310S Plain Weave 4X4 Stainless Steel Woven Mesh Coffee Filter
310S Plain Weave 4X4 Stainless Steel Woven Mesh Coffee Filter
310S Plain Weave 4X4 Stainless Steel Woven Mesh Coffee Filter
310S Plain Weave 4X4 Stainless Steel Woven Mesh Coffee Filter
310S Plain Weave 4X4 Stainless Steel Woven Mesh Coffee Filter
310S Plain Weave 4X4 Stainless Steel Woven Mesh Coffee Filter
Specifications
Brand Name :
R&K
Model Number :
SS-15
Certification :
SGS
Place of Origin :
Hebei
MOQ :
1 squaremeter
Price :
Negotiate
Payment Terms :
L/C, D/P, T/T, Western Union，PayPal
Supply Ability :
1000 squaremeter per week
Delivery Time :
5-8 workday
Packaging Details :
inside with paper tube,Then waterproof paper covered,Finally in a wooden case or pallet
Usage :
Filter
Weave style :
Plain weave
Mesh Count :
60 mesh
Color :
Silver
Advantage :
High strength
Product name :
Square 4X4 Woven Flour 100 Micron Stainless Steel Wire Mesh
Type :
Weave Wire Mesh
Application :
Woven Wire Mesh
Description

60 Mesh Stainless Steel Woven Wire Mesh High Strength Coffee Filter

Description of the stainless steel wire mesh

Filter cloth is a woven wire mesh product known for its excellent durability. The filter cloth consists of a sturdy, heavy warp thread that is ideal for demanding screening and filtration applications. It is also the best choice for separating slurry and liquid materials. We offer a wide range of woven fabrics including Plain Dutch, Twilled Dutch and Reverse Plain Dutch.

Technical Description:

Standard width stainless steel wire mesh: 1 or 48 inches; stainless steel wire mesh with an additional roll width of 4 meters is also available.

Stainless steel wire mesh with standard roll length: 30 m or 100'.

Plain weave description:
Plain weave is a commonly used weaving method. The warp, the length of the wire mesh and the weft are determined, parallel to the width, intersecting each other, alternating one at the top and below, forming a 90° angle with each other.
The solid woven wire mesh can have a square or rectangular opening.

Plain weave mesh clothing is a basic component of filters, food colanders, chemicals, shielding, mosquito nets and other production.

Wire:
Stainless steel wire: Aisi 304, 304L, 316, 316L, 310, 314, 410, 430.
Special steel: Cromax, Incoloy, alloy nickel-chromium alloy, inconel, Nikkor, Monel, titanium alloy, duplex steel.

Stainless steel mesh according to weaving classification:

1. plain weave

2. twill weave

3. stainless steel wire mesh, split plain weave. Twill weave, stainless steel wire mesh size 20 mesh - 630 mesh. Material: SUS304, 304l, SUS316, SUS316L, 31 0, 310S, SUS302, etc.

Feature of stainless steel mesh

Stainless steel is resistant to high temperatures, acids, corrosion and abrasion. Because of these characteristics, stainless steel mesh is widely used in mining, chemical, food, petroleum, pharmaceutical, etc., mainly used for gas, liquid filter and other media separation.

Stainless steel is resistant to high temperatures, acids, corrosion and abrasion. Because of these characteristics, stainless steel mesh is widely used in mining, chemical, food, petroleum, pharmaceutical, etc., mainly used for gas, liquid filter and other media separation.

