Black Color Deep Cone Thickener Mineral Equipment 13500 Kg Gravity Sedimentation
Black Color Deep Cone Thickener Mineral Equipment 13500 Kg Gravity Sedimentation
Specifications
Brand Name :
MZZG
Model Number :
WS-6700
Place of Origin :
Henan, China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
10 set 15 set per month
Delivery Time :
35 work days
Packaging Details :
Depond on product
Manufacture standard :
Industrial Standard
Application :
treatment sludge, waste water
Keyword :
Black Color Deep Cone Thickener Mineral Equipment 13500 Kg Gravity Sedimentation
Motor Type :
Normal
Feed concentration (%) :
≤20
Weight (kg) :
13500
Advantages :
Change slurry water into clean
Installation :
Technical Guidance
Description

Black Color Deep Cone Thickener Mineral Equipment 13500 Kg Gravity Sedimentation

Introduction:
The solid-liquid separation equipment combined with gravity sedimentation can lift the slurry wastewater with a solid content of 2% to 10% to a concentration of 40% to 60% by gravity sedimentation. At the same time, the upper part of the tank realizes clear water overflow to achieve sewage. Purpose of purification and solid-liquid separation.

Structure:

Black Color Deep Cone Thickener Mineral Equipment 13500 Kg Gravity Sedimentation

Working principle:

The waste water from the processing material enters the central feeding barrel through the material channel, and passes through a series of effects such as slow flow and flocculation, so that the thickened underflow mud is discharged from the discharge port at the bottom of the tank and enters the filter press equipment, and presses into mud cake . The upper part of the tank produces clean water (overflow clarified liquid) with high cleanliness, which is discharged from the water outlet at the top. The clean water can be recycled to achieve zero discharge of production wastewater.

Black Color Deep Cone Thickener Mineral Equipment 13500 Kg Gravity Sedimentation

Tech specification:

Model

Feed

concentration
(%)

 Weight
(kg)		 Tank diameter
(mm)		 Process
capacity(m³/h)		 Dimension
L*W*H
(mm)
WS-3600 ≤20 6000 Φ3000 100-120 3000*3000*6500
WS-6700 ≤20 13500 Φ6000 200-250 6000*6000*7500
WS-8700 ≤20 33000 Φ8000 250-350 8000*8000*7500

Performance advantages:
1. Instead of the traditional sedimentation tank, solve the problem of sedimentation tank dredging
2. Overall closed structure, higher safety
3. Small footprint, saving land occupation
4. Recycle water, save resources and reduce pollution
5. Boiler steel as the main material of the tank body, without wearing parts, the service life can reach 10-15 years
