16m Diesel Hydraulic Articulated Towable Boom Lift 200kg Load Capacity
16m Diesel Hydraulic Articulated Towable Boom Lift 200kg Load Capacity
16m Diesel Hydraulic Articulated Towable Boom Lift 200kg Load Capacity
16m Diesel Hydraulic Articulated Towable Boom Lift 200kg Load Capacity
Specifications
Brand Name :
HESHAN
Model Number :
CP
Certification :
CE,ISO,SGS,ROHS
Place of Origin :
China
MOQ :
1 set
Price :
USD 8000~USD 30000
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Delivery Time :
15-25 work days
Packaging Details :
Export packing cases
Application :
plant installation, maintenance, venue construction,maintenance, construction engineering, large-scale warehousing, aviation,aerospace industry applications, airports,harbors, urban utilities,gardening, curtain wall engineering
Feature :
Easy Operation Safety Convenience, platform 360° rotation, Low noise, Electrostatic spraying painting, Self-Propelled Hydraulic Mobile
Max. Working height :
Up-and-over height up to 60'
Power supply :
Diesel-powered,Battery powered
Load Capacity :
200kg
Color :
Blue, Red, Yellow,Orange
Table Size :
0.9*0.7M
Lifting height :
8m,10m,12m,14m,16m,19m,22m
Power :
Diesel,Battery,Hybrid dual power
Machinery Test Report :
Provided
Warranty :
1 Year
Controls :
Joystick/Remote
Platform Rotation :
360°
Safety Features :
Emergency Stop/Alarm/Safety Harness
Description

200kg 16m Towable Articulated Towable Hydraulic Diesel Boom Lift

Looking for a reliable and versatile solution for accessing high-altitude areas? Look no further than our Articulated Towable Hydraulic Diesel Boom Lift. With its powerful diesel engine and articulated boom design, this lift can reach heights of up to several meters and can be easily maneuvered in tight spaces. The towable design allows for convenient transportation between job sites, while the hydraulic system provides precise control and stability during operation. Whether you're in construction, building maintenance, or industrial work, our Articulated Towable Hydraulic Diesel Boom Lift is a reliable and efficient choice for accessing high-altitude areas. With advanced safety features and a durable construction, you can trust our lift to get the job done safely and efficiently.
Specification:
Model Type CP-10A CP-12A CP-14A CP-16A CP-18A CP-20A
Lifting height 10M 12M 14M 16M 18M 20M
Working height 12M 14M 16M 18M 20M 22M
Load capacity 200KG
Platform size 0.9*0.7M
Working radius 5.5M 6.5M 8.5M 10.5M 11M 11M
Net Weight 1855KG 2050KG 2500KG 2800KG 2800KG 3500KG
Overall Size( L*W*H) 5.2*1.7*2.1M 6.2*1.7*2.1M 5.6*1.7*2.1M 5.7*1.7*2.2M 6.5*1.8*2.3M 5.8*1.9*2.3M
Supporting Legs Stride Distance(Horizontal) 3.0 M 3.6 M 3.6 M 3.9 M 3.9 M 3.9 M
Supporting Legs Stride Distance (Vertical) 4.7 M 4.7 M 4.7 M 4.9 M 4.9 M 4.9 M
Wind Resistance Level ≦5

16m Diesel Hydraulic Articulated Towable Boom Lift 200kg Load Capacity16m Diesel Hydraulic Articulated Towable Boom Lift 200kg Load Capacity

Features & Advantages

  • China's renowned YSD diesel pump station.
  • Electrical box with waterproof and dustproof features, ideal for outdoor use.
  • Control panel that is protected from rain.
  • Self-leveling feature for optimal and safe operation.
  • Water-resistant diesel engine, motor, and battery cover.
  • Maintenance access point designed for easy use.
  • Manually operated diesel engine accelerator, providing more flexible operation.
  • Double cylinders with balance valve and emergency decline switch, ensuring safety even in case of hydraulic hose rupture.
  • Basket leveling switch, making adjustments easier.
  • Torsion shaft with excellent shock absorption for improved road performance.
  • Hydraulic oil filtration alarm system that reminds you to replace oil if impurities are present.
  • Basket and arm lock system to prevent equipment body sway during transportation.
  • Illuminated platform for working.
  • Brake lights connected to the tractor.
  • Anti-pinch basket.
  • Safety harness for operator protection.
  • Stable rotary motor capable of 360-degree rotation.
  • Free quick wear parts for prompt replacement included in the offer.
  • Touch display fault code, easy maintenance.

Touch display fault code, easy maintenance.

A cherry picker machine is an essential tool for any job that requires working at height. These machines are designed to provide a stable and secure platform for workers to perform tasks such as painting, roofing, and maintenance work.
One of the key benefits of a cherry picker machine is its versatility. It can be easily maneuvered in tight spaces, making it ideal for use in a wide range of environments. Plus, with its stable platform and safety harnesses, it provides a safe and secure environment for workers to perform their tasks.If you need something even more versatile, a towable manlift for sale might be just what you need. These machines are designed to provide mobility and flexibility, making them ideal for a wide range of tasks. And if you need something that's easy to set up and maneuver, a tracked manlift could be just what you need.

Quick Setup and Mobility:
Time is of the essence in any project, and our Cherry picker ensures quick setup and effortless mobility. Its compact design and lightweight construction allow for easy transportation and maneuverability on various terrains. The user-friendly setup process saves valuable time, enabling your team to start work promptly and efficiently.
Remote Control Functionality:
For added convenience and flexibility, our Cherry picker features remote control functionality. This allows operators to control the platform's movements from a safe and convenient location. The remote control feature is particularly useful for precise positioning in challenging or hazardous environments, enhancing operator safety and operational efficiency.
