120 Mesh Plain Weave 100% Polyester Printing Mesh For T - Shirt Pringting
120 Mesh Plain Weave 100% Polyester Printing Mesh For T - Shirt Pringting
120 Mesh Plain Weave 100% Polyester Printing Mesh For T - Shirt Pringting
120 Mesh Plain Weave 100% Polyester Printing Mesh For T - Shirt Pringting
120 Mesh Plain Weave 100% Polyester Printing Mesh For T - Shirt Pringting
120 Mesh Plain Weave 100% Polyester Printing Mesh For T - Shirt Pringting
120 Mesh Plain Weave 100% Polyester Printing Mesh For T - Shirt Pringting
120 Mesh Plain Weave 100% Polyester Printing Mesh For T - Shirt Pringting
Specifications
Brand Name :
R&K
Model Number :
R&K-Polyester mesh
Certification :
FDA / SGS / ISO:9001
Place of Origin :
Hebei, China (Mainland)
MOQ :
1meter
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 Meters per month
Delivery Time :
7-15 days
Packaging Details :
cartons;cases;as your requirement
Width :
43/44"
Style :
Plain
Supply type :
Make-to-Order
Material :
100% Polyester
Yarn count :
75D/144F
Pattern :
Printed
Type :
Mesh Fabric,printing mesh
Technics :
Woven
Description

120mesh Plain Weave Polyester Silk Screen Printing Mesh for t-shirt pringting

Product Details

Product name 120mesh Plain Weave Polyester Silk Screen Printing Mesh for t-shirt pringting
Mesh count 18-420 mesh
Color White & Yellow
Width 127cm, 136cm, 145cm, 155cm, 158cm, 165cm
Thread diameter 31-200 Micron
Mesh opening 24-475 Micron
Thickness 55-365 Micron
Material 100% polyester
Weave type Plain weave
Printing Polyester screen printing

Product Specification

Different mesh sizes are used for different applications in the screen printing process. Mesh size is measured by how many threads of mesh there are crossing per square inch. For instance, a 110 mesh screen has 110 threads crossing per square inch. The higher the mesh count, the finer the threads and holes are in the screen. The size of the mesh has a lot to do with how detailed your image is and how thick the ink you are using is. If you have an image with extremely high detail, a lower mesh screen won’t hold the high detail.

Mesh Count Weaving Thread Diameter Pening Open Area Tension

um

 um % N/cm
10T 1:1PW 250 740 53 60
12T 1:1PW 150 522 47 62
16T 1:1PW 200 435 47 48
16T 1:1PW 100 450 70 48
20T 1:1PW 100 410 68 49
24T 1:1PW 100 323 58 50
24T 1:1PW 120 303 51 48
27T 1:1PW 100 270 58 46
32T 1:1PW 71 230 60 28
32T 1:1PW 64 245 61 28
32T 1:1PW 100 200 43 42
36T 1:1PW 100 182 42 42
39T 1:1PW 55 199 61 32
39T 1:1PW 80 172 46 42
43T 1:1PW 80 151 43 36
47T 1:1PW 55 157 55 32
48T 1:1PW 71 141 44 32
53T 1:1PW 55 133 50 34
55T 1:1PW 55 126 49 32
55T 1:1PW 64 115 39 30
59T 1:1PW 55 101 42 33
64T 1:1PW 55 104 43 33
64T 1:1PW 64 95 36 35
72T 1:1PW 48 96 46 32
72T 1:1PW 55 80 30 32
77T 1:1PW 55 75 28 33
80T 1:1PW 48 78 30 29
90T 1:1PW 48 55 26 32
100T 1:1PW 40 58 32 27
110T 1:1PW 40 48 27 30
120T 1:1PW 34 45 30 26
120T 1:1PW 40 40 20 27
140T 1:1PW 34 32 19 31
150T 1:1PW 34 26 20 31

How to choose

20 and 40 mesh glitter inks that need a very open mesh for printing.
60 mesh printing smaller glitter and most shimmer inks.
80 mesh printing shimmer inks and for laying down thick layers of ink for high-density printing
110 mesh makes printing white and other thick inks easy
120 mesh It works great for printing white ink and other colored inks that have a thicker viscosity.
155 mesh great for general purpose textile printing with basic to semi-fine detail
200 mesh It works very well with thinner inks and is a good middle-range mesh size.
230 mesh great for high-end fine detail printing.
230 mesh can hold halftones very well and also lets a little more ink through then a 305 mesh.
280 mesh great for high-end fine detail printing.
305 mesh holds extremely high detail, letting through only a thin layer of ink. This allows for a very soft hand on the garment and is great for use in printing halftones and process prints.

Product Features

1.High durability and best tensility: all threads are the best domestic or imported.
2.Nice appearance, standard size: all are imported worldly advanced production lines from Switzerland.
3.Clean and never depigment
4. Faster turnaround time from the screen room to the pressroom
5. Good diathermancy
6. High air permeability
7. Acid resistance and Alkali resistance
8. Long working life & Hard wear

FAQ

1.Q: Are you trading company or manufacturer ?

A:We are a manufacturer-trading company integrating production and sales. We have more than 600 employees,more than 600 sets of production and testing equipment.

2.Q:Q: Do you have any certifications?

A:A: Yes, we have IS09001, FDA, ROSH, SGS to guarantee the product's quality, so you can totally truth us.

3.Q: Do you provide samples ?

A:We can provide samples to you for free but you have to pay the cost of freight.

4.Q: What is your terms of payment ?

A:A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
