Mining Industrial Thickener Machine Normal Motor For Treatment Sludge
Mining Industrial Thickener Machine Normal Motor For Treatment Sludge
Mining Industrial Thickener Machine Normal Motor For Treatment Sludge
Mining Industrial Thickener Machine Normal Motor For Treatment Sludge
Specifications
Brand Name :
MZZG
Model Number :
WS-6700
Place of Origin :
Henan, China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
10 set 15 set per month
Delivery Time :
35 work days
Packaging Details :
Depond on product
Name :
Mining Industrial Thickener Machine Normal Motor For Treatment Sludge
Condition :
New
Motor Type :
Normal
Application :
Treatment sludge, waste water
Dimension(L*W*H)(mm) :
6000*6000*7500
Advantages :
Change slurry water into clean
Function :
Solid-liquid Separation
Port :
Shanghai/Qingdao
Description

Mining Industrial Thickener Machine Normal Motor For Treatment Sludge

Working principle

The waste water from the processing material enters the central feeding barrel through the material channel, and passes through a series of effects such as slow flow and flocculation, so that the thickened underflow mud is discharged from the discharge port at the bottom of the tank and enters the filter press equipment, and presses into mud cake . The upper part of the tank produces clean water (overflow clarified liquid) with high cleanliness, which is discharged from the water outlet at the top. The clean water can be recycled to achieve zero discharge of production wastewater.

Mining Industrial Thickener Machine Normal Motor For Treatment Sludge

What is the function of this Deep cone thickener?

The deep cone thickener completely replaces the traditional sedimentation tank through the interaction of the internal mechanism of the tank and the flocculant. The sewage washed into sand is clean and can be recycled for sand washing and water reduction. The occupation of resources and land meets the requirements of environmental protection and sustainable development.

Equipment manufacturing site

Mining Industrial Thickener Machine Normal Motor For Treatment Sludge

Tech specification

Model

Feed

concentration
(%)

 Weight
(kg)		 Tank diameter
(mm)		 Process
capacity(m³/h)		 Dimension
L*W*H
(mm)
WS-3600 ≤20 6000 Φ3000 100-120 3000*3000*6500
WS-6700 ≤20 13500 Φ6000 200-250 6000*6000*7500
WS-8700 ≤20 33000 Φ8000 250-350 8000*8000*7500

Application

Now the deep cone thickener widely applied to dewatering to various metal and non-metal ores and the slurry solid-liquid separation in sectors like metallurgy, coals, chemicals, mine tailings and environment protection.

Structure

Mining Industrial Thickener Machine Normal Motor For Treatment Sludge
