Rugged 10.1 Inch Industrial Touch Panel PC With Fingerprint Reader RFID NFC Reader
Rugged 10.1 Inch Industrial Touch Panel PC With Fingerprint Reader RFID NFC Reader
Rugged 10.1 Inch Industrial Touch Panel PC With Fingerprint Reader RFID NFC Reader
Rugged 10.1 Inch Industrial Touch Panel PC With Fingerprint Reader RFID NFC Reader
Rugged 10.1 Inch Industrial Touch Panel PC With Fingerprint Reader RFID NFC Reader
Rugged 10.1 Inch Industrial Touch Panel PC With Fingerprint Reader RFID NFC Reader
Rugged 10.1 Inch Industrial Touch Panel PC With Fingerprint Reader RFID NFC Reader
Rugged 10.1 Inch Industrial Touch Panel PC With Fingerprint Reader RFID NFC Reader
Rugged 10.1 Inch Industrial Touch Panel PC With Fingerprint Reader RFID NFC Reader
Rugged 10.1 Inch Industrial Touch Panel PC With Fingerprint Reader RFID NFC Reader
Rugged 10.1 Inch Industrial Touch Panel PC With Fingerprint Reader RFID NFC Reader
Rugged 10.1 Inch Industrial Touch Panel PC With Fingerprint Reader RFID NFC Reader
Rugged 10.1 Inch Industrial Touch Panel PC With Fingerprint Reader RFID NFC Reader
Rugged 10.1 Inch Industrial Touch Panel PC With Fingerprint Reader RFID NFC Reader
Specifications
Brand Name :
WXYUAN
Model Number :
SY101T-RFID
Certification :
CE FCC ROHS ISO9001
Place of Origin :
Guangdong, China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability :
100000 Piece/Pieces per Month
Delivery Time :
15 days
Packaging Details :
(bubble bag+soft pearl wool wrap) carton+plywood box
Rugged 14" 15.6" inch industrial Touchscreen panel PC J4125 Fanless All-In-One PC with Fingerprint reader card reader webcam
Type :
Panel PC
Touch Screen :
Capacitive touch; resistive touch as options
Network Function :
Wired LAN RJ45,wireless WIFI,3G, 4G network
Input Voltage :
12V 24V as options
RFID Protocol :
ISO 14443A/B, ISO 15693
Connectivity :
WiFi, Bluetooth
RFID Frequency :
13.56MHz
Power Supply :
AC 100-240V, 50/60Hz
RFID Reading Distance :
Up to 10cm
Resolution :
1920*1080
Description

Rugged 10.1 Inch Industrial Touch Panel PC With Fingerprint Reader RFID NFC Reader




LCD Screen
10.1 Inch
Display Ratio
Display Ratio
Screen Resolution
1280*800
Viewing Angle
178/178
Brightness
300cd/㎡ (higher brightness is available as option)
Contrast
900:1
Colour
16.7M
Display Panel Details
Display Panel Brand
LG,Samsung,AUO,Chimei,etc... original brand new + grade A+
Size
10.1 inch
Customize Frame Color
Black, white, green, pink, ivory, wine red, blue, violet, ......can be customized
Body Material
Durable aluminum frame & tempered glass to protect LCD panel against external impacts. front panel compliant NEMA / IP65 waterproof and dustproof standard,so that it can adapt to the harsh industrial site work environment, the most suitable for factory automation, machinery manufacturing, CNC equipment, textile equipment, communication networks, power automation and other industrial applications.
Display Ratio

16:10
Screen Resolution

1280*800
Viewing Angle

178/178
Brightness

300cd/㎡ (higher brightness is available as option)
Contrast

900:1
Colour

16.7M
PC Configuration
Chipset
X86 mainboard: Intel i3 i5 i7/ Celeron J1900/J1800/J6412/J4125, Rockchip: RK3568 RK3399 RK3566 RK3588...... as options
Chipset Frequency
Quad core upto 5Ghz
Chipset Integrated
Intel Bay trail SOC
Ram
4GB/8GB DDR4 SDRAM (64GB max)
Hard Disk
256GB high speed solid state disk upto 3TB (optional)
WiFi
350Mbps 802.11b/n/g Wifi Integrated, (2.4G & 5Ghz dual WIIF module as option)
PC Configuration
Audio
Realtek HD ALC662 HD
Line-In/Line-Out/Speaker out with 1W AMP Circuit
Ethernet Ports
Realtek RTL8111EL PCI-E Gigabit Ethernet LAN RJ45 port
VGA Ports
Default *1 (options)
COM Ports
Default *2 COM (RS232 RS485 RS422 options)
USB Ports
Default *4 USB (2*USB2.0; 2*USB3.0) (options)
Operation System
Win7, Win7 Embedded, Win8, Win10, Ubuntu, VXWORKS, QNX, Linux, Android etc...
Touch Screen
TouchScreen Type
Resistive(4-wire/5-wire); capacitive; SAW/IR as options
TouchScreen Interface
Serial (RS232) or USB or COM as options
Surface Hardness
Mohs' Number 7; Transmittance >75%
Power Supply
Input Voltage
DC 12V or 24V
Output Rating
≦20W
Environmental
Work Temperature
-20 ~ 60°C (-4~140°F)
Storage Temperature
-30 ~ 80°C (-22 ~ 176°F)
Relative humidity
5%~95% (Non condensation)
Shake: SSD applied
1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
Shock: SSD applied
10 G, IEC 60068-2-64, Half-sine wave, 11ms duration
EMC
CE/FCC Class A
Water-proof
Front panel IP65

Features.

Our industrial panel PC are fully-integrated‚ waterproof and dustproof that combine high-performance different touch screen technologies in industrial-grade TFT-LCD flat panels, with sleek, IP65 / NEMA 4-4 x Ingress rating flat front surface industrial design.
Our industrial PC provide reliability, durability, and long expected product life. Impervious to environmental conditions such as liquid spills, splashes and wash-downs, these screens are the most contamination-resistant units available in the market. Our industrial IP65/ NEMA 4 touch computer are designed for process control, food processing equipment, machine control, human interface, automation equipment and in-vehicle use applications. Our panel PC have 7 inches to 55 inches.

Specialties.

1. Long lasting product cycle for continuity thru all phases of project rollouts and servicing
2. Exceptional quality and highly engineered industrial monitors
3. Delivers drift-free operation with lifetime of more than 35 million finger touches like resistive, IR, SAW, Scap, Pcap, etc
4. All steel construction designed for harsh and industrial environments
5. Robust design with aluminum NEMA 4/ IP65 front panel or fully steel enclosed chassis
6. Meets NEMA 4/4x/12 and IP65 standards
7. Multiple mounting options (75*100mm VESA mount and clamps mounting)
8. Accuracy in high-use applications
9. Supports Windows 7/10/11, Linux OS, Android, Mac OS, Ubuntu, Debian
10. CE, FCC, RoHS, ISO9001:2008 compliance.
11. VGA, DVI, HDMI, AV, S-Video, BNC multiple inputs/outputs optional
12. Wide operating temperature from -30 to 80 degrees optional and supports 7/24 running

For OEM ODM service and orders, pls contact.
