830mmx500mm Manual Scissor Lift Tables Max Height 910mm
830mmx500mm Manual Scissor Lift Tables Max Height 910mm
830mmx500mm Manual Scissor Lift Tables Max Height 910mm
830mmx500mm Manual Scissor Lift Tables Max Height 910mm
830mmx500mm Manual Scissor Lift Tables Max Height 910mm
830mmx500mm Manual Scissor Lift Tables Max Height 910mm
830mmx500mm Manual Scissor Lift Tables Max Height 910mm
830mmx500mm Manual Scissor Lift Tables Max Height 910mm
830mmx500mm Manual Scissor Lift Tables Max Height 910mm
830mmx500mm Manual Scissor Lift Tables Max Height 910mm
Specifications
Brand Name :
JS
Model Number :
BS25
Certification :
CE/ISO9001
Place of Origin :
China
MOQ :
10 set
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 sets per month
Packaging Details :
Carton package or pallet package
Product name :
Manual Scissor Lifter
Capacity :
250kg
Lifting height: :
265mm~1585mm(customized)
Table Size: :
700*450mm-1010*520mm
Power :
2.2kw
Keyword :
Single scissor lift tables
Core Components: :
Pressure vessel
Material :
High Strength Steel
Type :
OEM Support
After-Sales Service :
Free spare parts
Description

Single Scissor Platform 830mm * 500mm Manual Scissor Lifter Tables Max Height 910mm

Portable scissor lifter table

More than 20 years, we started to produce and manufacture lifts. For more than 20 years, we have a wealth of experience and our mobile shear forklift technology is first class, featuring innovative design and industry leading quality.

High quality single scissors lift and double scissors lift has the following advantages:
Single lever regulation
Conform to international standards
Stable and controllable base
Standard steel thickness
Light weight, compact structure, easy to move and operate

Model
Capacity
(kg)
Description
Single/Double Scissor
Platfor Size
(mm)
Min/Max Height
(mm)
Wheel Dia.
(mm)
N.W.
(kg)
BS15
150
Single
700x450
265x755
100
41
BS25
250
Single
830x500
330x910
125
78
BS50
500
Single
1010x520
435x1000
150
112
BS75
750
Single
1010x520
442x1000
150
112
BS100
1000
Single
1010x520
445x950
150
130
BS15D
150
Double
830x500
435x1430
125
90
BS30D
300
Double
1010x520
435x1585
125
137.5
BS50D
500
Double
1010x520
440x1575
150
156
BS80D
800
Double
1010x520
470x1410
150
160

Portable Hydraulic manual scissor lifter tables

The portable manual scissor lifter table is an effective low-cost solution that can be raised to a height of 1580 mm. Ideal for lifting small, heavy goods to a comfortable working height - the perfect multi-stage work platform for easily positioning loads.
830mmx500mm Manual Scissor Lift Tables Max Height 910mm
Handle to release/lower the platform
Full parking brake prevents any movement when loading/unloading Lift height: from 265 mm to 1585 mm

830mmx500mm Manual Scissor Lift Tables Max Height 910mm

Pistion
Minimal maintenance lift using a foot pump for easy, stable lifting and a manual hydraulic system for precise lowering.
Load capacities from 150kg to 1000kg are available by superior pistion.
830mmx500mm Manual Scissor Lift Tables Max Height 910mm

Assemble

830mmx500mm Manual Scissor Lift Tables Max Height 910mm830mmx500mm Manual Scissor Lift Tables Max Height 910mm

Scan the QR code to contact us for quick reply for the Scissor lift tables
830mmx500mm Manual Scissor Lift Tables Max Height 910mm830mmx500mm Manual Scissor Lift Tables Max Height 910mm
