Double Layers Female USB Micro Connector Type A Right Angle 8 Pin DIP Jack
Double Layers Female USB Micro Connector Type A Right Angle 8 Pin DIP Jack
Double Layers Female USB Micro Connector Type A Right Angle 8 Pin DIP Jack
Double Layers Female USB Micro Connector Type A Right Angle 8 Pin DIP Jack
Double Layers Female USB Micro Connector Type A Right Angle 8 Pin DIP Jack
Double Layers Female USB Micro Connector Type A Right Angle 8 Pin DIP Jack
Double Layers Female USB Micro Connector Type A Right Angle 8 Pin DIP Jack
Double Layers Female USB Micro Connector Type A Right Angle 8 Pin DIP Jack
Specifications
Brand Name :
SHUANG YI
Model Number :
USB3.0
Certification :
ISO9001/SGS/UL/RoHS/Reach
Place of Origin :
Guangdong, China (Mainland)
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T, L/C
Supply Ability :
100000 Piece/Pieces Per Month
Delivery Time :
7~10 Work Days
Packaging Details :
1.Reel Packing 2.Custom Box Packing 3.According To Client's Request
Application :
PCB, PC System, Printer, Server
Contact Platin :
1'-50u'
Material :
Phosphor Bronze
Gender :
Male
Description

Double Layers Female USB Micro Connector Type A Right Angle 8 Pin DIP Jack

Product Name : USB Jack;Type : USB 2.0 Type A Female

Mount Pin Distance : 13mm/0.5";Pin Spacing : 2mm/0.08"

Total Size : 17 x 13 x 15.5mm/0.7'' x 0.5'' x 0.6'' (L*W*H);Material : Metal, Electronic Parts

Main Color : Black, Silver Tone;Net Weight : 5g

Package Content : 1 x USB Jack

Product Description:

USB 2.0 Type A Female Port, 8 Pin 90 Degree, soldering or PCB mount.

Features:
• Current Rating: 1.5A
• Contact Resistance: 30MΩ Max.
• Insulation Resistance: 1000MΩ Min. at 500 VDC
• Dielectric Withstanding Voltage: 500 VAC / Min.
• Operating Temperature: -40ºC to +105ºC
• Housing: LCP UL94V-0
• Contacts: Phosphor Bronze
• Pin Plated: Gold 3u" or customize

Applications:
• Audio equipment
• Digital optical data link
• Computer, Automobile
• Sound card
• TV sets, Microcomputer equipment
• Charge, printers, Terminals
• UPS, VCD/DVD players, audio and visual equipment
• Medical electronics
• Meters and equipment product
• Power supplies
• Current control and heat dissipation
• Other fields

Rated we can make:
• Wafer/housing/terminal
• SMA/MCX/BNC connector
• Pin header and Female header
• Switch, Power Jack and Solar Junction Box
• FFC connector and cable, IDC socket and cable
• SIM/CF/SD/TF card connector and USB connectors
• Various of HDMI, USB, FFC cables and Wire harness
• Various of Terminal block
• Various of Power transformers
• Various of inductor and current transformers
• Customer design per your request. Welcome OEM&ODM.
