Nylon Screen Printing Mesh Fabirc Plain Weave For T shirt Screen Printing Industry
Nylon Screen Printing Mesh Fabirc Plain Weave For T shirt Screen Printing Industry
Nylon Screen Printing Mesh Fabirc Plain Weave For T shirt Screen Printing Industry
Nylon Screen Printing Mesh Fabirc Plain Weave For T shirt Screen Printing Industry
Nylon Screen Printing Mesh Fabirc Plain Weave For T shirt Screen Printing Industry
Nylon Screen Printing Mesh Fabirc Plain Weave For T shirt Screen Printing Industry
Specifications
Brand Name :
R&K
Model Number :
R&K-F10171
Certification :
FDA
Place of Origin :
Hebei ,China
MOQ :
50 meters
Price :
negotiation
Payment Terms :
L/C , T/T , PaypaL , Trade Assurance , Western Union
Supply Ability :
100000 meters per week
Delivery Time :
3-15 days
Packaging Details :
1.rolled the mesh with paper tube,then in PVC bag,then in carton. 2.Folded the mesh,then in PVC bag,then in cartons
Colour :
White Yellow
Material :
100% nylon
Width :
30m
Weave Type :
Plain
Wire diameter :
31-150um
Length :
25m,30m,50m.custom require available at request
Description
Nylon Screen Printing Mesh Fabirc Plain Weave For T shirt Screen Printing Industry
Descriptions of nylon screen printing mesh:

- Materials: We use imported yarn from Switzerland and Japan. The material must have meet customer's requirement.With imported high quality material,advanced wire mesh instruments and technicicians well trained by Swiss exported,We supply you first class nylon mesh products.
- Mesh count: 10T(25mesh/inch)-165T(420mesh/inch)
- Color: white color,yellow color,and black color
- Width: the max width is 368cm(145") for white color
the max width is 330cm(129") for yellow color
- Package: 1.rolled the mesh with paper tube,then in PVC bag,then in carton.
2.Folded the mesh,then in PVC bag,then in cartons
- Our mainly market for nylon mesh screen printing :

North America (USA, Canada, Mexico),

South America( Braizil, Chile, Argentina, Peru etc.),

European country (Germany, France, Italy,Poland, etc.),

Asia (UAE, Iraq, Iran, Thailand, Vietnam , Malaysia, Turkey, Bangladesh, Pakistan etc.)

Specification
Model Mesh/cm Mesh/inch Aperture
(micron)		 Thread Dia.
(micron)		 Open Area
(%)		 Thickness
(micron)		 Theoretical Ink
(cm3/m2)
10-250 10 25 743 250 55 495 274
12-140 12 30 686 140 68 277 189
13-150 13 33 619 150 64 300 128
16-140 16 40 461 140 58 238 139
21-80 21 55 296 80 69 120 79
21-150 21 55 326 150 46 260 118
22-80 22 56 356 80 66 136 90
24-80 24 60 320 80 63 136 86
24-100 24 60 316 100 57 170 65
28-140 28 70 217 140 40 195 76
32-55 32 80 257 55 67 103 67
32-64 32 80 248 64 63 95 56
32-100 32 80 212 100 46 170 73
36-90 36 92 183 90 44 150 65
39-55 39 100 177 55 56 88 55
43-80 43 110 149 80 41 130 53
47-55 47 120 152 55 51 88 48
48-70 48 122 133 70 41 115 47
53-55 53 135 133 55 50 86 42
54-64 54 137 115 64 39 100 39
54-70 54 137 109 70 35 116 40
61-64 61 155 90 64 31 101 30
64-55 64 160 98 55 38 98 36
64-64 64 160 85 64 30 115 34
68-55 68 175 85 55 34 85 28
68-64 68 175 78 64 28 105 30
72-48 72 182 90 48 36 78 33
72-55 72 182 85 55 30 90 27
80-48 80 200 72 48 33 74 25
90-48 90 230 56 48 25 78 19
100-40 100 255 58 40 33 63 21
110-40 110 280 48 40 27 64 17
120-31 120 305 49 31 35 49 17
120-34 120 305 45 34 30 55 16
130-34 130 330 40 34 27 55 15
140-31 140 355 36 31 26 48 12
140-34 140 355 31 34 20 53 10
150-31 150 380 32 31 23 49 11
150-34 150 380 23 34 13 55 6.5
165-31 165 420 23 31 15 48 7

Note:The above theoretic data is for reference only,and thickness tollerance

Feartures of nylon screen printing mesh:

Low Elongation, High Tension
Excellent Tear Resistance
Very good Dimensional Stability
Improved registration due to stable tension

Dedicated and experienced weavers
Consistent quality products
On time delivery

Reasonable claim refund system

Applications of the nylon screen printing mesh:

Solar battery,
Pinted Circuit Board(PCB),
Chip Electrical components,
Flat Panel Display,
Liquid Crystal Display(LCD),
Plasma Display Panel(PDP) ECT.

Nylon Screen Printing Mesh Fabirc Plain Weave For T shirt Screen Printing Industry
