Type A Female USB Charging Connector , Lightweight 8 Pin Dual USB 2.0 Connector
Type A Female USB Charging Connector , Lightweight 8 Pin Dual USB 2.0 Connector
Type A Female USB Charging Connector , Lightweight 8 Pin Dual USB 2.0 Connector
Type A Female USB Charging Connector , Lightweight 8 Pin Dual USB 2.0 Connector
Type A Female USB Charging Connector , Lightweight 8 Pin Dual USB 2.0 Connector
Type A Female USB Charging Connector , Lightweight 8 Pin Dual USB 2.0 Connector
Type A Female USB Charging Connector , Lightweight 8 Pin Dual USB 2.0 Connector
Type A Female USB Charging Connector , Lightweight 8 Pin Dual USB 2.0 Connector
Type A Female USB Charging Connector , Lightweight 8 Pin Dual USB 2.0 Connector
Type A Female USB Charging Connector , Lightweight 8 Pin Dual USB 2.0 Connector
Specifications
Brand Name :
SHUANG YI
Model Number :
USB2.0
Certification :
ISO9001/SGS/UL/RoHS/Reach
Place of Origin :
Guangdong, China (Mainland)
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T, L/C
Supply Ability :
100000 Piece/Pieces Per Month
Delivery Time :
7~10 Work Days
Packaging Details :
1.Reel Packing 2.Custom Box Packing 3.According To Client's Request
Application :
PCB, PC System, Printer, Server
Contact Platin :
1'-50u'
Material :
ABS/PBT/PA66/LCP
Gender :
Female
Description

Type A Female USB Charging Connector , Lightweight 8 Pin Dual USB 2.0 Connector

Product Name : USB Jack;Type : USB 2.0 Type A Female

Mount Pin Distance : 15mm/0.6";Pin Spacing : 2mm/0.08"

Total Size : 17x 15x 16mm/0.67"x 0.6"x 0.63"(L*W*H);

Material : Metal, Electronic Parts

Main Color : Black, Silver Tone;Weight : 63g

Package Content : 10 x USB Jack

Product Description:

USB 2.0 Type A Female Port, 8 Pin 90 Degree, soldering or PCB mount.

NOTES:Electrical:
1. Voltage:125VAC RMS.
2. Current Rating:1.5A.
3. Contact Resistance:30 Millohms max.
4. Insulation Resistance:500 Megohms Min @500VDC.
5. Dielectric Strength:1000VAC RMS 50Hz 1Min.

6. RJ-45 Contact plating: Gold 6 micro-inches min.
In contact area
USB Contact plating: Gold flash

7. Gold Plating:(Gold Flash;1.5;3;6;15;30;50)U" Inch
8. Wave solder temperture: 230℃ to 250℃,5～10 Sec.

MECHANICAL:
1. Housing Material:Glass Filled Polyester UL94V-0.
2. Contact Material:Phosphor Bronze %%C 0.45mm.
3. Plating:Gold Plating Over Nickel.
4. Operating:750 Cycles Min.
5. Shield 0.23mm Thickness Copper Alloy With Nickel
Plated.
6. PCB Retention Pre-Solder:1 LB Min.

Environmental:
1. Temperature Range:-45℃～+85℃.
2. Relative Humidity:90～95%(40±2℃)
