XJBN-01123 XJBN01123 Hydraulic Main Pump Seal Kit For Hyundai R290LC-7
XJBN-01123 XJBN01123 Hydraulic Main Pump Seal Kit For Hyundai R290LC-7
XJBN-01123 XJBN01123 Hydraulic Main Pump Seal Kit For Hyundai R290LC-7
XJBN-01123 XJBN01123 Hydraulic Main Pump Seal Kit For Hyundai R290LC-7
XJBN-01123 XJBN01123 Hydraulic Main Pump Seal Kit For Hyundai R290LC-7
XJBN-01123 XJBN01123 Hydraulic Main Pump Seal Kit For Hyundai R290LC-7
XJBN-01123 XJBN01123 Hydraulic Main Pump Seal Kit For Hyundai R290LC-7
XJBN-01123 XJBN01123 Hydraulic Main Pump Seal Kit For Hyundai R290LC-7
XJBN-01123 XJBN01123 Hydraulic Main Pump Seal Kit For Hyundai R290LC-7
XJBN-01123 XJBN01123 Hydraulic Main Pump Seal Kit For Hyundai R290LC-7
XJBN-01123 XJBN01123 Hydraulic Main Pump Seal Kit For Hyundai R290LC-7
XJBN-01123 XJBN01123 Hydraulic Main Pump Seal Kit For Hyundai R290LC-7
Specifications
Brand Name :
SUNCAR
Model Number :
XJBN-01123 XJBN01123 Hydraulic pump seal kit
CertifiC-A-Tion :
ISO9001
Place of Origin :
CN
MOQ :
10 Sets
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union,
Supply Ability :
550 sets per week.
Delivery Time :
3-7 days after payment received(Public Holiday Excluded)
Packaging Details :
PP bag inside,carton box outside.
Material :
PU, Rubber, PTFE, NBR, HNBR, ACM, VMQ
Condition :
New, 100%new, brandnew
Brand or manufacturer :
HYUNDAI construction
Style :
Hydraulic seal,Mechanical seal
Part name :
XJBN-01123 Hydraulic pump seal kit
OEM number :
XJBN-01123
Applicability :
HYUNDAI construction
Compatible model :
7-SERIES CRAWLER EXCAVATOR R290LC7 R290LC7A Hyundai
Hardness :
70 degree-95 degree
AppliC-A-Tion :
Machinery repair shops, excavator repair shops;Excavator;Hyundai
Feature :
Oil resistance, Heat resistance, Durable, Sealing performance, Manufacture
Standard or nonstandard :
Standard
Temperature :
EPDM(-50~150°C),PU(-40~90°C)
High light :
XJBN-01123, R290LC-7 Excavator hydraulic pump parts
Description

XJBN-01123 XJBN01123 Hydraulic Main Pump Seal Kit For Hyundai R290LC-7

Description: This is a seal kit of hydraulic pump seal kit,which compatible for HYUNDAI R210LC-7 R290LC-7.

Pump seal kit use in pump,main function is sealing oil.The hydraulic main pump is a kind of fluid pump. About the fluid sealing, it usually uses the mechanical seal to contain the fluid within a vessel (typically pumps, mixers, etc.) where a rotating shaft passes through a stationary housing or occasionally, where the housing rotates around the shaf.

Product name XJBN-01123 XJBN01123 Hydraulic Main Pump Seal Kit For Hyundai R290LC-7
Brand SUNCAR
OEM No.

XJBN-01123 XJBN01123
Color As per standard color
Pump assy' 31N8-10060
AppliC-A-Ted model

7-SERIES CRAWLER EXCAVATOR R290LC7 R290LC7A Hyundai
Feature

Oil resistance, Heat resistance, Durable, Sealing performance, Manufacture
Hardness 70 degree to 95 degree
Advantage

1. Products are enjoying great reputation for its diversifiC-A-Tion,Innovation,and Superior Quality
2. Releasing new items periodically and customizing products to OEM quality
3. Excellent services and durable uses of products
4. Strict quality control
5. Fast delivery
Weight 0.1kg
Temperature

-30 degree to +110 degree
Temperature EPDM(-50~150°C),PU(-40~90°C)
Temperature FKM(-20~200°C),Silicone (-70~220°C)
Temperature VMQ(-60~225℃)
Part name Main pump seal kit
Relative seal kit Boom cylinder seal kit / Arm cylinder seal kit / Swing motor seal kit / Travel motor seal kit / Main pump seal kit / Pilot pump seal kit / Regulator valve seal kit / Main control valve seal kit
Package PP bag, carton, wooden box, or as required
AppliC-A-Tion

Machinery repair shops, excavator repair shops;Excavator;Hyundai
MOQ 100 sets
Type Hydraulic pump seal kit
Payment terms L/C, D/A, D/P, T/T, Western Union,
Relative Brand

Komatsu,Hitachi,Sumitomo,Doosan,Daewoo,Hyundai,C-A-Terpillar,

Kobelco,SUNCARSUNCARSUNCARSUNCARVOLVO,Kato,Samsung,LiebherrI,Mitsubishi and more.
Packaging Nuetral packaging or OEM packaging
Shipping mode By air, by sea, by express
Express Post FedEx , UPS,DHL,TNT etc
Forwarder Your local forwarder or we find for you
Quality Stable quality,OEM standard,Genuine/Aftermarket
Loading port

