Lubricating System ASTM C26200 Seamless Copper Tube
Lubricating System ASTM C26200 Seamless Copper Tube
Lubricating System ASTM C26200 Seamless Copper Tube
Lubricating System ASTM C26200 Seamless Copper Tube
Lubricating System ASTM C26200 Seamless Copper Tube
Lubricating System ASTM C26200 Seamless Copper Tube
Lubricating System ASTM C26200 Seamless Copper Tube
Lubricating System ASTM C26200 Seamless Copper Tube
Specifications
Brand Name :
FRANK STEEL
Model Number :
ASTM C26200
Certification :
DNV / LR / BV/ SGS
Place of Origin :
P.R.CHINA
MOQ :
1 Tons or negotiation
Price :
Negotiation
Payment Terms :
T/T, L/C
Supply Ability :
1000 Ton per 30 days
Delivery Time :
about 30 work days
Packaging Details :
plywooden boxes for exporting
Impurity content :
≤0.15%
Softening temperature :
900～1050℃
Grade :
ASTM C26200
Length :
Negotiation ≤12M
3rd Party :
Supported BV SGS
Package :
Plywood wooden box for export
Description

ASTM C26200 Common Brass Seamless Tubes For Heat Exchanger And Lubricating System
1. Description

ASTM c26200 seamless brass tube has good variable performance (the best brass). High strength and good machinability make it easy to weld. The brass tube has good corrosion performance and is very stable. But it is easy to produce corrosion cracking. Brass seamless pipe can be used in heat exchanger and condenser, low temperature pipeline and submarine transportation pipe.


The strength of c26200 seamless copper tube is higher than that of copper tube (but the strength is the lowest among ordinary brass). It has good electrical and thermal conductivity, and has strong corrosion resistance in the atmosphere and fresh water. It is easy to be processed by hot and cold pressure, easy to be welded, forged and tinned, and has no tendency of stress corrosion cracking. It is usually used in oil pressure system, such as lubrication system.

2. Chemical composition

Cu :64.0～68.0
Zn:Remain
Pb:≤0．05
P:≤0．01
Fe:≤0．05
Sb :≤0．005
Bi:≤0.002
Impurity:≤0.3


3. Mechanical properties

Tensile strength: (σ B / MPA): ≥ 440

Elongation: (δ 10 /%) ≥ 25

Elongation: (δ 5 /%) ≥ 30

C26200 Brass Longitudinal Elastic Coefficient KGF / mm2:10500

4. Standard comparison

CategoryChinaUSUKGermanyJapan
GBASTMCDABSDINDigital systemJIS
Common BrassH68C26200　　CuZn332.028　


5. OD table and tolerance

T mm
OD mm		0.15--0.20.2--0.30.3--0.50.5--0.80.8--1.21.2--1.81.8--2.52.5--33--4
2.5--5√√√　　　　　　
6--10√√√√√　　　　
11--15　√√√√√　　　
16--20　　√√√√　　　
20--25　　√√√√√　　
25--35　　√√√√√　　
35--45　　√√√√√√　
45--55　　　√√√√√√

outside diameterAverage tolerance
General (±mm)high(±mm)
3--150.090.05
15--250.10.06
25--500.150.08


6. Wall Thicknese and tolerance

wall thicknessAverage tolerance
General(mm)high(mm)
0.2--0.5±0.02--0.05±0.01--0.03
0.5--0.8±0.05--0.08±0.02--0.05
0.8--1.5±0.08--0.15±0.05--0.12
1.5--2.5±0.15--0.25±0.12--0.2
2.5--4±0.25--4±0.2--0.3


7. Details picture
Lubricating System ASTM C26200 Seamless Copper Tube
