Smooth Running Material Screening Equipment 308.3*190.7*148.4cm Dimension Low Noise
Smooth Running Material Screening Equipment 308.3*190.7*148.4cm Dimension Low Noise
Smooth Running Material Screening Equipment 308.3*190.7*148.4cm Dimension Low Noise
Smooth Running Material Screening Equipment 308.3*190.7*148.4cm Dimension Low Noise
Specifications
Place of Origin :
Henan, China
Brand Name :
MZZG
MOQ :
1 set
Price :
Negotiation
Packaging Details :
Depond on product
Delivery Time :
35 work days
Payment Terms :
L/C, T/T
Supply Ability :
10 set 15 set per month
Model Number :
TS1530
Product name :
Smooth Running Material Screening Equipment 308.3*190.7*148.4cm Dimension Low Noise
Type :
Linear
Dimension(L*W*H) :
308.3*190.7*148.4cm
Capacity :
80-100TPH
Motor :
2 Vibrating Motors
Noise :
smooth
Selling Units :
Single item
After-sales Service Provided :
Online support, Free Spare Parts
Description

Smooth Running Material Screening Equipment 308.3*190.7*148.4cm Dimension Low Noise

Working principle
Sand dewatering screen adopts dual-motor self-synchronization technology. The motors coordinate with universal eccentric and adjustable amplitude vibrator. When the two motors start to work, the vibrators move reversely at the same time. The centrifugal force is generated by the eccentric blocks superpose themselves and form a single direction vibration. The high frequency vibration drives the screen move back and forth in line repeatedly. So the sand will be dehydrated and filtered.

Smooth Running Material Screening Equipment 308.3*190.7*148.4cm Dimension Low Noise

Product details

Model TS1530
Capacity 80-100TPH
Mesh size 100 mesh
Screen Mesh PU
Surface treatment self cleaning
Usage ore material dewater
Color Blue
Motor 2 Vibrating Motors
Layer(s) 1-2 Layers
Noise smooth
Product Keywords Wet silica sand dewatering sieve machine customized color from sand wash plant

Smooth Running Material Screening Equipment 308.3*190.7*148.4cm Dimension Low Noise

Application
TS dewatering screen is mainly used in mining, construction for coarse or fine sand dehydrate processing. With the advantages of simple structure and easy maintenance, it becomes a hot sell in our market.

Tech specification

Model

Power

(Kw)

 Capacity(t/h)

Feed size

(mm)

Screen size

W*L

(mm)

Screen area

(m²)

Screen

Material

Weight

(kg)

Dimension

L*W*H

(mm)
TS0918 0.75*2 10-30 ≤10 900*1800 1.6 PU 535 1885*1307*1133
TS1224 2.2*2 40-60 ≤10 1200*2400 2.88 PU 1080 2515*1607*1399
TS1530 3*2 80-100 ≤10 1500*3000 4.5 PU 1550 3083*1907*1484
TS1840 4*2 100-140 ≤10 1800*4000 7.2 PU 3100 4116*2381*1900
TS1842 4*2 100-150 ≤10 1800*4200 7.56 PU 3200 4316*2381*1976
TS1845 4*2 100-180 ≤10 1800*4500 8.1 PU 3400 4900*2380*2050

Structure

Smooth Running Material Screening Equipment 308.3*190.7*148.4cm Dimension Low Noise
