TiO2 Titanium Dioxide Crystal 10x10x0.5mmt 1sp/ 2sp Single Double Polishing
TiO2 Titanium Dioxide Crystal 10x10x0.5mmt 1sp/ 2sp Single Double Polishing
TiO2 Titanium Dioxide Crystal 10x10x0.5mmt 1sp/ 2sp Single Double Polishing
TiO2 Titanium Dioxide Crystal 10x10x0.5mmt 1sp/ 2sp Single Double Polishing
Specifications
Brand Name :
zmkj
Model Number :
sto wafers
Place of Origin :
china
MOQ :
10pcs
Price :
by case
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000pcs
Delivery Time :
2-4weeks
Packaging Details :
single wafer package in 100-grade cleaning room
material :
TiO2 crystal substrate
common size :
10x10 20x20
orientation :
<100><110><111>
color :
colorless
application :
High temperature superconducting junction technology
Description

TiO2 Crystal(Titanium Dioxide)Crystal by 10x10x0.5mmt 1sp/ 2sp

Product Name: Rutile (TiO2) crystal substrate

Product Description: Rutile (TiO2) large birefringence, large refractive index, is a method for spectral prism devices such as optical isolators and the polarization beam splitter and a very good material, compared with YVO4, TiO2 crystal better physical and chemical stability, Our high quality single crystal TiO2 rods and polished components widely used in optical isolators and special prism.

Technical parameters:

Specifications:

Typical dimensions: 2.6x2.6 x10 mm; 4x4x10 mm; 10x10x0.5 mm;

Size + / - 0.02 mm; flatness <l/10; roughness <10/5;

Parallelism <15 "; vertical <15"

Note: Can be customized according to the special orientation and size.

Standard Packaging: 1000 clean room, 100 clean bag or single box packaging

Major capability parameter
Crystal structure M4
Unit cell constant a=4.5936Å c=2.9582 Å
Density 4.26(g/cm3)
Melt point 1870℃
Dielectric constants dη/dT:a:-0.72×10­6/k c:-0.42×10-6/k
Linear expansion coefficient a:7.14×10­6 c:9.19×10­6
Hardness 7(mohs)
Polishing Single or double
Size 5×5×10mm,5×10×10mm,10×10×0.5mm
Polishing Single or double
Pack 100 clean bag,1000 exactly clean bag

Application:

Rutile has a large birefringence and a large refractive index. It is a good material for spectral prisms and polarizing devices (such as optical isolators and beam splitters). Compared with YVO4, TiO2 crystals have better physicochemical stability.

TiO2 Titanium Dioxide Crystal 10x10x0.5mmt 1sp/ 2sp Single Double Polishing

OUR RELATED PRODUCTS

TiO2 Titanium Dioxide Crystal 10x10x0.5mmt 1sp/ 2sp Single Double Polishing

FAQ


Q. Do you have any stock of wafer or ingots?

yes,aslike 3inch,4inch commen size substrates wafers are in stocks.


Q. Where is your company located?
Our company located in shanghai,China. factory is in wuxi city.

Q. How long will take to get the products?
Generally it will take 1~4 weeks to process and then delivery.

It is depend on the quantity and the size of the products.

Q: How about pay term ＆ delivery ?

T/T 50％deposit and left part before delivery by FOB .
