ASTM A240, JIS G4350 304LN Stainless Steel
ASTM A240, JIS G4350 304LN Stainless Steel
Specifications
Place of Origin :
China
Model Number :
304LN
Standard :
ASTM A240, JIS G4350
Packaging Details :
normally wrapped by plastic film and waterproof paper, and then fastened on wooden pallet or as you
Delivery Time :
15-20 days
Payment Terms :
FOB,CIF or others
Supply Ability :
100000pcs
MOQ :
5 tons
Brand Name :
Seed Steel
Description

Application:304LN Stainless Steel is used for a wide variety of home and commercial applications.

Surface treatment:No.1,2B,BA,No.4,Mirror, HL,or as customers' requirements

ASTM A240, JIS G4350 304LN Stainless Steel

304LN Stainless Steel Introduction

SDJS 304LN stainless is a nitrogen-strengthened version of Carpenter Stainless Type 304L. By means of solid solution strengthening, the nitrogen provides significantly higher yield and tensile strength as annealed than Type 304L without adversely affecting ductility,corrosion resistance or non-magnetic properties. In the hot rolled unannealed condition, yield strengths of 75 ksi (518 MPa) or higher can be achieved for bar diameters up to 1.375 in. (34.925 mm).

304LN Stainless Steel Usage

Magnetic resonance imaging (MRI) scanners, reinforcing bar for structures surrounding MRI scanners, pressure vessels, cryogenic applications.

304 Stainless Steel Typical Chemical Requirements(%)

Type

C

Mn

P

S

Si

Cr

Ni

N

ASTM 304

≤ 0.08

≤ 2.00

≤ 0.045

≤ 0.030

≤ 0.75

18.0--20.0

8.0--10.5

0.10

ASTM 304L

≤ 0.03

≤ 2.00

≤ 0.045

≤ 0.030

≤ 0.75

18.0--20.0

8.0--12.0

0.10

ASTM 304H

0.04--0.10

≤ 2.00

≤ 0.045

≤ 0.030

≤ 0.75

18.0--20.0

8.0--10.5

--

ASTM 304N

≤ 0.08

≤ 2.00

≤ 0.045

≤ 0.030

≤ 0.75

18.0--20.0

8.0--10.5

0.10--0.16

ASTM 304LN

≤ 0.03

≤ 2.00

≤ 0.045

≤ 0.030

≤ 0.75

18.0--20.0

8.0--12.0

0.10--0.16

304 Stainless Steel Mechanical Test Requirements(%)

Type

Tensile Strength,

min

Yield Strength,

min

Elongation in 2

in.or 50mm,min, %

Hardness,

max

ksi

MPa

ksi

Mpa

HB

HRB

HV

ASTM

304

75

515

30

205

40

201

92

--

ASTM

304L

70

485

25

170

40

201

92

--

ASTM 304H

75

515

30

205

40

201

92

--

ASTM 304N

80

550

35

240

30

217

95

--

ASTM 304LN

75

515

30

205

40

217

95

--
