Solar PV Screen Printing Stainless Steel Wire Mesh 500 Micron Mesh
Solar PV Screen Printing Stainless Steel Wire Mesh 500 Micron Mesh
Solar PV Screen Printing Stainless Steel Wire Mesh 500 Micron Mesh
Solar PV Screen Printing Stainless Steel Wire Mesh 500 Micron Mesh
Solar PV Screen Printing Stainless Steel Wire Mesh 500 Micron Mesh
Solar PV Screen Printing Stainless Steel Wire Mesh 500 Micron Mesh
Solar PV Screen Printing Stainless Steel Wire Mesh 500 Micron Mesh
Solar PV Screen Printing Stainless Steel Wire Mesh 500 Micron Mesh
Specifications
Brand Name :
R&K
Model Number :
R&K-Stainless Steel Screen Mesh
Certification :
FDA / SGS / ISO:9001
Place of Origin :
Hebei, China(Mainland)
MOQ :
1meter
Price :
USD 5$-30$ per meter
Supply Ability :
10000 meters per month
Delivery Time :
7-15 days according to your quantity
Packaging Details :
Wrapped with moister-barrier paper, then in wooden cases.Or your requirements.
Weave Style :
Plain Weave
Elasticity :
No
Monofilament :
Yes
Mesh Count :
18 Mesh-420 Mesh
Width :
as your request
Application :
Chemical Industry / Solar Battery
Description

Solar PV Screen Printing Stainless Steel Wire Mesh 500 Micron Mesh

Product Introduction

The polyester yarns passed twice testing before weaving to guarantee the high tension of the silk screen printing mesh.

1 High Flexibility. The wire mesh will not lose elasticity at extreme tension.

2 Super Precision. Uniform wire diameter and aperture with extermely low difference.

3 Low Elongation. Very small elongation of wire mesh at high tension.

4 High tension. Its tension is more higher than common polyester mesh,and this proptery is very stable.

Product Specification

Specification Mesh/
inch		 Wire Dia
(μm)		 Open area
Ratio(%)		 Apereture
(μm)		 Apereture
(μm)		 Calendered Thickness
(μm)		 Theoretical
lnk(cm^/m^)
40*40*160 40 160 56 475 300-320 As order 179.1
60*60*120 60 120 51.3 303 230-245 As order 123.2
80*80*120 80 120 39 198 235-245 As order 92.9
80*80*90 80 90 52 228 175-180 As order 103
80*8*50 80 50 71 268 95-100 As order 78
100*100*100 100 100 36.8 154 195-205 As order 77.2
120*120*80 120 80 39 132 155-165 As order 65.8
150*150*60 150 60 41.7 109 115-124 As order 50
165*165*35 165 35 60 119 70-75 As order 48
165*165*45 165 45 50.1 109 88-93 As order 45.1
165*165*50 165 50 45.6 104 97-105 As order 45.6
180*180*45 180 45 46.4 96 88-93 As order 41.5
180*180*50 180 50 42 91 98-104 As order 41.7
200*200*40 200 40 46.9 87 82-84 As order 43
200*200*50 200 50 37 77 98-103 As order 42
230*230*35 230 35 46.7 75 72-76 50-67 37
250*250*40 250 40 36.8 62 82-86 50-80 34
250*250*30 250 30 49.7 72 64-68 40-58 30
250*250*35 250 35 43 67 76-78 57-70 32
270*270*35 270 35 39.4 59 76-80 58-70 30
300*300*30 300 30 41.7 55 66-68 4-59 28
325*325*30 325 30 38 48 66-68 45-60 24
325*325*28 325 28 41.2 50 63-64 40-56 26.4
325*325*23 325 23 49.8 55 49-53 37-41 25.4
350*350*35 350 25 43 48 52-54 41-50 18.7
400*400*23 400 23 40.7 41 50-54 35-48 19
400*400*18 400 18 51.3 46 36-40 28-30 20
500*500*18 500 18 41.7 33 36-40 23-29 15.3

Product Features

1.Super precisions

2.Extremely low elongation rate

3.High corrosion resistance

4.High tension

5.Non-electrostatic

6.Good heat-melting

7.Many years of research and production experience

8.High quality and export over 50 ountries.

9.High capacity and fast delivery.

Solar PV Screen Printing Stainless Steel Wire Mesh 500 Micron Mesh
