Silver Color Stainless Steel Filter Wire Mesh / Stainless Steel Micro Mesh Screen
Silver Color Stainless Steel Filter Wire Mesh / Stainless Steel Micro Mesh Screen
Silver Color Stainless Steel Filter Wire Mesh / Stainless Steel Micro Mesh Screen
Silver Color Stainless Steel Filter Wire Mesh / Stainless Steel Micro Mesh Screen
Specifications
Brand Name :
R&K
Model Number :
R&K-TH
Certification :
FDA
Place of Origin :
Hebei,China
MOQ :
50 meters
Price :
negotiation
Payment Terms :
L/C，T/T，Western Union，Paypal，Trade assurance
Supply Ability :
2000 square meter per month
Delivery Time :
Within 8 work days
Packaging Details :
Waterproof,woven bags inside,carton or plywood case outside.
Product name :
304 316 corrosion resistant 300 400 micron stainless steel screen printing mesh material
Color :
Silver
Application :
Kinds Filtration Industry
width :
1m
Weave style :
Plain weave.
hole size :
300,400 micron
Description

Silver Color Stainless Steel Filter Wire Mesh / Stainless Steel Micro Mesh Screen

Description of stainless steel screen mesh:

Material SUS304,304L,316,316L
Hole Shape Square
Width 1.0-1.5m
size per roll usually 1meter or 1.2meter wide,30meter per roll
wire diameter Min diameter is0.018mm
aperture size Min is 1Micron

Stainless steel filter wire mesh refers to stainless woven wire mesh used in filter liquid,gas and pulp.The opening can be square, rectangular or special opening.Normally,this kind of wire mesh has standard opening sizes,uniform opening, good permeability and high strength. The raw materials should be chosen according to different environments of applications.

Features of stainless steel wire mesh:

  • Acid and alkali resistant
  • Corrosion resistant
  • Abrasion resistance, durable
  • Easy to plastic processing, so that the possibility of the use of stainless steel screens diversified
  • High finish, no surface treatment, maintenance is simple
  • Standard size,uniform opening,Precise control fiter rating etc

Application of stainless steel mesh roll :

stainless steel filter wire mesh is used in petroleum,chemical industry,chemical fiber, food

,medicine,fertilizer,paper-making,airspace.

Specification:

Specification Mesh/
inch		 Wire Dia
(μm)		 Open area
Ratio(%)		 Apereture
(μm)		 Apereture
(μm)		 Calendered Thickness
(μm)		 Theoretical
lnk(cm^/m^)
40×40×160 40 160 56 475 300-320 As order 179.1
60×60×120 60 120 51.3 303 230-245 As order 123.2
80×80×120 80 120 39 198 235-245 As order 92.9
80×80×90 80 90 52 228 175-180 As order 103
80×8×50 80 50 71 268 95-100 As order 78
100×100×100 100 100 36.8 154 195-205 As order 77.2
120×120×80 120 80 39 132 155-165 As order 65.8
150×150×60 150 60 41.7 109 115-124 As order 50
165×165×35 165 35 60 119 70-75 As order 48
165×165×45 165 45 50.1 109 88-93 As order 45.1
165×165×50 165 50 45.6 104 97-105 As order 45.6
180×180×45 180 45 46.4 96 88-93 As order 41.5
180×180×50 180 50 42 91 98-104 As order 41.7
200×200×40 200 40 46.9 87 82-84 As order 43
200×200×50 200 50 37 77 98-103 As order 42
230×230×35 230 35 46.7 75 72-76 50-67 37
250×250×40 250 40 36.8 62 82-86 50-80 34
250×250×30 250 30 49.7 72 64-68 40-58 30
250×250×35 250 35 43 67 76-78 57-70 32
270×270×35 270 35 39.4 59 76-80 58-70 30
300×300×30 300 30 41.7 55 66-68 4-59 28
325×325×30 325 30 38 48 66-68 45-60 24
325×325×28 325 28 41.2 50 63-64 40-56 26.4
325×325×23 325 23 49.8 55 49-53 37-41 25.4
350×350×35 350 25 43 48 52-54 41-50 18.7
400×400×23 400 23 40.7 41 50-54 35-48 19
400×400×18 400 18 51.3 46 36-40 28-30 20
500×500×18 500 18 41.7 33 36-40 23-29 15.3

Silver Color Stainless Steel Filter Wire Mesh / Stainless Steel Micro Mesh ScreenSilver Color Stainless Steel Filter Wire Mesh / Stainless Steel Micro Mesh Screen
