SFF 8087 To SFF 8482 Dual Port SAS Power Cable SAS TO SAS Length 0.65m

Features:

Product Type Data Transfer Cable
Manufacturer Part Number SAS808782P50
Product Name 50cm Internal Serial Attached SCSI Mini SAS Cable - SFF8087 to 4x SFF8482
Green Compliant Yes
Green Compliance Certificate/Authority RoHS
Weight (Approximate) 3.20 oz
Color Red
Cable Length 1.64 ft
Device Supported Hard Drive
Connector on First End 1 x 36-pin SFF-8087 Male Mini-SAS
Connector on Second End 4 x 15-pin Male SATA Power
4 x 29-pin SFF-8482 Mini-SAS
Cable Type SAS/SATA

Monoprice 65CM 28AWG Internal Mini SAS 36-Pin SFF-8087 Male to SAS 29-Pin Female and 4-Pin Power Cable, Black

Serial Attached SCSI (SAS) is a high-speed data storage interface designed for high-throughput and fast data access

Intended primarily for data storage centers the SAS interface is backwards compatible with SATA

This 1 meter long cable uses 28 AWG wires and is intended for external use

Serial Attached SCSI (SAS) is a high-speed data storage interface designed for high-throughput and fast data access. Intended primarily for data storage centers, the SAS interface is backwards compatible with SATA. This allows the user to mix more expensive, lower-capacity SAS drives for applications that require faster data access and higher reliability, with lower-cost, higher-capacity SATA drives for applications with lower access speed requirements. Monoprice carries a full line of quality SAS cables with connectors for every possible application, both internal and external.

This 1 meter long cable uses 28 AWG wires and is intended for internal use. It has a single 36-pin SFF-8087 male Mini-SAS plug on one end and four 29-pin SFF-8482 female SAS plugs, each with an attached 4-pin Molex 8981 female drive power plug, on the other end.

Mini SAS 36Pin To 4 * SAS 29Pin Cable, SFF8087 To 4 * SFF8482 Cable, 65M

Mini Serial Attached SCSI (mini SAS) Internal Cable Assemblies provide for high speed transmission up to 6 Gbps. It is an ideal interconnect solution for the growing server and storage market. Mini SAS are designed to significantly reduce the cable size for storage systems currently using SAS 4-lane (4x or 4-lanes of data) and are being widely adopted for next-generation designs.The 36-position internal mini SAS cable assemblies are available in custom lengths of up to one meter. They are also available in three standard sideband configurations. Customized sideband configurations are available upon request.Mini SAS was developed to support data rates at 6.0 Gbps in order to meet the ongoing industry requirement for higher speed and greater bandwidths, This data rate is achieved via the use of high speed differential signals. One assembly is designed to support up to four channels of transmit and receive.
