Heavy Duty Stationary Hydraulic Lift Table Electric Container Load Scissor Lift
Heavy Duty Stationary Hydraulic Lift Table Electric Container Load Scissor Lift
Heavy Duty Stationary Hydraulic Lift Table Electric Container Load Scissor Lift
Heavy Duty Stationary Hydraulic Lift Table Electric Container Load Scissor Lift
Specifications
Brand Name :
HESHAN
Model Number :
SLT
Certification :
CE,ISO,SGS,ROHS
Place of Origin :
China
MOQ :
1 unit
Price :
USD 900-USD 4000/unit
Payment Terms :
T/T, Western Union
Supply Ability :
1000/units per month
Delivery Time :
15-20 work days
Packaging Details :
Plywood case package
Application :
Hotels, Building Material Shops
Load Capacityy :
1000kg,2000kg,3000kg,4000kg,20000kg
Platform Size :
Standard and OEM
Color :
Customized
Feature :
Easy Operation Safety Convenience
Warranty :
2 Years
OEM :
YES
After-sales service provided :
Free spare parts
Power :
1.5kw~7.5kw
Core Components :
Pressure vessel
Description

Heavy Duty Stationary Electric Hydraulic Container Load Scissor Lift

Heavy Duty scissor lift table is designed for portability and features an electric motor for convenient lifting and lowering. It has a load capacity of 20000kg and a durable steel frame with an eye-catching orange finish.

The Heavy Duty Lift Table is a robust and reliable product that is designed to facilitate heavy lifting and positioning tasks in industrial settings. Its key features include a high load capacity of up to 10,000 pounds, a durable steel construction that ensures long-term durability, and a smooth and precise hydraulic lifting system that allows for easy and accurate lifting of heavy loads. The lift table is also equipped with safety features such as a safety bar, safety restraint, and safety velocity fuse, which ensure worker safety during operation. Additionally, the lift table features a user-friendly control panel that allows for easy adjustment of lift height and speed, making it an efficient and versatile tool for any heavy lifting task.

Basic Parameter:

  • Load range: 1000kg~20000kg. Or customized according to customer requirements.
  • Platform Size: standard parameters or special customization.
  • Maximum lifting height: customized heavy duty lift table.

Standard Hysraulic Electric Scissor Lift Tbale Parameters:

(Can be customized if special size or requirement)

Model Load Capacity(KG) Self Height(MM) Max Platform Height(MM) Platform Size(MM) Base Size(MM) Lifting time(s) Motor(KW) Net weight(KG)
SLT01 1000 205 1000 1300×820 1240×640 20~25 1.1 160
SLT02 1000 205 1000 1600×1000 1240×640 20~25 1.1 186
SLT03 1000 240 1300 1700×850 1580×640 30~35 1.1 200
SLT04 1000 240 1300 1700×1000 1580×640 30~35 1.1 210
SLT05 1000 240 1300 2000×850 1580×640 30~35 1.1 212
SLT06 1000 240 1300 2000×1000 1580×640 30~35 1.1 223
SLT07 1000 240 1300 1700×1500 1580×1320 30~35 1.1 365
SLT08 1000 240 1300 2000×1700 1580×1320 30~35 1.1 430
SLT2001 2000 230 1000 1300×850 1220×785 20~25 1.5 235
SLT2002 2000 230 1050 1600×1000 1280×785 20~25 1.5 268
SLT2003 2000 250 1300 1700×850 1600×785 25~35 2.2 289
SLT2004 2000 250 1300 1700×1000 1600×785 25~35 2.2 300
SLT2005 2000 250 1300 2000×850 1600×785 25~35 2.2 300
SLT2006 2000 250 1300 2000×1000 1600×785 25~35 2.2 315
SLT2007 2000 250 1400 1700×1500 1600×1435 25~35 2.2 415
SLT2008 2000 250 1400 2000×1800 1600×1435 25~35 2.2 500
SLT4001 4000 240 1050 1700×1200 1600×900 30~40 2.2 375
SLT4002 4000 240 1050 2000×1200 1600×900 30~40 2.2 405
SLT4003 4000 300 1400 2000×1000 1980×900 35~40 2.2 470
SLT4004 4000 300 1400 2000×1200 1980×900 35~40 2.2 490
SLT4005 4000 300 1400 2200×1000 2000×900 35~40 2.2 480
SLT4006 4000 300 1400 2200×1200 2000×900 35~40 2.2 505
SLT4007 4000 350 1300 1700×1500 1620×1400 35~40 2.2 570
SLT4008 4000 350 1300 2200×1800 1620×1400 35~40 2.2 655

Heavy Duty Stationary Hydraulic Lift Table Electric Container Load Scissor LiftHeavy Duty Stationary Hydraulic Lift Table Electric Container Load Scissor Lift

Safety Precautions of heavy duty lift table:

  • Industrial Movable Lift Table Explosion-Proof Valves: These valves safeguard the hydraulic pipes and prevent hydraulic pipe ruptures.

  • Pressure Relief Valve: This valve helps regulate pressure and prevents high pressure buildup during upward movements.
  • Emergency Descent Valve: In the event of an emergency or power failure, this valve enables a controlled descent of the platform.
  • Anti-Fall Device: This feature ensures the stability and safety of the platform, preventing any accidental dropping.
  • Automatic Safety Sensors: Equipped with sensors, the lift platform will automatically stop when it encounters any obstacles or barriers.

The Heavy Duty Stationary Electric Hydraulic Container Load Scissor Lift is designed for heavy-duty tasks and offers the following features:
  • High Load Capacity: It can handle heavy loads efficiently.
  • Electric Hydraulic System: Provides smooth and reliable lifting and lowering operations.
  • Stationary Design: Offers a stable platform for loading and unloading containers.
  • Durable Construction: Built with strong materials for long-lasting performance.
  • Safety Features: Equipped with safety rails, non-slip platform, and emergency stop buttons.
  • Versatility: Suitable for various industries and applications.
  • User-Friendly: Easy to operate and control.
  • Customizable Options: Can be tailored with additional accessories.
  • Compliance: Meets industry safety and performance standards.

Conditions for electric lift table:

Quality warranty: 12 Months.Free Spare Parts Replacement.

Packing: will be packed by high quality boxes and put on pallet.
