P92 High Pressure Boiler Tube , ASTM A335 Seamless Boiler Tube 1321mm X 140mm Size
P92 High Pressure Boiler Tube , ASTM A335 Seamless Boiler Tube 1321mm X 140mm Size
P92 High Pressure Boiler Tube , ASTM A335 Seamless Boiler Tube 1321mm X 140mm Size
P92 High Pressure Boiler Tube , ASTM A335 Seamless Boiler Tube 1321mm X 140mm Size
Specifications
Brand Name :
NEW FORCE
Model Number :
52''
Certification :
MTC
Place of Origin :
China
MOQ :
10 tons or negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200000 tons per month
Delivery Time :
5~10 weeks
Packaging Details :
bare and loose
Steel :
Alloy Steel
Application :
High Pressure Boiler
Material :
P92
Standard :
ASTM A335
Size :
1321mm x 140mm
OD :
52''
Description

P92 52'' 1321mm x 140mm High Pressure Boiler Tube Alloy Steel ASTM A335

TIPTOP is providing ASTM A335 P92 alloy steel seamless pipes, which are mainly used for high-temperature service. P92 pipe is a kind of chrome moly pipes.

1. Available Size Range:

OD Thickness
mm inch mm SCH
88.9~1422 3''~ 56'' 2.11~140 ≥SCH10
*If the steel grades and size you are looking for are not listed above, please contact us for further information.

2. Standards

ASTM A335 ——Standard Specification for Seamless Ferritic Alloy-Steel Pipe for High-Temperature Service

3. Application

For the high-pressure boiler and steam pipes, and the petrochemical industry pipes;
Power plant; Chemical Fertilizer; Petrochemicals; Offshore Oils; Gas Productions; Refineries and etc.

4. Steel pipes No. of main production:

ASTM A335 Grade P5, P9, P11, P12, P22, P91, P92

5. Dimensional Tolerance

Pipe types OD (mm) Tolerance WT (mm) Tolerance
High Pressure Boiler Tube 219~457 ±1.0％ ≤20 -10% ~ +12.5%
20~40 -10% +10%
457~1422 ±0.9％ ＞40~70 -7％, +9％
＞70~20 -6％, +8％

6. Chemical Composition:

High Pressure Boiler Tube Chemical Requirements
Standard Grade UNS Designation Composition, %
C Mn P S Si Cr Mo Ni V Others
ASTM A335 P5 K41545 0.15max 0.30-0.60 0.025 0.025 0.50max 4.00-6.00 0.45-0.65 　 　 ...
P9 S50400 0.15max 0.30-0.60 0.025 0.025 0.25-1.00 8.00-10.00 0.90-1.10 　 　 ...
P11 K11597 0.05-0.15 0.30-0.60 0.025 0.025 0.50-1.00 1.00-1.50 0.44-0.65 　 　 ...
P12 K11562 0.05-0.15 0.30-0.61 0.025 0.025 0.50 max 0.80-1.25 0.44-0.65 　 　 ...
P22 K21590 0.05-0.15 0.30-0.60 0.025 0.025 0.50 max 1.90-2.60 0.87-1.13 　 　 ...
P91 K91560 0.08-0.12 0.30-0.60 0.02 0.01 0.20-0.50 8.00-9.50 0.85-1.05 0.4 0.18-0.25 N 0.030-0.070
Al 0.02max
Cb 0.06-0.10
Ti 0.01 max
Zr 0.01max
P92 K92460 0.07-0.13 0.30-0.60 0.02 0.01 0.50 max 8.50-9.50 0.30-0.60 0.4 0.15-0.25 N 0.03-0.07
Al 0.02 max
Cb 0.04-0.09
W 1.5-2.00
B 0.001-0.006
Ti 0.01 max
Zr 0.01 max

7. Mechanical Properties

Standards Steel pipes No. Tensile strength Yield strength Elongation Impact energy Hardness
(Mpa) (Mpa) (%) (J)
ASTM A335 P5 ≥415 ≥205 ≥22 ≥35 ≤187HB
P9 ≥415 ≥205 ≥22 ≥35 　
P11 ≥415 ≥205 ≥22 ≥35 ≤163HB
P12 ≥415 ≥220 ≥22 ≥35 ≤163HB
P22 ≥415 ≥205 ≥22 ≥35 ≤163HB
P91 585～760 ≥415 ≥20 ≥35 ≤250HB
P92 ≥620 ≥440 ≥20 ≥35 ≤250HB

P92 High Pressure Boiler Tube , ASTM A335 Seamless Boiler Tube 1321mm X 140mm Size
