304 30m/Roll Stainless Steel Woven Wire Mesh Filter Strainer
304 30m/Roll Stainless Steel Woven Wire Mesh Filter Strainer
304 30m/Roll Stainless Steel Woven Wire Mesh Filter Strainer
304 30m/Roll Stainless Steel Woven Wire Mesh Filter Strainer
304 30m/Roll Stainless Steel Woven Wire Mesh Filter Strainer
304 30m/Roll Stainless Steel Woven Wire Mesh Filter Strainer
Specifications
Brand Name :
R&K
Model Number :
SS-11
Certification :
SGS
Place of Origin :
Hebei
MOQ :
1 squaremeter
Price :
Negotiate
Payment Terms :
L/C, D/P, T/T, Western Union，PayPal
Supply Ability :
1000 squaremeter per week
Delivery Time :
5-8 workday
Packaging Details :
inside with paper tube,Then waterproof paper covered,Finally in a wooden case or pallet
Material :
304 stainless steel
Usage :
Filter
Weave style :
Plain weave
Mesh Count :
60 mesh
Color :
Silver
Advantage :
High strength
Product name :
Stainless Steel Woven Wire Mesh
Technique :
Woven
Application :
Woven Wire Mesh,Filters
Length :
30m/roll 50m/roll or as required
Description

304 food grade stainless steel woven wire mesh for filter strainer

Description

According to the material, it can be divided into 304 stainless steel wire mesh. The 316 stainless steel wire mesh has 80 mesh stainless steel wire mesh according to the mesh number. The 100 mesh stainless steel wire mesh requires production and processing. Surface treatment: electrolytic polishing, epoxy resin, electrostatic spraying, metal plating, ultrasonic spraying, etc. Features of stainless steel wire mesh: good acid resistance, alkali resistance and rust resistance; high strength, strong tensile, toughness and wear resistance, durable; high temperature oxidation resistance, normal temperature processing, ie easy plastic processing, making the use of stainless steel screen possible Sexual diversification; high finish, no need to surface treatment of cooking wine, salt cans, equipment and dressings, strong etched sulfuric acid medium 904L is a matching steel grade

Many different grades of stainless steel are used for wire mesh. 304, 304L, 316, 316L are the most common, and others are used for specific applications to take advantage of the unique attributes of each level.

Stainless steel mesh according to weaving classification:

1, plain weave

2, twill weave

3. stainless steel wire mesh, split plain weave. Twill weave, stainless steel wire mesh size 20 mesh - 630 mesh. Material: SUS304, 304l, SUS316, SUS316L, 31 0, 310S, SUS302, etc.

Feature of stainless steel mesh

Stainless steel is resistant to high temperatures, acids, corrosion and abrasion. Because of these characteristics, stainless steel mesh is widely used in mining, chemical, food, petroleum, pharmaceutical, etc., mainly used for gas, liquid filter and other media separation.

For the oxidizing acid, it was found in the experiment that the 304 stainless steel wire mesh has strong corrosion resistance in the nitric acid below the boiling temperature of ≤ 65%. It also has good corrosion resistance to alkaline solutions and most organic and inorganic acids.

Uses: for sieving and filtration under acid and alkali conditions

Feature of stainless steel mesh

Stainless steel is resistant to high temperatures, acids, corrosion and abrasion. Because of these characteristics, stainless steel mesh is widely used in mining, chemical, food, petroleum, pharmaceutical, etc., mainly used for gas, liquid filter and other media separation.

For the oxidizing acid, it was found in the experiment that the 304 stainless steel wire mesh has strong corrosion resistance in the nitric acid below the boiling temperature of ≤ 65%. It also has good corrosion resistance to alkaline solutions and most organic and inorganic acids.

