Specifications
Brand Name :
ECOICE
Model Number :
Industrial evaporative air cooler
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
USD350-450/SET
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
500000 SET PER YEAR
Delivery Time :
around 20 DAYS
Packaging Details :
pvc film wrapped
Material :
Stainless Steel 304
Voltage :
380V
Freezing Type :
Compressor System
Refrigerant :
R22
Description

High Efficiency Air Cooler Evaporator for Cold Room

High Efficiency Air Cooler Evaporator for Cold Room

High Efficiency Air Cooler Evaporator for Cold RoomHigh Efficiency Air Cooler Evaporator for Cold Room

High Efficiency Air Cooler Evaporator for Cold Room

Evaporator Introduction

Cold room evaporator can be used as cooling device in different kinds of cold storages, like chiller room, frozen room and blast freezer room. There are DL, DD and DJ model cold room evaporator, which are suit for different room usages.

Cold room evaporator features:
1.Cold room evaporator has reasonable structure, uniform frosting and high efficiency heat exchange.
2.The shell is made of high-quality steel with surface plastic-sprayed, which is corrosion-resistant. Stainless steel shell is optional.
3.Cold room evaporator are assembled with high-quality fan motor with low noise, big air volume. Air duct can be customized for long-distance air.
4.Cold room evaporator is equipped with U-shaped stainless copper pipe evenly, which can shorten the defrosting time.
5.Water defrosting and electric defrosting are optional.

How to select evaporator:
1.When the cold room temperature is around 0℃, select 4.5mm(DL model) as fin space.
2.When the cold room temperature is around -18℃, select 6mm(DD model) as fin space.
3.When the cold room temperature is around -25℃, select 9mm(DJ model) as fin space.
High Efficiency Air Cooler Evaporator for Cold Room
Tech.data for DL ceiling type high temperature evaporator
Note: The tech. data is based on R22,T(r)=0°C, △T=10°C.
Model
Ref.capacity
(kW)
Cooling Area
(㎡)
Fan Qty
Diameter
(mm)
Volume
(m³/h)
Fan motor
(n*w)
Power supply
DL-40
8.2
40
2
400
2*3400
2*180
380V
50Hz
3Ph
DL-55
11.5
55
2
400
2*3400
2*180
DL-80
16.7
80
2
500
2*600
2*550
DL-105
22
105
2
500
2*600
2*550
DL-125
25.8
125
3
500
3*600
3*550
DL-160
33.6
160
3
500
3*600
3*550
DL-185
38.7
185
4
500
4*600
4*550
DL-210
44
210
4
500
4*600
4*550
Tech.data for DD ceiling type middle temperature evaporator
Note: The tech. data is based on R22,T(r)=0°C, △T=10°C.
Model
Ref.capacity
(kW)
Cooling Area
(㎡)
Fan Qty
Diameter
(mm)
Volume
(m³/h)
Fan motor
(n*w)
Power supply
DD-30
6
30
2
400
2*3400
2*180
380V
50Hz
3Ph
DD-40
8
40
2
400
2*3400
2*180
DD-60
12
60
2
500
2*600
2*550
DD-80
15.9
80
2
500
2*600
2*550
DD-100
20
100
3
500
3*600
3*550
DD-120
24
120
3
500
3*600
3*550
DD-140
28
140
4
500
4*600
4*550
DD-160
32.1
160
4
500
4*600
4*550
Tech.data for DJ ceiling type low temperature evaporator
Note: The tech. data is based on R22,T(r)=-25°C, △T=10°C.
Model
Ref.capacity
(kW)
Cooling Area
(㎡)
Fan Qty
Diameter
(mm)
Volume
(m³/h)
Fan motor
(n*w)
Power supply
DJ-30
5.1
30
2
400
2*3400
2*180
380V
50Hz
3Ph
DJ-40
7.8
40
2
400
2*3400
2*550
DJ-55
9.5
55
2
500
2*6000
2*550
DJ-70
9.5
70
3
500
2*6000
3*550
DJ-85
12.8
85
3
500
3*6000
3*550
DJ-100
15.7
100
4
500
3*6000
4*550
DJ-115
18.5
115
4
500
4*6000
4*550