Huangpu port,China
About us The scope of our business Excavator parts for excavator of various models and brands

SUNCAR Main Pump Seal Kit:

707-99-13103KT 31Q6-10050KT 403-02392 401-00161AKT
708-2L-00500KT 14554943 K9001010 401-00225AKT
708-2L-00300KT 14554943 K9001195 401-00253KT
4463047 708-1L-00471KT K9001902 401-00255KT
4463047 14520405 K9004528 401107-00062
4463047 14533146 K9004882 401107-00478
4633148 S19020-12099 K9005911 401107-00649
707-99-13102KT S19020-11199 PDBS-102310 401107-00681
707-99-13104KT S19020-06999 PDDS-102610 401107-00942
PV10V00003R100 S19020-06299 2437U214R100 401107-00943
PV10V00001R100 YW10V00003S011 2437U188S530 401107-00953
2437U219R100 YX10V00003R400 2437U219R100 401107-01037
2437U470R100 YX10V00003R300 2437U470R100 401107-01084
PA10V00001R400 YX10V00003R200 PA10V00001R400 403-02392
PDBS-102310 708-2L-00300KT 708-2L-00500KT PA10V00001R300 K9001010
PDDS-102610 401107-00649 719517 K9001195
2437U214R100 401107-00681 7009733 K9001902
2437U188S530 401107-00942 2.180-00718 K9004528
XJBN-0097 401107-00943 2401-9084K K9004882
VOE14555298 401107-00953 2401-9154K K9005911
708-2H-00110KT 401107-01037 2401-9155K 708-2H-00026KT
708-2H-01120KT 401107-01084 2401-9164KT 708-2H-01022KT
708-2H-00191KT 403-02392 2401-9165KT 708-2H-00022KT
708-2H-00025KT K9001010 2401-9223KT 708-2H-00150KT
708-2H-00027KT 708-2H-01121KT 2401-9225KT 708-2H-00350KT
708-2H-00024KT 708-2H-01130KT 2401-9231KT 708-2H-00120KT
708-2H-00130KT 708-2H-01110KT 2401-9233KT 708-2H-00131KT
401-00033KT 401-00161AKT 2401-9236AKT 401107-00062
401-00059KT 401-00225AKT 2401-9255KT 401107-00478
2401-9286KT 401-00255KT 2401-9258KT 401-00253KT

Relative Parts:

Pos. Part No Qty Parts name
*. 31N8-10060 [1] MAIN PUMP
*-1. XJBN-00963 [1] MAIN PUMP UNIT
111 XJBN-00953 [1] SHAFT(F)-DRIVE
113 XJBN-00952 [1] SHAFT(R)-DRIVE
116 XJBN-00951 [1] GEAR-1ST
123 XJBN-00950 [2] BEARING-ROLLER
124 XJBN-00949 [2] BEARING-NEEDLE
127 XJBN-00081 [3] SPACER-BEARING
N141. XJBN-00948 [2] BLOCK-CYLINDER
N151. XJBN-00947 [18] PISTON
N152. XJBN-00946 [18] SHOE
153 XJBN-00945 [2] PLATE-SET
156 XJBN-00083 [2] BUSHING-SPHERICAL
157 XJBN-00944 [18] SPRING-CYLINDER
211 XJBN-00085 [2] PLATE-SHOE
N212. XJBN-00943 [2] PLATE-SWASH
214 XJBN-00071 [2] BUSHING-TILTING
251 XJBN-00942 [2] SUPPORT-SP
261 XJBN-00941 [1] COVER(F)-SEAL
271 XJBN-00088 [2] CASING-PUMP
312 XJBN-00940 [1] BLOCK-VALVE
N313. XJBN-00939 [1] PLATE(R)-VALVE
N314. XJBN-00938 [1] PLATE(L)-VALVE
326 XJBN-00937 [1] COVER
401 XJBN-00090 [8] SCREW-HEX SOC HD
406 XJBN-00029 [4] SCREW-HEX
414 XJBN-00160 [4] SCREW-SOCKET
466 XJBN-00030 [2] PLUG
467 XJBN-00936 [2] PLUG
468 XJBN-00031 [4] PLUG
490 XJBN-00032 [32] PLUG
N531. XJBN-00956 [2] PIN-TILTING
532 XJBN-00955 [2] PISTON-SERVO
534 XJBN-00092 [2] STOPPER(L)
535 XJBN-00093 [2] STOPPER(S)
N541. XJBN-00859 [4] SEAT
N543. XJBN-00860 [2] STOPPER
N544. XJBN-00861 [2] STOPPER
545 XJBN-00038 [4] BALL-STEEL
N548. XJBN-00360 [2] PIN-FEED BACK
K702. XJBN-00918 [2] O-RING
K710. XJBN-00095 [2] O-RING
K717. XJBN-00096 [4] O-RING
K724. XJBN-00044 [16] O-RING
K725. XJBN-00045 [4] O-RING
K726. XJBN-00233 [2] O-RING
K728. XJBN-00046 [4] O-RING
K732. XJBN-00912 [2] O-RING
K774. XJBN-00906 [1] SEAL-OIL
K789. XJBN-00099 [2] RING-BACK UP
K792. XJBN-00100 [2] BACK-UP RING

XJBN-01123 XJBN01123 Hydraulic Main Pump Seal Kit For Hyundai R290LC-7
