2.2KW Screw Dehydrator , Screw Filter Press For Food Waste Water Treatment
2.2KW Screw Dehydrator , Screw Filter Press For Food Waste Water Treatment
2.2KW Screw Dehydrator , Screw Filter Press For Food Waste Water Treatment
2.2KW Screw Dehydrator , Screw Filter Press For Food Waste Water Treatment
2.2KW Screw Dehydrator , Screw Filter Press For Food Waste Water Treatment
2.2KW Screw Dehydrator , Screw Filter Press For Food Waste Water Treatment
Specifications
Brand Name :
HST
Certification :
ISO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200sets/per year
Delivery Time :
10 working days
Packaging Details :
wooden package
Applicable Industries: :
Hotels, Garment Shops, Building Material Shops, Manufac
Weight :
5000KG
Power: :
2.2KW
Product name :
multi-disk press machine
Control mode :
automatic control box
Size: :
3*2*3M
Description

Screw filter press system sludge dehydrator machine sewage treatment equipment

Main Parts:
Sludge concentration & dewatering Body; Flocculation & Conditioning Tank; Integrate Automatic Control Cabinet; Filtrate Collection
Tank
Working Principle:
1. Concentration : When the screw drive shaft rotation, live in multiple solid drive shaft periphery laminated relative
movement,under the force of gravity,Water from the relative motion of laminated filter out in the clearance,Achieve rapid
concentrate. 2. Dehydration : After concentrate of sludge as the rotation of the screw axis moves forward constantly ,Follow the
direction of the mud cake export , Screw axis of pitch became smaller , The gap between ring and ring also gradually become
smaller , Spiral cavity volume shrinking ,Screw drive shaft Pushed by continuous operation in turn ,The water squeezed out of the
sludge ,Filter cake solid content increase ,Finally realizes the continuous dehydration of sludge .3. self-cleaning : Screw axis
rotation ,It pushes the float ring continuous rotation ,Equipment rely on the fixing ring and float ring to move between
consecutive since the cleaning process ,Skillfully avoided Traditional dewatering machine common plugging problem .Our company are
always focusing on independent technology innovation of themselves. Under the cooperation with Tongji University, we have
successfully developed the new generation of sludge dewatering technology - multi-plate screw press, a screw type sludge
dehydrator that is much more advanced in very aspects than belt presses, centrifues, plate-and-frame filter presses, etc. It
features clogging-free, wide range of applications, low energy consumption, simple operation& maintenance.
Working process:
2.2KW Screw Dehydrator , Screw Filter Press For Food Waste Water Treatment
Detailed Images:
2.2KW Screw Dehydrator , Screw Filter Press For Food Waste Water Treatment
2.2KW Screw Dehydrator , Screw Filter Press For Food Waste Water Treatment
2.2KW Screw Dehydrator , Screw Filter Press For Food Waste Water Treatment

Model list

model NO
screw axis dia
sludge cake outlet distance form ground(mm)
machine size(L*W*H)
SMDL131
130*1
250
1969*756*1040
SMDL132
130*2
250
2069*910*1040
SMDL201
200*1
350
2400*800*1270
SMDL202
200*2
350
2500*935*1270
SMDL301
300*1
495
3255*985*1600
SMDL302
300*2
495
3455*1295*1600
