1/2-13 UNC Nylon Insert Lock Nuts ASME B18 16.6 Grade 5 Steel Black Zinc
1/2-13 UNC Nylon Insert Lock Nuts ASME B18 16.6 Grade 5 Steel Black Zinc
1/2-13 UNC Nylon Insert Lock Nuts ASME B18 16.6 Grade 5 Steel Black Zinc
1/2-13 UNC Nylon Insert Lock Nuts ASME B18 16.6 Grade 5 Steel Black Zinc
1/2-13 UNC Nylon Insert Lock Nuts ASME B18 16.6 Grade 5 Steel Black Zinc
1/2-13 UNC Nylon Insert Lock Nuts ASME B18 16.6 Grade 5 Steel Black Zinc
1/2-13 UNC Nylon Insert Lock Nuts ASME B18 16.6 Grade 5 Steel Black Zinc
1/2-13 UNC Nylon Insert Lock Nuts ASME B18 16.6 Grade 5 Steel Black Zinc
1/2-13 UNC Nylon Insert Lock Nuts ASME B18 16.6 Grade 5 Steel Black Zinc
1/2-13 UNC Nylon Insert Lock Nuts ASME B18 16.6 Grade 5 Steel Black Zinc
Specifications
Brand Name :
XGFH
Model Number :
ASME B18.16.6
Certification :
ISO9001,EN10204 3.1Certificate
Place of Origin :
China
MOQ :
100PCS
Price :
USD0.01-0.2/PC
Payment Terms :
T/T, L/C
Supply Ability :
500000PCS PER MONTH
Delivery Time :
2-10work days
Packaging Details :
Bulk into plastic bag and carton box,and then Pallet.
Standard :
ASME B18.16.6
Grade :
Class 5
Material :
Carbon steel 35K
Coated :
Black Zinc
Lock type :
Nylon insert
Thread direction :
Right hand
Thread fit :
Coarse
Thread tolerance :
6H
Description :
Hex Nylon Insert Lock Nuts
System of measurement :
Imperial Inch
Description

ASME B18.16.6 Grade 5 Steel Black Zinc 1/2-13UNC Nylon Insert Lock Nuts

Product Description:

1. Certification: ISO9001, ROHS, SGS
2. Available Standard: DIN, ANSI, ASTM, JIS, BSW
3. Strength: Grade 4.8,Grade 8.8,Grade10.9,Grade12.9, A2-70, A4-70, A4-80
4. Finishing: Yellow Zinc, Blue White Zinc Plated, Galvanized,HDG,Chromate,Dacromet, PTFE
5. Available Material: Carbon steel, stainless steel SS304, A2 ,Stainless steel SS314,A4.
6. Size: M3-M36, MOQ: 500pcs, Port: Shanghai,Ningbo
7. Available Packing: Plastic bags+Chipboard Cartons+Plywood pallet with Belt &Film.

Product Name ASME B18.16.6 Grade 5 Steel Black Zinc Nylon Insert Lock Nuts
Material Carbon Steel:C1010, C1018, C12L14, C1035
Color Black,Yellow,White,Blue,Gray
Standard DIN,ASME,ASNI,ISO
Grade Grade 4,Grade 8,Grade 10
Finished Galvanized Steel,Black Oxide,Nickel Plated,Chromat,Dacromet
Thread Coarse,Fine
Used Building Industry Machinery,Wind Energy

Product Drawing:

Hex nylon lock nuts-thick type
ASME/ANSI B 18.16.6-2008
1/2-13 UNC Nylon Insert Lock Nuts ASME B18 16.6 Grade 5 Steel Black Zinc
d(inch) PP s(inch) k(inch) m(inch)
UNC min max min max min
1/4 20 0.43 0.439 0.298 0.328 0.225
5/16 18 0.489 0.502 0.329 0.359 0.25
3/8 16 0.551 0.564 0.438 0.468 0.335
7/16 14 0.616 0.627 0.438 0.468 0.324
1/2 13 0.736 0.752 0.579 0.609 0.464
9/16 12 0.861 0.877 0.626 0.656 0.469
5/8 11 0.922 0.94 0.735 0.765 0.593
3/4 10 1.052 1.064 0.86 0.89 0.742
7/8 9 1.239 1.252 0.969 0.999 0.79
1 8 1.427 1.44 1.016 1.078 0.825
1-1/8 7 1.614 1.627 1.141 1.203 0.93
1-1/4 7 1.801 1.815 1.36 1.422 1.125
1-3/8 6 1.973 2.008 1.547 1.609 1.282
1-1/2 6 2.159 2.197 1.578 1.64 1.313

1/2-13 UNC Nylon Insert Lock Nuts ASME B18 16.6 Grade 5 Steel Black Zinc

1/2-13 UNC Nylon Insert Lock Nuts ASME B18 16.6 Grade 5 Steel Black Zinc

1/2-13 UNC Nylon Insert Lock Nuts ASME B18 16.6 Grade 5 Steel Black Zinc

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory and OEM are available.

Q: How long is your delivery time?

A: Generally it is 2-5 days if the goods are in stock,or it is 15-30 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: 30% T/T in advance ,balance before shipment or L/C.
If you have another question, please feel free to contact us.
