General Purpose 4007Ω 0603 Chip Resistor Thick Film ± 5% Resistance Tolerance
General Purpose 4007Ω 0603 Chip Resistor Thick Film ± 5% Resistance Tolerance
General Purpose 4007Ω 0603 Chip Resistor Thick Film ± 5% Resistance Tolerance
General Purpose 4007Ω 0603 Chip Resistor Thick Film ± 5% Resistance Tolerance
Specifications
Brand Name :
YAGEO
Model Number :
RC0603FR-074K7L
Certification :
RoHS
Place of Origin :
China
MOQ :
5000 pcs
Payment Terms :
T/T
Supply Ability :
5000k pieces per Month
Delivery Time :
10-15work days
Packaging Details :
Paper tape reel 5000 pcs
Type :
Chip Resistor
Resistance :
4007Ω
Length :
1.6 ±0.10 mm
Resistance Range(uF) :
1Ω-22MΩ
Resistance tolerance :
±5%
Coating meature :
0603(1608M)
Feature :
Extremely thin and light
Application :
filter decoupling bypass
Wide :
0.8 ±0.1 mm
Material :
Ceramic substrate and jumpe chip
Description


Thick Film General Purpose Chip Resistors 0603 4007Ω

Features
• Extremely thin and light
• Highly reliable multilayer electrode construction
• Compatible with all soldering process
• Highly stable in auto-placement surface mounting applications
• Barrier layer end termination
• Zero ohm jumper is available
• Available in 8mm tape & reel per EIA RS481

General Purpose 4007Ω 0603 Chip Resistor Thick Film ± 5% Resistance Tolerance

Electrical characteristics

Type

Power P70

Operating Temp. range

MWV

RCOV

DWV

Resistance range & tolerance

T. C. R. ( ppm/°C)

Jumper criteria (unit: A)

RC0100

1/32W

-55°C to +125°C

15V

30V

30V

E24 ±1%, 5%
Zero ohm jumper

10Ω≤R≤1MΩ
<50mΩ

10Ω≤R≤1MΩ

±250

Rated current Max. current

0.5
1.0


RC0201


1/20W


-55°C to +125°C


25V


50V


50V

E24 ±5%
E24/E96 ±1%
E24/E96 ±0.5%
Zero ohm jumper

1Ω≤R≤10MΩ
1Ω≤R≤1MΩ
10Ω≤R≤1MΩ
<50mΩ


10Ω<R≤10MΩ
1Ω≤R≤10Ω


±200
-100/+350


Rated current Max. current


0.5
1.0

RC0402

1/16W

-55°C to +155°C

50V

100V

100V

E24 ±5%
E24/E96 ±1%
E24/E96 ±0.5%
Zero ohm jumper

1Ω≤R≤22MΩ
1Ω≤R≤10MΩ
10Ω≤R≤1MΩ
<50mΩ

10Ω<R≤10MΩ
1Ω≤R≤10Ω
10MΩ<R≤22MΩ


±100
±200

Rated current Max. current

1.0
2.0

RC0603

1/10W

-55°C to +155°C

50V

100V

100V



RC0805

1/8W

-55°C to +155°C

150V

300V

300V

Rated current Max. current

2.0
5.0


1/4W


-55°C to +155°C


150V


300V


300V

E24 ±5%
E24/E96 ±1%
Zero ohm jumper

1Ω≤R≤1MΩ
1Ω≤R≤1MΩ
<50mΩ


1Ω≤R≤1MΩ


±200

Rated current Max. current

2.0
5.0




RC1206


1/4W


-55°C to +155°C


200V


400V


500V

E24 ±5%
E24/E96 ±1%
E24/E96 ±0.5%
Zero ohm jumper

10Ω≤R≤22MΩ
1Ω≤R≤10MΩ
10Ω≤R≤1MΩ
<50mΩ

10Ω<R≤10MΩ
1Ω≤R≤10Ω
10MΩ<R≤22MΩ


±100
±200


Rated current Max. current


2.0
10.0


1/2W


-55°C to +155°C


200V


400V


500V

E24 ±5%
E24/E96 ±1%
Zero ohm jumper

1Ω≤R≤1MΩ
1Ω≤R≤1MΩ
<50mΩ


1Ω≤R≤1MΩ


±200

Rated current Max. current

3.0
7.5


RC1210


1/2W


-55°C to +155°C


200V


500V


500V

E24 ±5%
E24/E96 ±1%
E24/E96 ±0.5%
Zero ohm jumper

1Ω≤R≤22MΩ
1Ω≤R≤10MΩ
10Ω≤R≤1MΩ
<50mΩ






10Ω<R≤10MΩ
1Ω≤R≤10Ω
10MΩ<R≤22MΩ






±100
±200


Rated current Max. current


2.0
10.0


RC1218


1W


-55°C to +155°C


200V


500V


500V

E24 ±5%
E24/E96 ±1%
E24/E96 ±0.5%
Zero ohm jumper

1Ω≤R≤1MΩ
1Ω≤R≤1MΩ
10Ω≤R≤1MΩ
<20mΩ


Rated current Max. current


6.0
10.0

RC2010

3/4W

-55°C to +155°C

200V

500V

500V

E24 ±5%
E24/E96 ±1%
E24/E96 ±0.5%
Zero ohm jumper

1Ω≤R≤22MΩ
1Ω≤R≤10MΩ
10Ω≤R≤1MΩ
<50mΩ

Rated current Max. current

2.0
10.0



RC2512

1W

-55°C to +155°C

200V

500V

500V

Rated current Max. current

2.0
10.0


2W


-55°C to +155°C


200V


400V


500V

E24 ±5%
E24/E96 ±1%
Zero ohm jumper

1Ω≤R≤150Ω
1Ω≤R≤150Ω
<50mΩ


1Ω≤R≤150Ω


±200

Rated current Max. current

6.0
15.0




General Purpose 4007Ω 0603 Chip Resistor Thick Film ± 5% Resistance Tolerance
