Auto Weighing Filling And Sealing Machine For Heavy Bag 12KW SEW Motor

Application Scope

Auto Weighing Filling And Sealing Machine is distinguished by its outstanding speed and reliability as well as its high flexibility to work with all kinds of bag types and materials. Due to its technical maturity and several patented modules, the bagging system has become one of the most reliable packaging machines in the world. The bagging machine has been therefore installed in many different industries for packaging products like plastic pellets, animal feed, corn, seed, beans, lentils, sugar, rice, and so on.

Auto Weighing Filling And Sealing Machine Brief Introduction

Our new packaging machine unit designed for large bag of granule, powder materials in chemicals, fertilizer, feed, grain, seeds, food, rubber & plastic and other industries which has functions of automatic weighing, bag clipping, filling, bag sending, bag sealing etc. It can be connected with next steps equipment like palletizing robot etc. to realize large-scale package and unmanned operation of the stacking.

Auto Weighing Filling And Sealing Machine Each Parts Introduction

1. Weighing Machine: The part in contact with the material is made of 304 SS, other parts use carbon steel which sprayed with plastic. Metering speed: weighing controller and sensor, reserved for dust removal interface.
2. Empty bag storage: The part in contact with the material is made of 304 SS, other parts use carbon steel which sprayed with plastic. Electric power, reducer motor system.
3. Bag upper unit and Bag holding & guide unit: Delta servo drive system
4. Whole control cabinet: Self-developed patent system, widely used in automatic packaging machines, and gained a good reputation. Germany Siemens PLC control system and software system, France Schneider Electric and other high-end configurations. Germany Sick photoelectric control system, wire and cable and bridge wiring.
5. Bag sewing machine / Heat sealing machine: suitable for open mouth bag of woven bag, plastic bag, paper bag etc.
6. Stand-up bag conveyor: Made of carbon steel + PVC belt + stainless steel baffle guardrail, reducer motor system, Germany Sick photoelectric control system, etc.
7. Platform, guardrail, ladder: Carbon steel spray

Auto Weighing Filling And Sealing Machine Technical Parameters

Auto Weighing Filling And Sealing Machine main parts list (subject to actual configuration)

Machine Features

1. Double working station bag giving system. 100-300 bags can be stored.

2. There is an air pressure detecting device in the process of picking up the bag, opening the bag, clamping the bag, and filling the bag. Unqualified bags will be kicked out automatically without stopping the working. bagging system.

3. High speed weighing scale. automatic bagging machine, Automatic rice packing machine

4. Bag-clamping movement and discharge gate are using two independents
systems which make the bag clamping more stable

5. Using the big finger cylinder can make sure the bag mouth to be smooth.

6. It adopts a plastic chain plate conveyor belt, gear meshing transmission, which is not easy to slip and deflect; the conveyor belt and the upper guide bag mechanism adopt mechanical linkage to ensure the synchronization of the conveying process.

7. All the major motoring is using servo motors.

Working Process

Automatic bag seizing

Automatic bag opening

Automatic bag feeding & material auto filling

Bag automatic transferred by the conveyor

Auto bag sewing / heat sealing (folded)

Finished bag
