ASTM C26000 Common Brass Seamless Tubes, Very Stable For General Corrosion
ASTM C26000 Common Brass Seamless Tubes, Very Stable For General Corrosion
ASTM C26000 Common Brass Seamless Tubes, Very Stable For General Corrosion
ASTM C26000 Common Brass Seamless Tubes, Very Stable For General Corrosion
ASTM C26000 Common Brass Seamless Tubes, Very Stable For General Corrosion
ASTM C26000 Common Brass Seamless Tubes, Very Stable For General Corrosion
Specifications
Brand Name :
FRANK STEEL
Model Number :
ASTM C26000
Certification :
DNV / LR / BV/ SGS
Place of Origin :
P.R.CHINA
MOQ :
1 Tons or negotiation
Price :
Negotiation
Payment Terms :
T/T, L/C
Supply Ability :
1000 Ton per 30 days
Delivery Time :
about 30 work days
Packaging Details :
plywooden boxes for exporting
Impurity content :
≤0.15%
Softening temperature :
900～1050℃
Grade :
ASTM C26000
Length :
Negotiation ≤12M
3rd Party :
Supported BV SGS
Package :
Plywood wooden box for export
Description

ASTM C26000 Common Brass Seamless Tubes, Very Stable For General Corrosion

1. Description

ASTM C26000 seamless brass pipe has very good malleability (the best one among brass) and high strength. It has good machinability and is easy to weld. It is very stable for general corrosion, but easy to produce corrosion cracking. It can be used as thin-walled pipe, corrugated pipe, papermaking net and house building supplies.

The strength of C26000 seamless copper tube is higher than that of ordinary copper tube. Besides good conductivity and thermal conductivity, din-cuzn36 seamless copper tube has high corrosion resistance in atmosphere and fresh water. It is widely used in factories because of its good malleability, easy cold and hot pressure processing, easy welding, forging, tin plating, no tendency of stress corrosion cracking. It is also commonly used in oil pressure system, such as lubrication system, and also widely used in bathroom and shower room water pipe.

2. Chemical composition

Cu :68.5～71.5
Zn:Remain
Pb:≤0．03
P:≤0．01
Fe:≤0．10
Sb :≤0．005
Bi:≤0.002
Impurity:≤0.3


3. Mechanical properties

Tensile strength: (σ B / MPA): 340～460

Elongation: (δ 10 /%) ≥ 25

Hardness:85～145HV

4. Standard comparison

CategoryChinaUSUKGermanyJapan
GBASTMCDABSDINDigital systemJIS
Common BrassH70C26000260Cz106CuZn302.0265C2600


5. OD table and tolerance

T mm
OD mm		0.15--0.20.2--0.30.3--0.50.5--0.80.8--1.21.2--1.81.8--2.52.5--33--4
2.5--5√√√　　　　　　
6--10√√√√√　　　　
11--15　√√√√√　　　
16--20　　√√√√　　　
20--25　　√√√√√　　
25--35　　√√√√√　　
35--45　　√√√√√√　
45--55　　　√√√√√√

outside diameterAverage tolerance
General (±mm)high(±mm)
3--150.090.05
15--250.10.06
25--500.150.08


6. Wall Thicknese and tolerance

wall thicknessAverage tolerance
General(mm)high(mm)
0.2--0.5±0.02--0.05±0.01--0.03
0.5--0.8±0.05--0.08±0.02--0.05
0.8--1.5±0.08--0.15±0.05--0.12
1.5--2.5±0.15--0.25±0.12--0.2
2.5--4±0.25--4±0.2--0.3


7. Details picture
ASTM C26000 Common Brass Seamless Tubes, Very Stable For General Corrosion
