Talings Aggregate Screening Equipment Customized Voltage Low Maintenance
Talings Aggregate Screening Equipment Customized Voltage Low Maintenance
Talings Aggregate Screening Equipment Customized Voltage Low Maintenance
Talings Aggregate Screening Equipment Customized Voltage Low Maintenance
Specifications
Place of Origin :
Henan, China
Brand Name :
MZZG
MOQ :
1 set
Price :
Negotiation
Packaging Details :
Depond on product
Delivery Time :
35 work days
Payment Terms :
L/C, T/T
Supply Ability :
10 set 15 set per month
Model Number :
TS1530
Layer(s) :
1 Layer
Type :
Linear
Voltage :
Customized
Application :
Ore
Screen Mesh :
PU
Motor :
2 Vibrating Motors
Noise :
Smooth
After-sales Service Provided :
Free Spare Parts, Online support
Description

Talings Aggregate Screening Equipment Customized Voltage Low Maintenance

Application

TS dewatering screen is mainly used in mining, construction for coarse or fine sand dehydrate processing. With the advantages of simple structure and easy maintenance, it becomes a hot sell in our market.

Tech specification

Model

Power

(Kw)

 Capacity(t/h)

Feed size

(mm)

Screen size

W*L

(mm)

Screen area

(m²)

Screen

Material

Weight

(kg)

Dimension

L*W*H

(mm)
TS0918 0.75*2 10-30 ≤10 900*1800 1.6 PU 535 1885*1307*1133
TS1224 2.2*2 40-60 ≤10 1200*2400 2.88 PU 1080 2515*1607*1399
TS1530 3*2 80-100 ≤10 1500*3000 4.5 PU 1550 3083*1907*1484
TS1840 4*2 100-140 ≤10 1800*4000 7.2 PU 3100 4116*2381*1900
TS1842 4*2 100-150 ≤10 1800*4200 7.56 PU 3200 4316*2381*1976
TS1845 4*2 100-180 ≤10 1800*4500 8.1 PU 3400 4900*2380*2050

Parts material

Talings Aggregate Screening Equipment Customized Voltage Low Maintenance

Working principle

Sand dewatering screen adopts dual-motor self-synchronization technology. The motors coordinate with universal eccentric and adjustable amplitude vibrator. When the two motors start to work, the vibrators move reversely at the same time. The centrifugal force is generated by the eccentric blocks superpose themselves and form a single direction vibration. The high frequency vibration drives the screen move back and forth in line repeatedly. So the sand will be dehydrated and filtered.

Talings Aggregate Screening Equipment Customized Voltage Low Maintenance

Features

  1. Simple structure, easy maintenance.
  2. Advanced structure, light weight, high dehydrating ratio with new type vibrating motors.
  3. Cross beam and screen body connect with high strength bolts, no welding and easy to remove and maintenance.
  4. Polyurethane screen (PU) high screening ratio, big capacity,long service life and no blocking.
  5. Widely used, less replacement parts.
