6.38mm - 40.3mm CE and ISO9001 Curtain Wall Tempered Laminated Glass For Home
6.38mm - 40.3mm CE and ISO9001 Curtain Wall Tempered Laminated Glass For Home
6.38mm - 40.3mm CE and ISO9001 Curtain Wall Tempered Laminated Glass For Home
6.38mm - 40.3mm CE and ISO9001 Curtain Wall Tempered Laminated Glass For Home
Specifications
Brand Name :
Crystal Base
Model Number :
TSG
Certification :
CE/CSI/BS/ASTM
Place of Origin :
China
MOQ :
100sqm
Price :
negotiation
Payment Terms :
T/T ,L/C,DP or western Union
Supply Ability :
3,000 Sqm per Day
Delivery Time :
15 days after order confirmed
Packaging Details :
Packed in Strong Plywood Crates or Cases with PE,paper or Saftpad interlayer
Product Name :
Tempered Safety Glass
Application :
home appliance glass panels
Size Of Panel :
Various
Colours :
Clear, Blue
Standard :
CE/CSI/BS/ASTM
Type :
Flat or Curved Sheet Glass
Thickness :
6.38mm - 40.3mm
Transmittance :
more than 88%
Description

CE ／ ISO9001 Curtain Wall Tempered Laminated Glass Panels Curved for building

  • wo layers or more of glass "sandwiched" together with a PVB interlayer, laminated glass is the one glass that reconciles the aesthetic benefits of glass with a genuine concern for safety; offering superior protection against glass breakage, as well as harmful solar rays and hazardous noise levels.
  • Due to the adhesive properties of the PVB, Rider takes careful precautions to prevent unwanted particles from attaching to the PVB during the adhesion process.
  • Tempered Laminated Glass has double safety assurance, one is by glass laminating, the other one is on behalf of glass tempering.

Laminated Glass Assembly According to Safety Requirement

REQUIREMENT BENEFIT

GLASS ASSEMBLY
Solar control Energy saving 2ply+1PVB interlayer
UV elimination
Sound control Noise reduction 2ply+1PVB interlayer
Safety Lowest injury risk 2ply+2PVB interlayers
Anti-bandit protection 2ply+4-6PVB interlayers
Security Forced entry protection 3ply+4PVB interlayers
Bullet proof Decide case by case, at least
Blast resistant 4ply+multi PVB interlayers

BENEFITS

  • Holds together when shattered. The PVB interlayer keeps the glass bonded, even when broken, resulting in a characteristic spider web cracking pattern across the glass.
  • Cyclone resistant
  • Superior UV blockage
  • Excellent sound damping properties
  • Low visible distortion

Tempered glass production process

1. Cutting : cutting the annealing glass to the actual needs of shape.

2. Glass edging: Edging machine to mill the four edges to prevent frund when steeling,while

maintaining the beautiful appearance.

3. Drilling hole:If need to drilling hole using drilling machine.

4. Washing dry:cleaning the glass with washing maching.

5. Tempered glass:Tempered glass is produced by heating annealed glass in a furnace to 700°,

then the glass is rapidly cooled with jets of cold air to 40°,through the procedures, the original

glass is formed of tempered glass.
