Specifications
Brand Name :
XPM
Model Number :
20-50MM
Certification :
CE,ISO
Place of Origin :
ZHANGJIAGANG,CHINA
MOQ :
1 SET
Price :
20,000-25,000 USD/SET
Payment Terms :
L/C, T/T
Supply Ability :
20 SETS PER MONTH
Delivery Time :
45 WORKING DAYS
Packaging Details :
WOODEN CASE PACKING AND PLASTIC FILM
Contactor Brand :
Siemens
Raw Material :
PVC
Color :
Customized
Screw :
Conical Twin Screw
Warranty :
1 Year
Inverter :
ABB
Voltage :
220V,380V Or Customized
Application :
Plastic Pipe
Output :
250Kg/H
Motor Power :
37Kw
Description

TWO STRANDS DIAMETER 16-63MM PVC TUBES MAKING MACHINE LINE

Multi 2 Strands PVC Pipe Extrusion Line 37KW Pvc Tube Making Machine High Wear Resistant


Main Technical Features
1. It is mainly used to produce all kinds of UPVC pipes for agricultural water supply and drainage, building water supply and drainage and cable laying, etc.
2. Saw cutter and planetary cutter for choice
3. Changing some parts can also produce M-PVC pipe, C-PVC pipe, inner spiral wall pipe, inner hollow wall pipe, formed core pipe.
4. Conical twin screw extruder and parallel twin screw extruder for choice
5. Double-strand and four-strand for choice for small pipes

Application of pvc pipe:
pvc pipe mainly use in agricultural and construction water supply-drainage.cpvc pipe due to its special character, widely use in base oil transportation,temperature and corrosion resistance pipe of chemical,hot water supply-drainage pipe and protection pipe of high voltage electricity and electrical cables.

Multi 2 Strands PVC Pipe Extrusion Line 37KW Pvc Tube Making Machine High Wear Resistant


Specification

Model:SJ45 Ordinary pipe extruding line
Item Unit Parts Number Description
1 SJ45 Extruder screw & barrel 1 set Φ45 mm, L/D=25:1, 38CrMoAIA,
nitriding, screw: Cr plated
gear box 1 set gear hardening, polished, horizontal
machine frame 1 set Steel structure
main motor 1 set 11 kw frequency varying
control panel 1 set 5 zone temperature control, 4 air cooling
2 Vacuum Sizing Table 1 set length: 2.5 meters
surface material: stainless steel
3-dimension manual adjustable
vacuum pump: 2.2 kw
3 Drawing Unit 1 set 1.5 kw frequency varying
4 Cutting Unit 1 set 1.5 kw frequency varying
effective length: 3 m
automatic discharge rack

Multi 2 Strands PVC Pipe Extrusion Line 37KW Pvc Tube Making Machine High Wear Resistant

Multi 2 Strands PVC Pipe Extrusion Line 37KW Pvc Tube Making Machine High Wear Resistant

SPECIFICATIONS:

MODEL PIPE DIAMETER (MM) EXTRUDER MODEL MOTOR POWER (KW)
XPM-32F 16-32 (FOUR PIPE) SJSZ65/132 37 AC
XPM-32E 16-32 (DOUBLE PIPE) SJSZ51/105 22 AC
XPM-32W 16-32 (DOUBLE PIPE) SJSZ65/132 37 AC
XPM-40E 16-40 (DOUBLE PIPE) SJSZ51/105 22 AC
XPM-40W 16-40 (DOUBLE PIPE) SJSZ65/132 37 AC
XPM-50E 16-50 (DOUBLE PIPE) SJSZ51/105 22 AC
XPM-50W 16-50 (DOUBLE PIPE) SJSZ65/132 37 AC
XPM-63W 16-63 (DOUBLE PIPE) SJSZ65/132 37 AC

Multi 2 Strands PVC Pipe Extrusion Line 37KW Pvc Tube Making Machine High Wear Resistant
