JIS G3445 DIN2391 High precision stainless steel tubing for Automobile

Description:

1. ProductItemNo.:004Precision-CoscoSteel
2. OD:6-80mm, WT:1-10mm,Length: 3000mm or 6000mm/pc
3. Tolerances: OD+/- 0.05, WT: +/-5%*S, or by agreement
4. Steel Grade: St30Al, St35, St37, St37.4, St44, St45, St52.4, E195, E235, E255, E355
5. Delivery conditions: BK, BKS, BKW, NBK, GBK
6. Tube ends: tubes are delivered with plain ends without burrs at the ends of the tube. Upon request, ends could be plugged with plastic caps
7. Testing : Testing is performed in accordance with corresponding standards or by agreement
   • flattening test , drift expanding test, flaring test, bending test
   • mechanical properties test
   • NDT for detection of transverse imperfections and wall imperfections
8. Packing and Protective coating:
   Finished tubes are heat treated in protetive atmosphere, and light oiled, packed in round or hexagonal bundles with weight max.2000 kg. Other possibilities by agreement
9. Marking:Registeredlogo,HeatNumber,SteelGrade,Standard,Size
10. H.SCode:7304.9000
11. Material:A/SA179,A/SA192,

20Cr/AISI5120/Scr420/20Cr4;30CrMo/AISI4130/SCM430/25CrMo4

40Cr/AISI5140/Scr440/41Cr

ST35/1.0308;ST37.4/1.0255;ST45/1.0408etc.

Standard:

AmericanStandardASTMA106,ASTMA519,ASTMA513,ASTMA179

GermanyStandardDIN2391,DIN2445

JapaneseStandardJISG3445etc

European Standard EN10305

Applications:

We,thistypeseamlesssteelpipebewidelyusedinkindsofindustries:

1. Bicyclespindle,hub,carriage,handleofchildrencart
2. Automobileoilduct,oil,ductconnector,shockabsorb-er,sunvisor,leveljoystick
3. Sportsequipment,electricroller
4. Sewingmachine,medicalequipment

Specifications

Standard:JIS G3445
USES:Applicable to machinery, automobile, bicycle, furniture, appliances and other mechanical parts with carbon steel pipe

The main production steel grades:
STKM11A, STKM12 (A, B, C), STKM13 (A, B, C), STKM14 (A, B, C)

Process

Ouradvantage

Weownedspecialequipmentformanufacturingvarioushighprecisionproducts

1. High-precisioncolddrawingunit
2. Brightannealingoven
3. Straighter
4. 100%UTinspectionifbuyerrequested
5. 100%ETinspectionifbuyerrequested
