100% Nylon Material 90/120 Micron Food Grade Nylon Filter Flour Mesh Custom width
100% Nylon Material 90/120 Micron Food Grade Nylon Filter Flour Mesh Custom width
100% Nylon Material 90/120 Micron Food Grade Nylon Filter Flour Mesh Custom width
100% Nylon Material 90/120 Micron Food Grade Nylon Filter Flour Mesh Custom width
100% Nylon Material 90/120 Micron Food Grade Nylon Filter Flour Mesh Custom width
100% Nylon Material 90/120 Micron Food Grade Nylon Filter Flour Mesh Custom width
Specifications
Brand Name :
R&K
Model Number :
R&K-Nylon mesh
Certification :
MSDS,ROSH,SGS,ISO 9001
Place of Origin :
HEBEI ,CHINA
MOQ :
10 meters
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000 Meters per month
Delivery Time :
7~15 days
Packaging Details :
1 Roll/Small Box. 10 Small Boxes/Carton.
Usage :
Liquid Filter
Length :
30-70m/roll
Weave style :
Plain Woven Nylon Mesh
Technique :
Woven
Feature :
Corrosion Resistance
Color :
White
Description

100% Nylon Material 90/120 Micron Food Grade Nylon Filter Flour Mesh Custom width

Product Introduction

Material:FDA food grade commercial nylon mesh

Mesh opening:5-1950 micron

Weave Style:Plain Weave

Thread Diameter:31-550 micron

Monofilament Style:Yes

Thickness:51-1100 micron

Hole Shape:square

Roll length:30-70m or customized

Roll width:1m, 1.25m, 2.5m, 2.95m or customized

Usage:liquid filter, air filter, dust filter

Type:filter mesh, filter cloth, mine sieving mesh, filter disc, filter cylinder

Filter Rating:90%

Nylon mesh is mostly used for filtering. Flour filter, oil filter, etc. Can be widely used in food factories, flour factories, etc.

The term ‘Mono-filament’ means that each thread used in the construction of the cloth is a single smooth solid strand instead of many smaller diameter threads twisted together, as in a spun or multi-filament material. These mono-filament threads are perfectly round in section and are extruded to very precise and uniform diameters.

Product Advantage

1.Due to their uniformity they can be woven with great precision to give exact and regular apertures

2.The resulting material has a very smooth surface so that the filtered particles will easily separate from it
3.They have great strength and elasticity
4. Due to different pore sizes, they can be used in different filtration systems and can be well adapted to each industry.
5. Because the aperture can be made small, it has ultra-high precision. Can be adapted to all filtering applications

Product Features

It has high tension threshold and breaking point​

It has high modulus, low elongation monofilament nylon yarn

It has resist to chemicals, abrasion, heat and moisture

Minimal tension loss during stretching process

Improved registration due to stable fabric tension

Good antistatic

No surface treatment

Product Specification

NL5/1500 5 13 500 1500 1000 308
NL6/1267 6 15 400 1267 840 228
NL7/1079 7 18 350 1079 640 209
NL8/900 8 20 350 900 645 232
NL9/861 9 24 250 861 460 145
NL10/750 10 25 250 750 530 148
NL12/533 12 30 300 533 495 256
NL14/514 14 35 200 514 380 135
NL16/425 16 40 200 425 400 155
NL16/375 16 40 250 375 420 240
NL17/388 17 42 200 388 380 160
NL18/366 18 45 220 366 400 207
NL20/300 20 50 200 300 375 190

Product Advantage

1.Due to their uniformity they can be woven with great precision to give exact and regular apertures

2.The resulting material has a very smooth surface so that the filtered particles will easily separate from it
3.They have great strength and elasticity
4. Due to different pore sizes, they can be used in different filtration systems and can be well adapted to each industry.
5. Because the aperture can be made small, it has ultra-high precision. Can be adapted to all filtering applications
6. Can be stored for a long time, not easily disturbed by external natural factors, can be used as an outdoor protective mesh

100% Nylon Material 90/120 Micron Food Grade Nylon Filter Flour Mesh Custom width