Parameter of stainless steel mesh

mesh Wire Diameter Aperture Open Area Weight
Inch MM Inch MM (%) (kg /Square meter)
1x1 0.08 2.03 0.92 23.37 92 2
2X2 0.063 1.6 0.437 11.1 87.4 2.5
3X3 0.054 1.37 0.279 7.09 83.8 2.7
4X4 0.047 1.19 0.203 5.16 81.2 2.7
5X5 0.041 1.04 0.159 4.04 79.5 2.6
8X8 0.02 0.5 0.105 2.675 71 1
9X9 0.02 0.5 0.091 2.32 67.7 1.1
10X10 0.025 0.64 0.075 1.91 74.9 2
12X12 0.02 0.508 0.063 1.6 75.9 1.5
12X12 0.022 0.55 0.062 1.567 54.8 1.815
14X14 0.02 0.508 0.051 1.3 71.9 1.8
14X14 0.0177 0.45 0.054 1.36 75.14 1.417
16X16 0.016 0.4 0.047 1.188 55 1.28
16X16 0.018 0.457 0.0445 1.13 71.2 1.6
18X18 0.017 0.432 0.0386 0.98 69.4 1.6
20X20 0.02 0.24 0.03 0.76 76 0.56
20X20 0.016 0.33 0.034 0.86 72.2 1.1
20X20 0.014 0.35 0.036 0.92 52.5 1.225
20X20 0.016 0.4 0.034 0.87 46.9 1.6
20X20 0.0177 0.45 0.0322 0.82 41.7 2.025
22X22 0.012 0.3 0.034 0.854 54.76 0.99
24X24 0.014 0.35 0.028 0.708 44.77 1.47
30X30 0.014 0.35 0.0195 0.5 34.6 1.84
30X30 0.012 0.305 0.0213 0.54 63.9 1.4
30X30 0.0094 0.24 0.0243 0.62 72.1 0.84
35X35 0.0079 0.2 0.021 0.526 52.5 0.7
35X35 0.0098 0.25 0.0187 0.475 42.92 1.09
40X40 0.0079 0.2 0.017 0.435 46.9 0.8
40X40 0.01 0.254 0.015 0.38 59.9 1.3
40X40 0.014 0.35 0.011 0.285 20.14 2.45
50X50 0.0055 0.14 0.0145 0.368 72.4 0.48
50X50 0.0079 0.2 0.012 0.308 36.76 1
60X60 0.0047 0.12 0.012 0.303 71.6 0.42
60X60 0.0059 0.15 0.0107 0.273 64.5 0.65
60X60 0.007 0.18 0.0096 0.243 33 0.972
80X80 0.047 0.12 0.0078 0.1975 38.7 0.576
80X80 0.0055 0.14 0.0069 0.117 45.5 0.76
100X100 0.0039 0.1 0.006 0.154 36.76 0.5
100X100 0.0045 0.114 0.0055 0.14 55.1 0.59
100X100 0.004 0.102 0.006 0.152 59.8 0.49
120X120 0.0028 0.07 0.0057 0.147 67.7 0.29
120X120 0.003 0.08 0.0052 0.132 38.7 0.384
150X150 0.0024 0.06 0.0043 0.11 64.7 0.26
150X150 0.0028 0.07 0.0039 0.1 58.8 0.38
165X165 0.0019 0.05 0.0041 0.104 67.5 0.2
180X180 0.0019 0.05 0.0035 0.091 64.5 0.22
180X180 0.0024 0.06 0.0031 0.081 57.4 0.32
200X200 0.0019 0.05 0.003 0.077 60.6 0.24
200X200 0.0024 0.06 0.0026 0.067 52.7 0.35
250X250 0.0016 0.04 0.0024 0.0616 60.6 0.2
270X270 0.0016 0.04 0.0021 0.054 57.4 0.21
300X300 0.0016 0.04 0.0018 0.045 53.5 0.23
325X325 0.0014 0.035 0.0017 0.0432 55.3 0.2
400X400 0.0012 0.03 0.0013 0.0335 52.7 0.18
500X500 0.0009 0.025 0.001 0.0258 50.7 0.15
500X500 0.0012 0.03 0.0008 0.0208 16.76 0.225
635X635 0.0007 0.018 0.0008 0.022 55 0.1

310S Plain Weave 4X4 Stainless Steel Woven Mesh Coffee Filter
