Customized Textile Screen Printing Mesh Roll 150 Micron Fast Printing Speeds
Customized Textile Screen Printing Mesh Roll 150 Micron Fast Printing Speeds
Customized Textile Screen Printing Mesh Roll 150 Micron Fast Printing Speeds
Customized Textile Screen Printing Mesh Roll 150 Micron Fast Printing Speeds
Customized Textile Screen Printing Mesh Roll 150 Micron Fast Printing Speeds
Customized Textile Screen Printing Mesh Roll 150 Micron Fast Printing Speeds
Specifications
Brand Name :
R&K
Model Number :
Y1871
Certification :
SGS,ISO9001:2008,SGS
Place of Origin :
Hebei,China(Mainland)
MOQ :
100METERS
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union,Paypal.Credit card
Supply Ability :
1000meter for 30days.
Delivery Time :
depends on your quantity,about 7days.
Packaging Details :
Poly bag inside,and cardboard box outise plus the woven bag..
Textile Printing Mesh Material :
100% Polyester Yarn
Textile Printing Mesh Thread diameter :
55 micron
Textile Printing Mesh Keywords :
Pritning mesh,polyester mesh,screen printing mesh...
Roll width :
Max width up to 2.6meter
Roll length :
Normally 50/60/80/100/500/1000
Brand name :
R&K
Specification :
47T-55 micron
Description

Textile Screen Printing Mesh Polyester Fabric Yellow Color 150 Micron Plain Weave

Polyester mesh is the carrier of the directly plate making and printing.Polyester printing mesh are widly used in ceramic print,glass print,textile print,graphic print, it is plain weave mesh,twill weave is not available on the printing industry.

Description for the Textile Printing Mesh:

Textile Printing Mesh Material:100% monofialment polyester yarn

Textile Printing Mesh Mesh count:47T/120mesh ,55 micron

Textile Printing Mesh Thread dimeter:55 micron

Textile Printing Mesh

Textile Printing Mesh Color:yellow,white,red,orange. other special size we can accept OEM,MOQ is 5000meters.

Specification for Polyester Screen Printing Mesh:

Mesh Count Diameter (Mesh/cm um) Mesh Count (Mesh/inch) Weave Aperture (um) Thread Diameter (um) Opening (%) Thickness (um) Thickness Tollerance (+/- um) Theoretical Ink (cm3/m2) Weight (g/m2) Tension value(N/CM)
165-31PW (S) 420 1:1 23 31 15 48 2 7 36 25
150-34PW(T) 380 1:1 23 34 13 55 3 6.5 42 30
150-31PW(S) 380 1:1 32 31 23 49 3 11 32 24
140-34TW(T) 355 2:1 33 34 21 56 3 12 41 27-28
140-34PW(T) 355 1:1 31 34 20 53 3 10 39 26-28
140-31PW(S) 355 1:1 36 31 26 48 2 12 30 22-24
130-34PW(T) 330 1:1 40 34 27 55 3 15 37 27-28
120-40PW(HD) 305 1:1 37 40 20 63 3 13 44 33-35
120-34PW (T) 305 1:1 45 34 30 55 3 16 35 25-26
120-31PW (S) 305 1:1 49 31 35 49 3 17 26 20-23
110-40PW (HD) 280 1:1 48 40 27 64 3 17 40 30-32
100-40PW (T) 255 1:1 58 40 33 63 3 21 37 26-27

Features for the Polyester Screen Printing Mesh:

Low-enlongation;

High tenson threshold and braking point;

Faster tension stabilization;

Improved fabric strength;

Improved registration due to stable tension;

Loss tension loss during the strentching process;

No surface treatment,

Heat and moisture;

Abrasion;

Fast printing speeds.

Application for the Polyester Screen Printing Mesh:

Polyester screen printing mesh widely used in Glass printing,touch screen printing,electronic components,packing printing,graphic printing,membrane switch,plastic,metal ,screen printing plate ect..

The precision object printing we can use the stainless steel screen printing mesh,here is the link you could check it.

http://mao.ecer.com/test/domaindemo-30425.tmp/sale-10310675-factory-outlet-low-enlongation-stainless-steel-screen-printing-mesh.html

FAQ for the Polyester Screen Printing Mesh:

A: Can you send us some sample for testing?

B: Sure ,Small sample are available for you,if you need more,please contact me freely.

A: Are you trade company or the manufacturer?

B: We are the manufacturer for this polyester printing mesh,we have the plant on Anping county.we have more than 25 years experience,any problem,you could ask for us,maybe we can help you.

A: Can you please take us to visit your factory?

B: Of caurse,we can take you from the hotel if you are in China living,or we can pick rom you from the air port to dlelivery our factory.

THANK YOU FOR YOUR PRESENCE,LOOKING FORWARD TO YOUR INQUIRY.
