X6325LA Vertical and Horizontal Turret Milling Machine
X6325LA Vertical and Horizontal Turret Milling Machine
Specifications
Brand Name :
Sanmore
Model Number :
Sanmore X6325LA
Certification :
CE Certificate
Place of Origin :
China
MOQ :
One Set
Supply Ability :
50 Sets Per Month
Delivery Time :
About one month
Packaging Details :
Wooden box
Description

Vertical and Horizontal Turret Milling Machine X6325W

Main specifications X6325W
Table size (mm) 1270*260
Table travel (mm) 700*280
Overall dimension (mm) 1655*1650*2300
Spindle Spindle taper (mm) NT30/R8/NT 40)
Spindle drilling diameter(mm) 15
Spindle quill travel(mm) 127
Spindle speeds Low (r/min) 80, 135,210, 325, 660, 1110,1750, 2720
High(r/min) 160,270 420, 650, 1320, 2220, 3500,5400
Distance from spindle to table surface(mm) 100-490
Left right ±90°
Before behind ±45°
Voltage 380V
Frequency 50Hz
Motor 3Hp
N. W/G..W 1650/1750

Technical support online service provided.

Technical files service provided.

All of the questions will be replied within 24 hours

Warranty period: one year

During warranty period, if you have any parts broken because of qulity problem, we will supply to you free of charge by express. Out of warranty period, if you have any question, you can contact with us, we will supply our best service to you.
