Yellow Monofilament Polyester Silk Screen Printing Mesh 39t 168t 80 380 420
Yellow Monofilament Polyester Silk Screen Printing Mesh 39t 168t 80 380 420
Yellow Monofilament Polyester Silk Screen Printing Mesh 39t 168t 80 380 420
Yellow Monofilament Polyester Silk Screen Printing Mesh 39t 168t 80 380 420
Yellow Monofilament Polyester Silk Screen Printing Mesh 39t 168t 80 380 420
Yellow Monofilament Polyester Silk Screen Printing Mesh 39t 168t 80 380 420
Specifications
Brand Name :
R&K
Model Number :
J801
Certification :
SGS， ISO 9001
Place of Origin :
Hebei , China
MOQ :
50 Meter/Meters Thermal Screen Printing Mesh
Price :
negotiation
Payment Terms :
L/C,T/T,Paypal, Western Union,Trade Assurance.
Supply Ability :
15000 Meter/Meters per Week Thermal Screen Printing Mesh
Delivery Time :
3-10 days
Packaging Details :
in cartons,plastic film packaging or as customer's request
Mesh count :
39t 168t 80 380 420r
name :
39t 168t 80 380 420 yellow monofilament polyester silkscreen printing mesh
Thermal screen printing mesh Roll width :
1M-3.9M
length :
50m 100m,200m
Thread diameter :
40 micron
Aperture size :
59 - 60 micron
Description

Thermal Polyester Bolting Cloth Screen Printing Mesh 41 Inch White Color​

Description of the polyester thermal printing mesh:

Hebei Reking polyester thermoset fabric is woven from an imported weaving machine. Swiss Sulzer grip weaving machine, Swedish Jaguar BK600 weaving machine, Germany Babcock heat setting machine, WIS SC-3 automatic insertion machine, Japan imported RGK-1300 METAL WIRE MESH automatic loom, Kyoto RD automatic pressure Optical machines, the world's most advanced wire mesh production equipment and some household equipment support the association at the level of production equipment and technical equipment.

Specification For Thermal Screen Printing Mesh:

Mesh Count Diameter (Mesh/cm um) Mesh Count (Mesh/inch) Weave Aperture (um) Thread Diameter (um) Opening (%) Thickness (um) Thickness Tollerance (+/- um)
165-31PW(S) 420 1:1 23 31 15 48 2
150-34PW(T) 380 1:1 23 34 13 55 3
150-31PW(S) 380 1:1 32 31 23 49 3
140-34TW(T) 355 2:1 33 34 21 56 3
140-34PW(T) 355 1:1 31 34 20 53 3
140-31PW(S) 355 1:1 36 31 26 48 2
130-34PW(T) 330 1:1 40 34 27 55 3
120-40PW(HD) 305 1:1 37 40 20 63 3
120-34PW(T) 305 1:1 45 34 30 55 3
120-31PW(S) 305 1:1 49 31 35 49 3
110-40PW(HD) 280 1:1 48 40 27 64 3
100-40PW(T) 255 1:1 58 40 33 63 3
90-48PW(T) 230 1:1 56 48 25 78 4
80-48PW(T) 200 1:1 72 48 33 74 4
77-55PW(T) 195 1:1 67 55 27 88 4
77-48PW(S) 195 1:1 77 48 35 80 4
72-55PW(T) 182 1:1 85 55 30 90 5
72-48PW(S) 182 1:1 90 48 36 78 5
68-64PW(T) 175 1:1 78 64 28 105 5
68-55PW(S) 175 1:1 85 55 34 85 4
64-64PW(T) 160 1:1 85 64 30 115 6
64-55PW(S) 160 1:1 98 55 38 98 5
61-64PW(T) 155 1:1 90 64 31 101 5
54-70PW(HD) 137 1:1 109 70 35 116 6
54-64PW(T) 137 1:1 115 64 39 100 5
53-55PW(S) 135 1:1 133 55 50 86 6
53-45PW(S) 135 2:2 143 45*2 57 79 7
48-70PW(T) 122 1:1 133 70 41 115 6
47-55PW(S) 120 1:1 152 55 51 88 6
43-80PW(T) 110 1:1 149 80 41 130 7
40-80PW(T) 103 1:1 166 80 44 133 7
39-55PW(S) 100 1:1 177 55 56 88 6
36-90PW(T) 92 1:1 183 90 44 150 8
32-100PW(T) 81 1:1 212 100 45 165 8
32-64PW(S) 81 1:1 248 64 63 95 6
32-55PW(S) 81 1:1 257 55 67 103 6
28-140PW(SL) 70 1:1 217 140 40 195 13
24-100PW(T) 60 1:1 316 100 57 136 11
21-150PW(SL) 55 1:1 326 150 46 260 14
21-80PW(S) 55 1:1 296 80 69 120 9
13-150PW(SL) 33 1:1 619 150 64 300 14
PW:TW:SL；S,T,HD PW:(Plain Weave);TW:(Twill Weave); S,T,HD:(thickness of Mesh) Standard Color: white and yellow, other colors on request.

Features For Thermal Screen Printing Mesh:

  • Wear resistance;
  • No surface treatment;
  • Low elongation;
  • The registration is improved because of the stable tension.
  • Fast printing speed;
  • Stable tension;
  • Improve fabric strength;:

Application of the screen printing mesh:

Polyester Screen Printing Mesh is widely used in Textile printing,T-shirt printing,ceramic printing,glass printing and PCB printing industry.
