Specifications
Brand Name :
Hopui
Model Number :
AL-FFU-575
Certification :
CE
Place of Origin :
China
MOQ :
1 Piece/Pieces
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
5000 Piece/Pieces per Month
Delivery Time :
10-20 working days
Packaging Details :
PE bag package then put in the a carton.
Description

HEPA Fan Filter Unit FFU For Clean Room In Pharmaceutical And Medical Industry

Fan filter Unit (FFU)

Product Information:

Fan Filter Unit (FFU) is self-clean air equipment, it can be installed to the ceiling or setted on the holder, which can reach Class100. FFU has HEPA filter and pre-filter, the fan absorbs the air from the top through the prefilter and HEPA filter then the clean air at 0.45m / s ± 20% speed blow out by the whole air supply grill.

Standard Model Technology Parameter:

Model

AL-FFU-575

AL-FFU-1175

AL-FFU-1225

AL-FFU-1175×2

Cabinet Size

(W×D×H)mm

575×875×230

575×1175×230

615×1225×230

1175×1175×230

Cabinet Material

Epoxy powder coated steel/Galvanized steel with aluminum painted/Stainless steel

Air Flow(m3/h)

800

1100

1200

2000

Noise(dB)

56

56

58

58

Air Velocity

0.3~0.5m/s

0.3~0.5m/s

0.3~0.5m/s

0.3~0.5m/s

(pa)

97(10mAq)

97(10mAq)

97(10mAq)

97(10mAq)

HEPA Filter

Size

570×870×69

570×1170×69

610×1220×69

1170×1170×230

Efficiency

99.995% 0.3µm

99.995% 0.3µm

99.995% 0.3µm

99.995% 0.3µm

Frame

Aluminum

Initial

pressure loss

220pa 0.45m/s

220pa 0.45m/s

220pa 0.45m/s

220pa 0.45m/s

Fan

Power Supply

220V/50hz

220V/50hz

220V/50hz

220V/50hz

Type

Aluminum turbofan

Vibration

0.2~0.5mm/s

0.2~0.5mm/s

0.2~0.5mm/s

0.2~0.5mm/s

Total Power

170W

170W

210W

275W

Weight

24kg

28kg

31kg

47kg

Salient Features: long use life, low noise and vibration, maintenance-free, adjustable air speed, thousands unit can be easy controlled.

Factory Strict Test: according to international ISO14644-1 standards, with a dust particle counter detection one by one to ensure the quality.

Application: widely used in the semiconductor, electronics, flat panel displays, and optical disk drive manufacturers, bio- industries, assembled clean room and laminar flow hood.etc.
