Portable Worker Camp Accommodation Steel Frame Prefab Home Kits
Portable Worker Camp Accommodation Steel Frame Prefab Home Kits
Portable Worker Camp Accommodation Steel Frame Prefab Home Kits
Portable Worker Camp Accommodation Steel Frame Prefab Home Kits
Portable Worker Camp Accommodation Steel Frame Prefab Home Kits
Portable Worker Camp Accommodation Steel Frame Prefab Home Kits
Portable Worker Camp Accommodation Steel Frame Prefab Home Kits
Portable Worker Camp Accommodation Steel Frame Prefab Home Kits
Specifications
Brand Name :
KHOME
Model Number :
KHPA
Certification :
CE, ISO
Place of Origin :
Henan, China
MOQ :
300 sqm
Price :
$50-$70 per square meter
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
30000 square meter per month
Delivery Time :
Depend on quantity needs
Packaging Details :
Naked packaged in 40 HQ shipping container
Connection :
Screws,Bolts
Application :
Factory and Construction site
Fireproof level :
A1
Installation :
Professional Guide
Wall material :
Rock Wool / PU Sandwich Panel
Roof material :
Rock Wool / PU Sandwich Panel
High Light :
steel home kits, tiny house kit, Prefabricated Construction Camp
Description

Portable Worker Camp Accommodation Steel Frame Prefab Home Kits

I. Introduction

This T type prefab house is the most economical and applicable for small and medium-sized temporary accommodation, office buildings, and schools. Its layout can very flexible.
It is the buildings with the longest history and the widest distribution which have been used for 40 years. After 15 technical improvements, the products have been widely distributed in all parts of the country and nearly 100 countries and regions around the world.
It is also one of the fastest temporary buildings that can be installed, with 4 people a day and 130 ㎡. A 40-foot container can carry about 330 ㎡.

II. Design description

Portable Worker Camp Accommodation Steel Frame Prefab Home Kits

1 Building area 192.40 sqm
2 Capacity 42 people
3 Floor number 1
4 Dormitory qty. 14
5 Toilet qty. 6
6 Roof type single slope


III. Main material specification

Part 1:Roof System
Roof Panel 50mm rock wool sandwich panel;
Color is common color: scarlet/blue
Herringbone Galvanized square tube: 40*80*1.4mm;
Firm, strong corrosion resistance and has a long service life
Roof Purlin Galvanized square tube: 40*60*1.4mm;
Strong, durable, corrosion resistance and has a long service life.
Ring Beam Galvanized square tube: 40*60*1.4mm;
Firm, strong corrosion resistance and has a long service life
Ceiling Steel plate ceiling
Strong and corrosion resistance
Part 2:Steel Frame (Bottom Steel Structure+Column+Bolt )
Bottom Steel Structure 1. Foot support: 40mm(Width)*80mm(Length)
2. Bottom purlin: 40mm(Width)*80mm(Height)
Column Galvanized square tube: 80*80*2.0mm;
Safe, strong and corrosion resistance,
The color is glossy and can last for a long time.
Bolt High strength galvanized steel bolt
Firm, strong and corrosion resistance
Part 3: Wall Panel
Wall Panel 50mm rock wool sandwich panel,( 0.38mm steel plate on both sides);
Color is a common color: white grey.

Portable Worker Camp Accommodation Steel Frame Prefab Home Kits

Portable Worker Camp Accommodation Steel Frame Prefab Home Kits

IV. FAQ

Q: How to buy?
A: You can provide us your drawing, and we will produce as your drawings.
Q: How to pay?
A: TT and L/C are acceptable and TT will be more appreciated. 30% deposit before producing, 70% balance before loading by TT.
Q: What is the delivery time?
A: It depends on the order quantities. Generally speaking, the delivery time will be within 15 to 30 days.
Q: How to ship?
A: Loading by sea shipping container.
Q: How to install after the goods arriving destination?
A: We will provide detailed illustration photos and videos to you. If it is necessary, we will send technicians to help you. However, the visa fee, air tickets, accommodation, wages will be borne by buyers.
