Specifications
Brand Name :
Anping County Xinlu Wire Mesh Products Co.,Ltd
Model Number :
XL- stainless steel filter screen -028
Place of Origin :
Anping County, Hebei Province, China
MOQ :
4pcs
Price :
Negotiable according to the specification
Payment Terms :
T/T
Supply Ability :
100pcs/20days
Delivery Time :
8-10days
Packaging Details :
wood case
Name :
300micron V Wire Johnson Screen Slotted Filter Pipe For Water Well
Material :
SS304, or 316L, 321, Duplex stainless steel, Hastelloy
tag :
Stainless Steel Johnson Screen Pipe, SS Wedge Wire Filter Pipe, Water Lateral Filter Pipe for Filtration Equipment
High Light :
ss304 johnson wire screen, 6-5/8" johnson wire screen, downhole slotted vee wire screen tube
End connection :
welded ring, threaded API, PT, NPT，BST, flange, etc
Slot :
0.30mm
Advantage :
no magnetic, Easy for installation, Long using life
Application :
Filter, filter, mineral, gas/oil/liquid filtration, Industry
Description

300micron V Wire Johnson Screen Slotted Filter Pipe For Water Well

Our screen filter tubes can be designed for a flow from out to in (standard construction) or from into out (re-rolled construction).

The screen is perfectly round and is adapted for self-cleaning filters or screw press filters.

It can be cleaned with scrappers.

Flanges and reinforcement rings are available depending on the application.

Filter Direction:

300 Micron V Wire Johnson Screen Slotted Filter Pipe For Water Well

Application of SS Wedge Wire Filter Pipe

The SS Wedge Wire Filter Pipes are mainly used for the water-treatment, water well drilling, oil well drilling, mineral processing, coal-cleaning plant, sewage treatment and other industries, water, oil or gas filter, and other filtration equipment.

SS Wedge Wire Filter Pipe for water well

Benefits:

Easy cleaning surface
High percentage open area
Minimal clogging and maximum water flow
Strong construction
Can be designed and customized according to working conditions.

Noted: Specifications Can Be Customized According To Requirement

Stainless Steel Continuous Slot Wedge WireJohnson Water Well Filter Screen Tube Specifications:

sizes
(inch)		 OD
(mm)		 slot
(mm)		 Length
(m)		 Tenslile
strength		 collapse
Strength

wrap wire
vee-shaped wire

(Width x height:mm)

 support rod
Round wire (mm)
3-1/2 88.9 1 2.9 >22 10.2 2.3 x 3.5 3.0MMx22
4-1/2 114.3 1 2.9 >28 11.5 2.3 x 3.5 3.0MM×22
6-5/8 168.3 0.75 5.8 >40 12.8 2.3 x 3.5 3.8MM×32
6-5/8 168.3 1 5.8 >33 12.8 2.3 x 3.5 3.8MM×32
6-5/8 168.3 0.63 5.8 >83 45 3.0 x 6.0 5.OMM×32
8-5/8 219.1 1 5.8 >34 21.9 2.3 x 3.5 3.8MMx48
8-5/8 219.1 1 5.8 >50 38.2 3.0 x 4.6 4.0MMx48
8-5/8 219.1 1 5.8 >60 46 3.05 x 6.35 5.0MMx48
10-3/4 273.1 0.75 5.8 >50 9 2.5 x 4 .0 3.8MM×55
10-3/4 273.1 1 5.8 >60 39.5 3.0 x 4.6 4.5MMx55
10-3/4 273.1 1 5.8 >100 48 3.2 x 6.0 5.0MM×55
12-3/4 323.9 1 5.8 >120 37.2 3.0 x 6.0 4.0MMx56
14 355.6 1 2.9 >80 37.8 3.0 x 5.0 4.0MMx59
16 426 1 2.9 >80 37.5 3.0 x 5.0 4.OMM×64

　PROFILE WIRE
　WIDTH(mm) 1.00 1.50 1.50 2.00 2.30 2.50 3.00 3.05
　HEIGHT(mm) 2.00 2.00 2.50 3.80 3.50 4.00 4.60 6.35

　SUPPORT ROD
ROUND
　WIDTH(mm) 1.80 2.00 2.50 3.00 3.00 Ø2.5--Ø6mm
　HEIGHT(mm) 2.50 3.00 4.00 4.60 6.00 ----

Package of wedge wire filter screens:


Plastic bubble bag packaging
Transparent plastic bag inside, woven bag outside
Wooden box
Pallet

FAQ

Q1. Can I have a sample order?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A: 3-5 days for Sample preparing , 15-25 working days for mass production.

Q3. Do you have any MOQ limit for the order?

A: Low MOQ, 3pc for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?

A: Airline, sea shipping and rail transportation are all optional.

Or ship by EMS, DHL, UPS, FedEx or TNT, it takes 5-7 days to arrive.

Q5. How to proceed an order?

A: Firstly let us know your need specification or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms and places deposit for formal order.

Fourthly We arrange the production.

Q6. Is it OK to print my logo on the product?

A: Yes. Please inform us formally before our production.