Uses: for sieving and filtration under acid and alkali conditions

Parameter of stainless steel mesh

mesh Wire Diameter Aperture Open Area Weight
Inch MM Inch MM (%) (kg /Square meter)
1x1 0.08 2.03 0.92 23.37 92 2
2X2 0.063 1.6 0.437 11.1 87.4 2.5
3X3 0.054 1.37 0.279 7.09 83.8 2.7
4X4 0.047 1.19 0.203 5.16 81.2 2.7
5X5 0.041 1.04 0.159 4.04 79.5 2.6
8X8 0.02 0.5 0.105 2.675 71 1
9X9 0.02 0.5 0.091 2.32 67.7 1.1
10X10 0.025 0.64 0.075 1.91 74.9 2
12X12 0.02 0.508 0.063 1.6 75.9 1.5
12X12 0.022 0.55 0.062 1.567 54.8 1.815
14X14 0.02 0.508 0.051 1.3 71.9 1.8
14X14 0.0177 0.45 0.054 1.36 75.14 1.417
16X16 0.016 0.4 0.047 1.188 55 1.28
16X16 0.018 0.457 0.0445 1.13 71.2 1.6
18X18 0.017 0.432 0.0386 0.98 69.4 1.6
20X20 0.02 0.24 0.03 0.76 76 0.56
20X20 0.016 0.33 0.034 0.86 72.2 1.1
20X20 0.014 0.35 0.036 0.92 52.5 1.225
20X20 0.016 0.4 0.034 0.87 46.9 1.6
20X20 0.0177 0.45 0.0322 0.82 41.7 2.025
22X22 0.012 0.3 0.034 0.854 54.76 0.99
24X24 0.014 0.35 0.028 0.708 44.77 1.47
30X30 0.014 0.35 0.0195 0.5 34.6 1.84
30X30 0.012 0.305 0.0213 0.54 63.9 1.4
30X30 0.0094 0.24 0.0243 0.62 72.1 0.84
35X35 0.0079 0.2 0.021 0.526 52.5 0.7
35X35 0.0098 0.25 0.0187 0.475 42.92 1.09
40X40 0.0079 0.2 0.017 0.435 46.9 0.8
40X40 0.01 0.254 0.015 0.38 59.9 1.3
40X40 0.014 0.35 0.011 0.285 20.14 2.45
50X50 0.0055 0.14 0.0145 0.368 72.4 0.48
50X50 0.0079 0.2 0.012 0.308 36.76 1
60X60 0.0047 0.12 0.012 0.303 71.6 0.42
60X60 0.0059 0.15 0.0107 0.273 64.5 0.65
60X60 0.007 0.18 0.0096 0.243 33 0.972
80X80 0.047 0.12 0.0078 0.1975 38.7 0.576
80X80 0.0055 0.14 0.0069 0.117 45.5 0.76
100X100 0.0039 0.1 0.006 0.154 36.76 0.5
100X100 0.0045 0.114 0.0055 0.14 55.1 0.59
100X100 0.004 0.102 0.006 0.152 59.8 0.49
120X120 0.0028 0.07 0.0057 0.147 67.7 0.29
120X120 0.003 0.08 0.0052 0.132 38.7 0.384
150X150 0.0024 0.06 0.0043 0.11 64.7 0.26
150X150 0.0028 0.07 0.0039 0.1 58.8 0.38
165X165 0.0019 0.05 0.0041 0.104 67.5 0.2
180X180 0.0019 0.05 0.0035 0.091 64.5 0.22
180X180 0.0024 0.06 0.0031 0.081 57.4 0.32
200X200 0.0019 0.05 0.003 0.077 60.6 0.24
200X200 0.0024 0.06 0.0026 0.067 52.7 0.35
250X250 0.0016 0.04 0.0024 0.0616 60.6 0.2
270X270 0.0016 0.04 0.0021 0.054 57.4 0.21
300X300 0.0016 0.04 0.0018 0.045 53.5 0.23
325X325 0.0014 0.035 0.0017 0.0432 55.3 0.2
400X400 0.0012 0.03 0.0013 0.0335 52.7 0.18
500X500 0.0009 0.025 0.001 0.0258 50.7 0.15
500X500 0.0012 0.03 0.0008 0.0208 16.76 0.225
635X635 0.0007 0.018 0.0008 0.022 55 0.1

304 30m/Roll Stainless Steel Woven Wire Mesh Filter Strainer
