3.0 Megapixel WDR Vandal-Proof IR Network Dome Camera
3.0 Megapixel WDR Vandal-Proof IR Network Dome Camera
Specifications
Item :
3.0 Megapixel WDR Vandal-Proof IR Network Dome Camera
Skype :
david.zksv
E-mail :
sales@safe-cctv.com
Model Number :
SA-DG5300WP
Description

3.0 Megapixel WDR Vandal-Proof IR Network Dome Camera

Features:

>1/3" 3.0 Megapixel Progressive Scan Aptina WDR CMOS sensor
> Ti DaVinci Series DSP
> H.264 & MJPEG dual-stream encoding
> Max 20fps @ 3.0MP (20480×1536)
> Dual encoding streams supported
> 2.8~12mm /F1.4 Manual lens
> Built-in 1/1 alarm in/out
> 30pcs Φ5 IR lights ,Max IR Distance :20m
> True WDR 120dB
> True Day/Night ICR
> Micro SD memory, IK10, PoE
> Built-in Web server, NVR, CMS
> IP66 all-environments protection

Model SA-DG5300WP
General
Main Processor Ti DaVinci Series DSP
Operating System Embedded LINUX
Resource Simultaneous remote monitoring, local recording and remote control
User Interface WEB, CMS, NVR
Camera
Image Sensor 1/3" 3.0Megapixel Progressive Scan Aptina WDR CMOS Sensor
Effective Pixels 2048(H)×1536(V)
Electronic Shutter 1/5s to 1/50,000s
Mini. Illumination Color:0.2Lux/F1.2; B/W:0.01Lux/F1.2; 0Lux/F1.2(IR on)
Signal Noise Ratio >50dB
Day/Night Mode Auto, dual IR-Cut filter
Gain Control Auto/Manual
White Balance Auto/Manual
WDR Dynamic Range WDR (120dB)
Lens 2.8mm~12mm/F1.4Manual lens
Max IR Distance 20m, 30pcs Φ5 IR lights
Video
Video Compression H.264/MJPEG Optional
H.264 Encode Type H.264 Baseline/H.264 Main Profile/H.264 High Profile Optional
Video Bit Rate Main Stream: 200Kbps~12Mbps
Sub Stream: 100Kbps~6Mbps
Image Resolution 3.0Mp(2048 × 1536 ) /1080P(1920×1020) / 720P(1280×720) / D1(704×576/704×480)
Encoding Speed Main Stream: 3.0Mp /20 fps; 1080P/720P(1~25fps/30fps)
Extra Stream: D1/CIF(1~25fps/30fps)
Video Format PAL/NTSC
Audio
Audio Compression G.711a/G.711u/RAW_PCM Optional
Audio Bit Rate G.711a(8kbps)/G.711u(8kbps)/
Audio Input 1-channel 3.5mm audio interface MIC IN/Line IN
Audio Output 1-channel 3.5mm audio interface (line level,600Ω)
Network
Ethernet RJ-45 (10/100Base-T)
Network Protocol Ipv4/Ipv6, RTSP, TCP/UDP, HTTP, DHCP, DNS, FTP, DDNS, PPPoE, SMTP
Common Features One button Reset, Prevent Flicker, Dual-stream, Heartbeat, Password Protect, Video cover, Motion Alarm
ONVIF ONVIF Ver.2.4
Max User Access 10 users
Smart phone Iphone , Ipad ,Android,
Remote Operation Monitor, System setting, , Log information, Maintenance & Upgrade
Auxiliary Interface
Reset Input One Reset Button(Hold on 3 seconds at least)
RS485 PTZ Control
Memory Slot Micro SD Card, Max 64GB
Alarm Input 1-channel input, Normally Open/Normally Close modes adjustable
Alarm Output 1-channel output,, 120VAC 1A/24VDC 1A
Video Output 1Vp-p Composite Output(75Ω/BNC)
Environmental
Power Supply DC12V
Power Consumption <10W
Working Environment -40ºC ~ +60ºC, Humidity less than95%(Non-condensing)
Dimensions(mm) 148mm×148mm×121.5mm
Weight(kg) 0.77Kg
PoE IEEE802.3af
Protection Level IP66 only with External metal bracket
