Acid Resistance 420 Mesh Silk Screen Mesh Fabric High Air Permeability
Acid Resistance 420 Mesh Silk Screen Mesh Fabric High Air Permeability
Acid Resistance 420 Mesh Silk Screen Mesh Fabric High Air Permeability
Acid Resistance 420 Mesh Silk Screen Mesh Fabric High Air Permeability
Specifications
Brand Name :
R&K
Model Number :
R&K-Polyester Mesh
Certification :
FDA / SGS / ISO:9001
Place of Origin :
Hebei, China (Mainland)
MOQ :
1 meter
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000 Meters per month
Delivery Time :
7~15 days
Packaging Details :
cartons;cases;as your requirement
Weave type :
Plain
Monofilament style :
Yes
Printing :
Silk Screen Printing
Material :
Polyester
Mesh count :
420 mesh
Length :
50m , 100m
Description

420 Mesh Yellow Color High air permeability Polyester Silk Screen Printing Mesh

Product Introduction

The polyester printing screen has a variety of mesh numbers, which can meet all the requirements and precision of screen printing. It is widely used in the printing of automobile glass, household appliance glass and various special-shaped bottles. In the production of glass screen printing, it has the highest efficiency and repeatability. Suitable for various screen printing machines and different printing inks. Polyester printing screen can provide customized services for template manufacturers and solar panel printers. During use, the production cost and production loss of glass printing will be reduced. Therefore, the polyester printing screen of Hebei Ruijin Screen's polyester screen is price-competitive and can help you occupy more markets in the local market.

Product Details

Material 100% polyester
Product name 420 Mesh Yellow Color High air permeability Polyester Silk Screen Printing Mesh
Mesh count 40-420mesh
Keyword Silk Screen Printing Mesh
Color yellow
Thread Diameter 30-150micron
Weave style Plain weave

Product specification

Mesh Count
Diameter
(Mesh/inch μm)		 Mesh
Count
(Mesh
/Inch)		 Weave Aperture
(μm)		 Thread
Diameter
(μm)		 Opening
(%)		 Thickness(μm) Thickness
Tollerance
(+/- μm)		 Theoretical
lnk(cm3/m2)		 Weight
(g/m2)
12-250 30 1:1 583 250 49 490 20 228 117
13-150PW(SL) 33 1:1 619 150 64 300 14 128 60
16-200 40 1:1 425 200 46 400 18 172 148
20-120PW(T) 50 1:1 380 120 58 210 11 122 76
21-80pw(S) 55 1:1 296 80 69 120 9 79 35
21-150PW(SL) 55 1:1 326 150 46 260 14 118 121
24-100PW(T) 60 1:1 316 100 57 136 11 65 81
28-140PW(SL) 70 1:1 217 140 40 195 13 76 125
32-55PW(S) 81 1:1 257 55 67 103 6 67 28
32-64PW(S) 81 1:1 248 64 63 95 6 56 32
32-100PW(T) 81 1:1 212 100 45 165 8 73 75
36-90PW(T) 92 1:1 183 90 44 150 8 65 68
39-55PW(S) 100 1:1 177 55 56 88 6 55 30
40-80PW(T) 103 1:1 166 80 44 133 7 59 60
43-80PW(T) 110 1:1 149 80 41 130 7 53 64
47-45PW(S) 120 1:1 166 45*2 61 80 6 42 40
47-55PW(S) 120 1:1 152 55 51 88 6 48 34
48-70PW(T) 122 1:1 133 70 41 115 6 47 55
53-45PW(S) 135 1:1 143 45*2 57 79 7 41 46
53-55PW(S) 135 1:1 133 55 50 86 6 42 40
54-64PW(T) 137 1:1 115 64 39 100 5 39 51
54-70(PW)HD 137 1:1 109 70 35 116 6 40 62
61-64PW(T) 155 1:1 90 64 31 101 5 30 58
64-55PW(S) 160 1:1 98 55 38 98 5 36 48
64-64PW(T) 160 1:1 85 64 30 115 6 34 61
68-55PW(S) 175 1:1 85 55 34 85 4 28 48
68-64PW(T) 175 1:1 78 64 28 105 5 30 65
72-48PW(S) 182 1:1 90 48 36 78 5 33 39
72-55PW(T) 182 1:1 85 55 30 90 5 27 51
77-48PW(S) 195 1:1 77 48 35 80 4 28 42
77-55PW(T) 195 1:1 67 55 27 88 4 24 55
80-48PW(T) 200 1:1 72 48 33 74 4 25 56
90-48PW(T) 230 1:1 56 48 25 78 4 19 50
100-40PW(T) 255 1:1 58 40 33 63 3 21 37
110-40PW(HD) 280 1:1 48 40 27 64 3 17 40
120-31PW(S) 305 1:1 49 31 35 49 3 17 26
120-34PW(T) 305 1:1 45 34 30 55 3 16 35
120-40PW(HD) 305 1:1 37 40 20 63 3 13 44
130-34PW(T) 330 1:1 40 34 27 55 3 15 37
140-31PW(S) 355 1:1 36 31 26 48 2 12 30
140-34PW(T) 355 1:1 31 34 20 53 3 10 39
140-34TW(T) 355 1:1 33 34 21 56 3 12 41
150-31PW(S) 380 1:1 32 31 23 49 3 11 32
150-34PW(T) 380 1:1 23 34 13 55 3 6.5 42
165-34PW(S) 420 1:1 23 31 15 48 2 7 36
180-27PW(S) 460 1:1 23 27 16 43 2.5 7 31

Product Application

(4) Textile printing net

Polyester screen printing can transfer thick ink deposits and produce special effects, making it the best process for printing high-quality commercial clothing.

(5) CD/DVD printing grid

Polyester screen printing can provide a variety of ink transparency, ink flexibility and various decorative pattern options, which is the most important in terms of fast production cycle and not affecting the performance of the disc. Therefore, screen printing is the preferred printing process for CD/DVD.

(6) Glass printing screen

Pharmacy glassware printing

Home appliance printing.
