40 Micron Monofilament White Plain Weave FDA Nylon Filter Mesh For Filtration
40 Micron Monofilament White Plain Weave FDA Nylon Filter Mesh For Filtration
Specifications
Brand Name :
R&K
Model Number :
R&K-Nylon mesh
Certification :
FDA,ISO9000,SGS
Place of Origin :
Hebei, China(Mainland)
MOQ :
100meters
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000 Meters per month
Delivery Time :
7~15 days
Packaging Details :
1.30-70m/roll in PVC bag 2 2-8 rolls per carton 3.waterproof bags outside 4.package belt strengthen
Material :
Nylon
Hole shape :
Square
Length :
30-70m/roll
Application :
air filter,filtration
Shape :
Customers' Request
Description

40 Micron White Plain Weave Nylon Filter Mesh For Filtration

Product Introduction

Material:FDA food grade commercial nylon mesh
Mesh opening:5-1950 micron
Weave Style:Plain Weave
Thread Diameter:31-550 micron
Monofilament Style:Yes
Thickness:51-1100 micron
Hole Shape:square
Roll length:30-70m or customized
Roll width:1m, 1.25m, 2.5m, 2.95m or customized
Usage:liquid filter, air filter, dust filter
Type:filter mesh, filter cloth, mine sieving mesh, filter disc, filter cylinder


Product Features

It has high tension threshold and breaking point​

It has high modulus, low elongation monofilament nylon yarn

It has resist to chemicals, abrasion, heat and moisture
It can achieve Minimal tension loss during stretching process
Good Improved registration due to stable fabric tension
It has Good antistatic

No surface treatment, can be customized according to customer requirements




Product Advantage

They have good acid resistance and alkali resistance and are not easily corroded
Due to their uniformity they can be woven with great precision to give exact and regular apertures
The resulting material has a very smooth surface so that the filtered particles will easily separate from it
They have great strength and elasticity
Due to different pore sizes, they can be used in different filtration systems and can be well adapted to each industry.
Because the aperture can be made small, it has ultra-high precision. Can be adapted to all filtering applications
Has good antistatic properties



Product Specification

Material:100 % polyamide yarn
Mesh count: 200 mesh per inch
Mesh opening: 75 micron
Mesh range:13mesh - 500 mesh
Weave style of 200 mesh :plain weave
Color:white is popular,we also can make accept pink,purple color. custom-made is abailable.
Thickness:51-1100 micron
Hole Shape:square


Product Package

1. We always use poly bag for the goods which ship by air, so that customer can save freight free
2. Wooden case is the best for ocean shipment, because it can effective avoid the damage during shipping
3. There also have some customer request us to use the carton to packing their goods
4. We can according to customer's requirements

Product Characteristic

Non-toxic,odorless,tasteless,high strength,high elongtation
wear resistant ,high strength,good filtration(high air permeability)
Certificate: FDA,ROSH,MSDS...
Service long life time.
Bulk mesh in stock.
sample are available for you.
Custom-make.(quantity,color, width and so on,as your request)
we are the big stable factory,welcome you to visit our plant.

How to choose

Mesh Count is the number of threads per inch in the direction of warp and weft of the fabric.The mesh count is indentical in both warp and weft direction for Share Fitration's woven mesh.

Thread Diameter is specified as the diameter of the thread in microns.Yarn sizes in both warp and weft directions are the same.

Mesh Opening is the size or space between threads.The mesh opening is the result of the combination of the mesh count and yarn size.Mesh opening will determine the size or amount of material that will pass through the fabric.


Photo show

40 Micron Monofilament White Plain Weave FDA Nylon Filter Mesh For Filtration
