Durable 25 Micron Dpp Plain Weave Silk Mesh For Screen Printing / Textile Printing
Durable 25 Micron Dpp Plain Weave Silk Mesh For Screen Printing / Textile Printing
Durable 25 Micron Dpp Plain Weave Silk Mesh For Screen Printing / Textile Printing
Durable 25 Micron Dpp Plain Weave Silk Mesh For Screen Printing / Textile Printing
Specifications
Brand Name :
R&K
Model Number :
J 685
Certification :
ISO9001,FDA
Place of Origin :
HEBEI CHINA
MOQ :
1 square meter
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union,PayPal,Credit Card,T/A
Supply Ability :
2000 square meters per day
Delivery Time :
5-8 days
Packaging Details :
carton box, or ask your request
Material :
100% polyester
Nylon Mesh :
120 mesh
Name :
durable 25 micron dpp plain weave polyester printing silk screen mesh for textile printing
Monofilament style :
Yes
Printing :
Polyester Screen Printing,Silk Screen Printing
Mesh count :
18mesh-420mesh
Description

Durable 25 Micron Dpp Plain Weave Silk Mesh For Screen Printing / Textile Printing



Descriptions of the mesh:


Screen printing is widely used in the decoration of fine porcelain dishes, ceramic tiles, and pottery, which can be printed on challenging intense colors and home decoration.
In the ceramic industry, polyester printing screens have a line count of 36 to 165 lines / cm (90 to 420 mesh / inch) and are used in porcelain and handicrafts as well as other excellent Chinese
Polyester screen printing mesh is a printing fabric that we widely use,
Can be used for graphic printing, apparel printing, textile and flat film applications according to customer requirements or different

We are factory of polyester screen printing mesh, nylon screen printing mesh,monofilament screen printing mesh.
Specification from 10T to 180T.wide from 50cm to 3.7m.

We have white yellow black orange colors. All can made as your required specifcation. Tension is high can used for pcb. glass,bottle.ceramic.VCD.DVD. textile and cloth printing.

Brand Name:R&K
Place of Origin:China
Quality Inspection:ISO9001 FDA SGS
Port:Xingang, Tianjin
Minimum Order Quantity: 1m
Supply Ability:50000m per month
Payment Terms.L/C.T/T.paypal:western union.Ali express

Material 100 % polyester
Mesh 120 mesh
Color white,yellow
MOQ 1 aquare meterl


Specifications of the polyester mesh:

Mesh Count
Diameter
(Mesh/inch μm)		 Mesh Count
(Mesh/Inch)		 Weave Aperture(μm)

Thread Diameter(μm)

Opening(%)

 Thickness(μm) Thickness
Tollerance
(+/- μm)		 Theoretical
lnk(cm3/m2)		 Weight
(g/m2)
32-64PW(S) 81 1:1 248 64 63 95 6 56 32
54-70(PW)HD 137 1:1 109 70 35 116 6 40 62
61-64PW(T) 155 1:1 90 64 31 101 5 30 58
64-55PW(S) 160 1:1 98 55 38 98 5 36 48
68-64PW(T) 175 1:1 78 64 28 105 5 30 65
72-48PW(S) 182 1:1 90 48 36 78 5 33 39
72-55PW(T) 182 1:1 85 55 30 90 5 27 51
77-48PW(S) 195 1:1 77 48 35 80 4 28 42
77-55PW(T) 195 1:1 67 55 27 88 4 24 55
80-48PW(T) 200 1:1 72 48 33 74 4 25 56
90-48PW(T) 230 1:1 56 48 25 78 4 19 50
100-40PW(T) 255 1:1 58 40 33 63 3 21 37
110-40PW(HD) 280 1:1 48 40 27 64 3 17 40
120-31PW(S) 305 1:1 49 31 35 49 3 17 26
120-34PW(T) 305 1:1 45 34 30 55 3 16 35
120-40PW(HD) 305 1:1 37 40 20 63 3 13 44
130-34PW(T) 330 1:1 40 34 27 55 3 15 37


Adavantages of the polyester mesh:

Faster tensioning without damage to the threads,
Improved fabric strength;
Faster tension stabilization;
Higher tension threshold and breaking point:
L ess tension loss during the stretching process:
Faster turnaround time from the screen room to the pressroom;
Improved registration due to stable tension;
Faster printing speeds.


Application of the polyester mesh:

CD/DVD Printing,
Ceramic Decorating,
Graphic Screen Printing, Package Printing.
Printed Electronics.
Printing on Glass.
Solar Cell Printing,
Textile Printing, etc.
