Boiler High Pressure Carbon Steel Pipe ASTM A106 Grade C 56'' 1422mm X 120mm Size
Boiler High Pressure Carbon Steel Pipe ASTM A106 Grade C 56'' 1422mm X 120mm Size
Boiler High Pressure Carbon Steel Pipe ASTM A106 Grade C 56'' 1422mm X 120mm Size
Boiler High Pressure Carbon Steel Pipe ASTM A106 Grade C 56'' 1422mm X 120mm Size
Specifications
Brand Name :
NEW FORCE
Model Number :
56''
Certification :
MTC
Place of Origin :
China
MOQ :
10 tons or negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200000 tons per month
Delivery Time :
5~10 weeks
Packaging Details :
bare and loose
Steel :
Carbon Steel
Application :
High Pressure Boiler
Material :
Gr. C
Standard :
ASTM A106
Size :
1422mm x 120mm
OD :
56''
Description

Boiler High Pressure Carbon Steel Pipe ASTM A106 Grade C 56'' 1422mm X 120mm Size

TIPTOP piercing and rolling technology possesses a number of patents in designing and manufacturing the equipment, and has improved in lots of areas targeting better performance and efficiency, which has distinguished itself from its peers.

-Stable, fast and continuous

-Flexible on non-standard sizes

-Swift tooling switching

-Uniform mechanical properties and dimensions in longitudinal & transverse directions

-Better surface conditon thanks to shorter rolling time & good tooling quality

-Three-roller / five racks sizing machine can avoid inner hexagon significantly

1. Available Size Range:

OD Thickness
mm inch mm SCH
88.9~1422 3''~ 56'' 2.11~140 ≥SCH10
*If the steel grades and size you are looking for are not listed above, please contact us for further information.

2. Application

For the high-pressure boiler and steam pipes, and the petrochemical industry pipes;
Power plant; Chemical Fertilizer; Petrochemicals; Offshore Oils; Gas Productions; Refineries and etc.

3. Standards

ASTM A106 ——Standard Specification for Seamless Carbon Steel Pipe for High-Temperature Service

4. Dimensional Tolerance

Pipe types OD (mm) Tolerance WT (mm) Tolerance
High Pressure Boiler Tube 219~457 ±1.0％ ≤20 -10% ~ +12.5%
20~40 -10% +10%
457~1422 ±0.9％ ＞40~70 -7％, +9％
＞70~20 -6％, +8％

5. Chemical Composition:

High Pressure Boiler Tube Chemical Requirements
Standard Grade Composition, %
C Mn P S Si Cr Mo Ni V Others
ASTM A106 Grade C 0.35 0.29–1.06 0.035 0.035 0.1 0.4 0.15 0.4 0.08 　

6. Mechanical Properties

Standards Steel pipes No. Tensile strength Yield strength Elongation Impact energy Hardness
(Mpa) (Mpa) (%) (J)
ASTM A106 Grade C ≥485 ≥275 ≥20 ≥35 /

Please contact us for your full range of tailored material to your specification and design. Maximum OD: 56'', Wall thickness up to 140mm.
