Customize Black Wire To Board Connectors Crimp Type 22 Pin Jst For PC PCB
Customize Black Wire To Board Connectors Crimp Type 22 Pin Jst For PC PCB
Customize Black Wire To Board Connectors Crimp Type 22 Pin Jst For PC PCB
Customize Black Wire To Board Connectors Crimp Type 22 Pin Jst For PC PCB
Specifications
Brand Name :
SHUANG YI
Model Number :
Wire To Board Connector
Certification :
ISO9001/SGS/UL/RoHS/Reach
Place of Origin :
Guangdong, China (Mainland)
MOQ :
Negotiation
Price :
Negotiation
Supply Ability :
100000 Piece/Pieces per Month
Delivery Time :
7~10 Work days
Packaging Details :
1.Custom polybag packing 2.Custom paper box packing 3.According to client's request
Applicable PC board thickness :
0.8-1.6mm
Voltage Rating :
1400V AC/DC
Application :
PCB
Terminal :
Phosphor bronz
Housing :
Nylon UL94V-2(0)
Applicable wires :
AWG#22~#28
Gender :
Male
Working temp :
-20~85degrees
Current Rating :
1A
Poles :
2-24
Description

Customize Black Wire To Board Connectors Crimp Type 22 Pin Jst For PC PCB

Specification:

1. Poles: 2 to 20

2. Pitch: 1.5mm

3. Current Rating: 1A AC, DC

4. Voltage Rating: 100V AC, DC

5. Temperature Range: -25 to +85°C

6. Contact Resistance: 20mΩ (maximum)

7. Insulation Resistance: 500mΩ (minimum)

8. Withstanding Voltage: 500V AC/minute

9. Material: Wafer Nylon 66 9T, UL94V-0

10. Pin phosphoric copper tin-plate

11. Solder tads phosphoric copper tin-plate

12. Color: Black

13. Applicable Wire Sizes: AWG#22~#28

14. Applicable PC board thickness: 0.6~1.2mm

15. Exchangable: Exchangable with same specification products.

16. Dielectric Strength: ≥500V AC/minute

Application:

Auto mobile, Computer, Electronic, Home appliance, Motorccle, Speed governor, Voltage stabilizer, Inverter Electric meter, Electronic scales, LED Lighting.
