Alloy Steel ASTM A213 Superheater Hot Finished Seamless Tube Long Lifespan
Alloy Steel ASTM A213 Superheater Hot Finished Seamless Tube Long Lifespan
Alloy Steel ASTM A213 Superheater Hot Finished Seamless Tube Long Lifespan
Alloy Steel ASTM A213 Superheater Hot Finished Seamless Tube Long Lifespan
Specifications
Brand Name :
NEW FORCE
Model Number :
ASTM A213
Certification :
MTC
Place of Origin :
China
MOQ :
10 tons or negotiable
Supply Ability :
200000 tons per month
Delivery Time :
2~10 weeks
Packaging Details :
bundle
Standard :
ASTM A213
Structure :
Seamless
Application :
Superheater
Grade :
T2, T5, T9, T11, T12, T22, T91 and T92
Condition :
Hot Rolled or Cold Drawn
Length :
Fixed or Random
Material :
Alloy Steel
Usage :
Heat Exchanger
Description

Alloy Steel ASTM A213 Superheater Hot Finished Seamless Tube Long Lifespan

1. Standards:
ASTM A213 Standard Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes

2. Application:
Power plant; Boilers; Heat-Exchangers; Chemical Fertilizer; Petrochemicals; Offshore Oils; Gas Productions; Refineries and etc.

3. Ordering Information

Quantity (feet, meters, or number of lengths),

Name of material (seamless tubes),

Grade (T2, T5, T9, T11, T12, T22, T91, and T92),

Condition (hot finished or cold finished),

Size (outside diameter and minimum wall thickness),

Length (specific or random),

Hydrostatic Test or Nondestructive Electric Test

Increased Sulfur, and

Special requirements and any supplementary requirements selected.

4. Chemical Requirements

Chemical Requirements
Grade UNS Designation Composition, %
C Mn p S Si Cr Mo Other Elements
max max
T2 K11547 0.10-0.20 0.30-0.61 0.025 0.025 0.10-0.30 0.50-0.81 0.44-0.65 　
T5 K41545 0.15 max 0.30-0.60 0.025 0.025 0.50 max 4.00-6.00 0.45-0.65 　
T9 K90941 0.15 max 0.30-0.60 0.025 0.025 0.25-1.00 8.00-10.00 0.90-1.10 　
T11 K11597 0.05-0.15 0.30-0.60 0.025 0.025 0.50-1.00 1.00-1.50 0.44-0.65 　
T12 K11562 0.05-0.15 0.30-0.61 0.025 0.025 0.50 max 0.80-1.25 0.44-0.65 　
T22 K21590 0.05-0.15 0.30-0.60 0.025 0.025 0.50-1.00 1.9-2.6 0.87-1.13 　
T91 K90901 0.07-0.14 0.30-0.60 0.02 0.01 0.20-0.50 8.0-9.5 0.85-1.05 V 0.18-0.25
N 0.030-0.070
Ni 0.40 max
Al 0.04max
Nb 0.06-0.1
T92 K92460 0.07-0.13 0.30-0.60 0.02 0.01 0.50 max 8.5-9.5 0.30-0.60 Ni 0.40 max
V 0.15-0.25
B 0.001-0.006
Nb 0.04-0.09
N 0.030-0.070
Al 0.04max
W 1.50-2.00

5. Available Size Range

OD Thickness
mm inch mm SCH
88.9~141.3 3''~ 5'' 2.11~19.05 SCH10~XXS
*If the steel grades and size you are looking for are not listed above, please contact us for further information.

6. Heat Treatment Requirements

Heat Treatment Requirements
Grade UNS Number Heat Treat Type Austenitizing/Solutioning Temperature min or range Cooling Media Subcritical Annealing or Tempering Temperature
min or range °F 【°C】
T2 K11547 full or isothermal anneal normalize and temper subcritical anneal … … 1200 to 1350°F
【650 to 730°C】
T5 K41545 full or isothermal anneal normalize and temper … … 1250°F【675°C】
T9 S50400 full or isothermal anneal normalize and temper … . 1250°F【675°C】
T11 K11597 full or isothermal anneal normalize and temper … … 1200°F【650°C】
T12 K11562 full or isothermal anneal normalize and temper subcritical anneal … … 1200 to 1350 °F
【650 to 730°C】
T22 K21590 full or isothermal anneal normalize and temper … … 1250°F【675°C】
T91 K90901 normalize and temper 1900°F【1040°C】 … 1350°F【730°C】
T92 K92460 normalize and temper 1900°F【1040°C】 … 1350°F【730°C】

Alloy Steel ASTM A213 Superheater Hot Finished Seamless Tube Long Lifespan
