Gl API 2H Gr50 Shipbuilding steel sheet,plate thickness 3mm-380mm
Gl API 2H Gr50 Shipbuilding steel sheet,plate thickness 3mm-380mm
Specifications
Place of Origin :
China
Brand Name :
Seed Steel
Model Number :
API 2H Gr50
MOQ :
Negotiable
Price :
Negotiable
Packaging Details :
normally wrapped by plastic film and waterproof paper, and then fastened on wooden pallet or as you
Delivery Time :
15-20 days
Payment Terms :
FOB,CIF or others
Supply Ability :
100000 pcs
Description

Grade: API 2H Gr50

Type: steel plate, steel angle, bulb flat steel, shipbuilding steel plate, shipbuilding steel angle, shipbuilding bulb flat steel

Standard: ABS/BV/GL/LR/NK/KR/DNV/RINA/CCS/ASTM A131 API 2H

Steel Plate Thickness: 4-260mm,

Steel Plate Width: 1200-4000mm,

Steel Plate Length: 3000-18000mm

Steel Angle: 130*9~150*19mm, 100*63*6~200*125*18mm

Bulb Flat Steel: 80*5~430*20mm

Place of Origin: Henan China (Mainland)

Brand Name: SDJS

Application: Hull structure

Chemical Composition:

Element

Heat Anal.

Prod. Anal.

C

0.18

0.22

Mn

1.15-1.60

P

0.03

S

0.01

0.015

Si

0.05-0.40

0.05-0.45

Cb

0.01-0.04

Ti

0.020(b)

Altot.

0.02-0.06

N

0.012(c)

Mechanical Property:

Mechanical Property

Tensile Strength

(MPa)

Yield Strength (MPa)

% Elongation in 2 in.(50mm) min.

% Elongation in 8 in. (200mm) min.

483 - 620

t ≤ 2.5 in. (63.5 mm) 345

t > 2.5 in. (63.5 mm) 324

21

16

API 2H Gr50 Steel Packing

API 2H Gr50 Steel Packing is normally wrapped by plastic film and waterproof paper, and then fastened on wooden pallet or as you request.
