio enjoyment.
HDMI Out: Connect to larger displays.
DC 5.5x2.1 Power Input: Reliable power supply.
Multimedia - Ready
Video Support: MPEG - 1, MPEG - 2, MPEG - 4, H.263, H.264, RV (up to 1080P).
Audio Compatibility: MP3, WMA, AAC, etc., with 2×3W speakers.
Image Compatibility: JPEG, JPG for high - quality photo viewing.
Other Features
Operating Range: 0 - 50°C, suitable for diverse environments.
Multilingual OSD: Catering to a global user base.
Certified Quality: 3C, FCC, CE, ROHS compliant.
Package Contents
Power Adapter: 12V/3A for stable power.
User Manual: For easy setup and operation.
The 18.5" Android Touch Screen Monitor KR3566 is your go - to choice for a high - performance, versatile display solution.

Product Information
Display Panel 18.5" high-definition full view screen
Resolution 1920x1080
Viewing angle IPS Screen 85/85/85/85(L/R/U/D)
Brightness 300 cd/m2
Contrast 1000:1
Screen scale/Display area 16:9/ Display area : 409×229mm
System CPU Rockchip RK3566 Quad Core 64 bit Cortex-A55
RAM 2GB (4GB optional)
Internal memory 16GB (32GB optional)
Operation system Android 11/13 OS
Touch screen No 10-Point capacitive touch
Network WIFI 802.11b/g/n
Ethernet 100M ethernet (1000M optional)
Bluetooth BT 5.2
4G/5G Cellular network Optional
Interface TF TF card slots
USB 2.0 1×USB 2.0 interface (support U disk, mouse, keyboard, printer etc)
USB 3.0 1×USB 3.0 interface (support U disk, mouse, keyboard, printer etc)
RJ45 Ethernet interface (POE function Optional)
Earphone 1×3.5mm headphone Interface
HDMI out 1xHDMI out
Power DC power input (5.5x2.1)
Multi-Media Video Support MPEG-1, MPEG-2, MPEG-4, H.263, H.264, RV, etc. (max support 1080P)
Audio Support MP3, WMA, AAC and so on
Picture JPEG,JPG
Other parameters Microphone No
Speaker 2×3W speakers
Camera No
Working temp 0-50degree
OSD language Multi-language
Certificates 3C,FCC,CE,ROHS etc.
Attachment Adapter yes, specifications: 12V/3A
User's Manual yes
Desktop Bracket No
Product Size
Body Size Color Box 5pcs/Carton
Length Width Thickness Length Width Height Length Width Height
447 267 41 502 429 87 515 450 445
N.W 2.76KG N.W 3.46KG N.W 17.3KG
G.W 18.3KG
Unit: mm

18.5 Inch Android Touch Screen Monitor KR3568 IPS Display No Camera Vesa Wall Mounted With POE RJ45 Port18.5 Inch Android Touch Screen Monitor KR3568 IPS Display No Camera Vesa Wall Mounted With POE RJ45 Port18.5 Inch Android Touch Screen Monitor KR3568 IPS Display No Camera Vesa Wall Mounted With POE RJ45 Port18.5 Inch Android Touch Screen Monitor KR3568 IPS Display No Camera Vesa Wall Mounted With POE RJ45 Port18.5 Inch Android Touch Screen Monitor KR3568 IPS Display No Camera Vesa Wall Mounted With POE RJ45 Port18.5 Inch Android Touch Screen Monitor KR3568 IPS Display No Camera Vesa Wall Mounted With POE RJ45 Port


18.5 Inch Android Touch Screen Monitor KR3568 IPS Display No Camera Vesa Wall Mounted With POE RJ45 Port
